Fujitsu N7100 Consumable Replacement And Cleaning Instructions
  1. Manuals
  2. Brands
  3. Fujitsu Manuals
  4. Scanner
  5. N7100
  6. Consumable replacement and cleaning instructions

Fujitsu N7100 Consumable Replacement And Cleaning Instructions

Hide thumbs Also See for N7100:

Advertisement

Quick Links

Download this manual
N7100 C
R
C
I
ONSUMABLE
EPLACEMENT AND
LEANING
NSTRUCTIONS
N7100 C
R
ONSUMABLE
EPLACEMENT
C
I
AND
LEANING
NSTRUCTIONS
1
CG00002-291401

Advertisement

loading

Related Manuals for Fujitsu N7100

Summary of Contents for Fujitsu N7100

  • Page 1 N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS N7100 C ONSUMABLE EPLACEMENT LEANING NSTRUCTIONS CG00002-291401...
  • Page 2 N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS ONSUMABLES Description Life Fujitsu P/N Brake Roller 200,000 PA03706-0001 Pick Roller Brake Roller Pick Roller Note: The Brake Roller and Pick Roller are included when ordering part number PA03706-0001...
  • Page 3 N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS HECKING THE IFE OF THE ONSUMABLES 1. On the [Main Menu] or [Job Menu] window, press the [Consumable Alert] button. HINT The [Consumables Alert] button on the [Job Menu] window can be shown by pressing The [Consumable Alert] window appears.
  • Page 4 N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS EPLACING THE OLLER The Roller Set is made up of the brake roller and the pick roller. The procedure for replacing each roller is as follows. 1. Turn off the scanner power and wait for at least 15 minutes.
  • Page 5 N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS EPLACING THE OLLER CONT 2. Remove the shaft. Lift the right side of the roller first, then pull out the shaft from the slot on the left. Brake Roller Shaft 3. Remove the brake roller from its shaft...
  • Page 6 N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS EPLACING THE OLLER CONT 5. Install the brake roller with the shaft on the scanner. Fit the left end of the shaft in the slot, then install the rest of the shaft in place.
  • Page 7 N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS EPLACING THE OLLER CONT Open the sheet guide. Slide the side guides all the way, and pull the sheet guide open from the dip. Side Guides Sheet Guide Rotate the lock release tab on the shaft in the direction of the arrow.
  • Page 8 N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS EPLACING THE OLLER CONT 3. Remove the pick roller. Slightly lift the Lock release tab of the shaft (by approximately 5 mm), slide the shaft to the direction of the arrow below, and lift it up all the way.
  • Page 9 N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS EPLACING THE OLLER CONT 4. Install a new pick roller on the scanner. Insert the left end of the shaft into the slot of the scanner, and lower the other end gradually. Pick Roller 5.
  • Page 10 N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS EPLACING THE OLLER CONT 6. Close the sheet guide. Make sure that both ends of the sheet guide are locked firmly. 7. Close the LCD cover. You should hear a click. Be careful that the LCD cover does not shut on your fingers.

  • Page 11: Cleaning Supplies

    UPPLIES AND ARTS TO LEAN Cleaning Supplies CLEANING CLOTH (25/PK) CG90000-120001 Contact your FUJITSU scanner dealer or an authorized FUJITSU scan- ner service provider to obtain these products. For more details, refer to the following web page : http://www.fujitsu.com/global/about/resources/shop/computing/peripheral/ scanners/...

  • Page 12: Cleaning The Scanner Body

    N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Cleaning the Exterior of the Scanner Cleaning the Scanner Body The scanner exterior (other than the touch panel), the ADF paper chute, and the stacker must be cleaned using a dry cloth or a cloth slightly moistened with Cleaner F1 or a mild detergent.

  • Page 13: Cleaning Inside The Scanner

    N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Cleaning Inside the Scanner Clean the interior of the scanner with a cloth slightly moistened with Cleaner F1 or the Cleaning Wipe. Scanning repeatedly may cause dust and paper dust to accumulate inside the scanner resulting in a scanning error.
  • Page 14 N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Cleaning Inside the Scanner (cont.) Pull the cover release catch toward you and open the LCD cover. Cover Release Catch Be careful that the LCD cover does not shut on your fingers.
  • Page 15 N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS Clean the following parts with a soft cloth slightly moistened with Cleaner F1 or with the Cleaning Wipe. Ultrasonic sensor (x2) (Also on the ADF paper chute) Idler roller G l a s s...
  • Page 16 N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS LEANING NSIDE THE CANNER CONT Ultrasonic sensor (x2) Clean lightly with a soft cloth to wipe their surfaces clean. If you have trouble wiping them with the cloth, use a cotton swab. Idler roller (x4) Gently rotate the idler rollers by hand as you wipe them clean.
  • Page 17 N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS LEANING NSIDE THE CANNER CONT 2 On the [Main Menu] or [Job Menu] window, press the [Maintenance] button. HINT The [Maintenance] button on the [Job Menu] window can be shown by pressing .
  • Page 18 N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS LEANING NSIDE THE CANNER CONT The [Roller Cleaning] window appears. 4 Open the LCD cover. 5 Lightly press a soft cloth slightly moistened with Cleaner F1 or the Cleaning Wipe against the surface of the rollers.
  • Page 19 N7100 C ONSUMABLE EPLACEMENT AND LEANING NSTRUCTIONS...
  • Page 20 1250 East Arques Avenue Sunnyvale, CA 94085-4701 (800) 626-4686 (408) 746- 7000 info@fcpa.fujitsu.com © 2015 Fujitsu Computer Products of America, Inc. All rights reserved, Fujitsu and the Fujitsu Logo are registered trademarks, ScanCare and ScanAid are trade- marks of Fujitsu Computer Products of America, Inc All statements herein are valid only in the U.S.
