UTC-WALL-MOUNT4E

VESA 75 mm
ƒ Handy and Convenient supporter
ƒ Firmly fix to solid wall
ƒ Material:Steel
ƒ Weight capacity up to 20 kg
ƒ For UTC-510/307/310
Step 1
Tighten the wall plate on the wall by using four screws.
Step 3
Take the UTC unit with wall mount device plate to slide
into wall mount plate on the wall.
UTC-Wall-Mount Installation Guide
Step 2
Tighten the wall mount device plate on the rear cover of
UTC unit by using four screws into VESA holes.
Online Download
www.advantech.com/products
