Operation
30 S&C Instruction Sheet 659-520
Information Status Alarms
These notifications provide the status of the PureWave SMS-250 system and will not
affect the proper operation of the system. See Table 5 for the listed information statuses.
Table 5. PureWave SMS-250 Information Status Alarms
Alarm
Ac Breaker Indicates the ac circuit breaker is closed and has been closed
Closed for 300 ms .
Troubleshooting Tip: No action is required.
Auto Reset Indicates an auto reset has been activated
Command Troubleshooting Tip: No action is required.
Auxiliary Indicates the PureWave SMS-250 system is taking
SMS-250 commands from a lead PCS
Troubleshooting Tip: No action is required.
Battery at Open Indicates the battery is at open circuit voltage to avoid
Circuit Voltage charging or discharging the battery (This is used when the
inverter is running vars and the power is held at zero .)
Troubleshooting Tip: No action is required.
Compact Flash Indicates there is a problem with the compact flash card used
Problem to store snapshots
Troubleshooting Tip: Replace the Compact Flash card. If
the problem still persists, contact S&C Electric Company.
Dc Breaker Indicates the dc circuit breaker is closed and has been closed
Closed for 300 ms
Troubleshooting Tip: No action is required.
Dc Pre-charge Indicates the dc pre-charge voltage is above what is
Voltage High expected, causing problems with charging the dc link
Troubleshooting Tip: Contact S&C Electric Company.
Dc Pre-charge Indicates the dc pre-charge voltage is below what is
Voltage Low expected, causing problems with charging the dc link
Troubleshooting Tip: Contact S&C Electric Company.
Ethernet Power Indicates the PureWave SMS-250 system is following a power
setpoint from an Ethernet command
Troubleshooting Tip: No action is required.
Ethernet Switch Indicates the Ethernet switch is reporting a problem
Problem Troubleshooting Tip: Check all blue Ethernet cables to
make sure they are connected.
Ethernet VARs Indicates the PureWave SMS-250 system is following a var
command from the Ethernet connection to the lead unit
or a master control
Troubleshooting Tip: No action is required.
KVA Limit Is Indicates the PureWave SMS-250 system is not outputting
Limiting Vars the commanded amount of vars due to the real power flow
occurring at the same time
Troubleshooting Tip: To generate the full reactive power
expected, reduce the real power command.
Description
TABLE CONTINUED ▶
Reset Type
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
SELF
