IFO SIGN WC P-Trap
RAISED HEIGHT TOILET
Installation and Maintenance Instructions
I00512_06Jun23
1300 369 273 | info@enware.com.au
enware.com.au
stars the more
water efficient
WATER RATING
www.waterrating.gov.au
3.3
4.5 L per full flush / 3 L per half flush
AS1172-1
WM-040187
The more
litres
average flush
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for enware IFO SIGN WC P-Trap
Summary of Contents for enware IFO SIGN WC P-Trap
- Page 1 IFO SIGN WC P-Trap RAISED HEIGHT TOILET Installation and Maintenance Instructions The more stars the more water efficient WATER RATING www.waterrating.gov.au litres average flush 4.5 L per full flush / 3 L per half flush AS1172-1 WM-040187 I00512_06Jun23 1300 369 273 | info@enware.com.au...
-
Page 2: Table Of Contents
Page Product Description Contents Installation Floor Mounting Method Installation - Accessories Maintenance Cleaning Troubleshooting Spare Parts Warranty Call 1300 369 273 www.enware.com.au... -
Page 3: Product Description
6872 Model (Raised Height P-Trap) IFO6872 CARE602 CARE603 6872 CARE6872 Bottom inlet connection FRONT VIEW SIDE VIEW www.enware.com.au Call 1300 369 273... -
Page 4: Contents
Installations not complying with AS/NZS 3500, the PCA or the manufacturer’s instructions may void the product and performance warranty provisions. Enware Australia advises:1. Due to ongoing Research and Development, specifications may change without notice; 2. Component specifications may change on some export models. -
Page 5: Installation
• Bracket fixing (Optional - IFO98015 Bracket sold separately.) If toilet has support arms or may have support arms in future (raised height toilet models only), use: • Pan Screw fixing; or • Bracket fixing (Optional - IFO98015 Bracket sold separately.) www.enware.com.au Call 1300 369 273... - Page 6 Use white blind cover plugs supplied to plug the screw holes on the pan. Call 1300 369 273 www.enware.com.au...
- Page 7 5. Fix the pan in place with pan screws. Hand 60°-65° tighten the screws, but do not over-tighten. (Over- tightening screws will cause the ceramic to crack.) 6. Attach white screw caps (supplied) onto the heads of fixing screws. www.enware.com.au Call 1300 369 273...
- Page 8 6. Fix the bracket onto floor using the threaded rods and matching washers and nuts. 7. Cut off any excess threaded rod. Bracket Position WC pan xing hole positions Bolt hole positions to x bracket onto oor Call 1300 369 273 www.enware.com.au...
- Page 9 4x 12Gx50mm do not over-tighten. (Over-tightening screws will Screws cause the ceramic to crack.) (Drill pilot holes on bracket with 12. Attach white screw caps (supplied) onto the 3 mm drill) heads of fixing screws. www.enware.com.au Call 1300 369 273...
- Page 10 The inlet connection requires sealing with a washer. For hard pipe connection with compression nuts or thread sealing, use a loose nut extension fitting (available separately, Enware part code IFOS-009). (Use loose nut The inlet connection is flexible. Hold the inlet thread...
-
Page 11: Installation - Accessories
Cover Screw Rod by opening the flush button and releasing the tablet in the blue Cover Screw Max. 1 Rod, as illustrated. The tablet produces a fresh odour and cleaning effect on the whole bowl and colour. www.enware.com.au Call 1300 369 273... -
Page 12: Maintenance
To access the cistern valves, first take the complete cistern off the pan. To remove cistern valves, release the inlet hose from the bottom of cistern by pulling down and out. Then twist the valve assembly clockwise and lift it out of the cistern. Call 1300 369 273 www.enware.com.au... - Page 13 Feed the inlet tube over to the back right hand corner of cistern, then fit the inlet fitting into the housing on the bottom of cistern. CLICK Reinstall cistern cover, connect water supply and test operation. www.enware.com.au Call 1300 369 273...
-
Page 14: Cleaning
Water leaks between Spreader has dislodged Take ceramic cistern cover off, cistern and pan from cistern during transit fit spreader back onto cistern, reinstall cistern onto pan For further assistance, call Enware on 1300 369 273. Call 1300 369 273 www.enware.com.au... -
Page 15: Spare Parts
Ifo S-Trap Pan Back Inspection Opening IFO733 Cover Plug -Soft Fresh Sticks Blue (Pack of 5) IFO94690 Ifo Cistern Key with Hex and T25 Torx IFO91960 Loosenut Extension 1/2” BSP for inlet con- IFOS-009 nection www.enware.com.au Call 1300 369 273... -
Page 16: Warranty
All notifications and accompanying forms must be sent to us marked for the attention of Enware Pty Ltd, Except as provided or referred to in this document, 9 Endeavour Road, Caringbah NSW 2229. We can we accept no other or further liability for any...
