Ifo Sign Toilet - S Trap
One-piece free standing toilet with seamless cistern
lid for ease of cleaning enabled with Fresh WC
hygienic dosing solution in the flush button.
FEATURES
• Free standing WC
• Seamless cistern for added infection control
• WELS 4 star rated (4.5/3L Flush)
• Patented Fresh WC blue stick technology
enabled for increased infection control
• Option to place WC at 45 degree angle in
corner
• Cistern bolted onto pan for enhanced back
support
• Increased foot print enhances stability
• Fully glazed on back and inside rim to avoid
bacteria growth
• 100mm minimum set out to finished wall
and no maximum (does not cut into alcove)
• CAD drawings available from website
• All pans are to be fixed using high grade
anti-bacterial silicone of appropriate colour
and where exposed mounting holes are
provided, 316 stainless steel screws are
to be used
Product Code
IFO6860 IFO Sign Toilet - S Trap
IFO6860001010 IFO Sign Toilet - S Trap, no screw holes
OPTIONS
Raised Flush Button
Pressalit IFO Hard Seat - white
Pressalit Sign Soft Close Seat - white
Pressalit Sign Hard Seat No Lid - white
Pressalit Sign Hard Seat - anthracite grey IFO554112-BD1999
Pressalit Sign Hard Seat - white
Fresh Sticks - 10 packets of 5 sticks
Floor Anchor
The more
stars the more
water efficient
A joint government and industry program
Licence No. 0058
4.5
litres per full flush
AS 1172.1
3
litres per half flush
WMKA21026
3.1 litres per average flush
IAPMO R&T
When tested in accordance with Standard AS/NZS 6400
For more information and to compare
products, refer to:
www.waterrating.gov.au
Version:Sep15
Call 1300 369 273
www.enware.com.au/ifo
Enware Australia Pty Limited
9 Endeavour Rd Caringbah NSW 2229 Australia
Ph: 02 8536 4000 Fax: 02 8556 4055
IFO98308
IFO724D55999
IFO624000-DO39999
IFO553000-BD1999
IFO554000-BD1999
IFO94568
IFO98015
Certi kate Nr. 2004-SKM-AE-825 Certi kate Nr. 2004-SKM-AE-825
ISO 14001:2004 ISO 14001:2004
Certi kate Nr. 2004-SKM-AQ-2054 Certi kate Nr. 2004-SKM-AQ-2054
ISO 9001:2000 ISO 9001:2000
355
95
860
360-415
*For more details on the set out, refer to separate document Ifo
WC Set Out TDS
IFO6860
670
40
420
70
Ø102 100
100 Min.*
