Thank you for choosing Ifö Sign.
You have chosen an environmentally friendly, easy to clean and elegantly designed WC unit.
To guarantee correct and reliable installation of this product we urge you to follow the installation
instructions. Enware cannot accept liability for damage that occurs as a result of faulty installation.
Ifö Sign 6860, 6861
Y ou have chosen the optimum standard WC unit with
built-in S-trap. It can usually be installed as quickly
and easily, and in the same situations, as WC units
with traditional open S-traps.
WC connections
The water connection to the cistern inlet is a 1/2" BSP male.
Looking from the front of the pan, it is located on the right
hand side, on the bottom of cistern.
See "S-Trap WC Set Out" previous page for
connection dimensions and other dimensions on WC unit.
Bonding/Siliconing
This WC unit is suitable for bonding/siliconing,
see images 11-15.
The method applies to installation of WC units using elastic
free surface.
After pan is levelled, water is connected and pan is visually
inspected for any leaks, install the rear cover to plug the
inspection hole. Apply silicone sealant underneath
the base of the pan and around the perimeter to create a
Also apply silicone sealant around the rear cover to create
Ensure no gap is left that can let any moisture to get through
inside the base of the pan.
supplied blind cover plugs (IFO94752) must be used
in the screw holes on the WC unit, and sealed with silicone.
Do not use the WC before the silicone has cured.
For toilets with Arm Supports (e.g. IFO98125):
Due to the extra force applied to the toilet pan by the arm
stability. Fixing the toilet pan with only the silicone seal is
Waterproof Floor Mounting
Aavailable as an option:
This WC is prepared for the Fresh WC function, with a
screw, as illustrated in images 16 - 17.
Depending on the content of the tablet, it produces a fresh
blocks that are suspended from the rim of the bowl, by
Ifo Fresh Sticks are available from Enware.
Product code IFO94568 - 10 packets of 5 sticks.
Dosing
