PASCO OS-8458B Instruction Sheet

Manufacture
I.D. Label
1 0
1 0
R o
s e
Introduction
PASCO model OS-8458B is a diode laser designed for use with
PASCO Basic Optics systems. The laser is permanently mounted
in a holder that can be snapped into a Basic Optics bench or used
freestanding on a tabletop. (It can also be used with any PASCO
track if it is connected to the OS-8472 Dynamics Optics Carriage
- not included.) The holder includes vertical and horizontal
adjustment screws for fine-tuning the angle of the laser beam. An
included AC adapter provides power.
Compatible Equipment
The laser can be used with PASCO Basic Optics equipment and
is included in various systems offered by PASCO. See the
PASCO catalog or the on-line store at www.pasco.com for a com-
plete description of all Basic Optics equipment.
800-772-8700
®
Basic Optics Diode Laser
OS-8458B (green)
R E
A S
D
D
1 F
o o
v i l
t h i
l e ,
l l B
®
C A
l v d
. 9
.
5 7
4 7
U S
A
Included Equipment
Green Laser in Mount
AC Adapter, 9 VDC output
Green Laser
in mount
Part Number
OS-8458B
see Technical Support
___________________________________________________

CAUTION - use of controls or adjustments or performance
of procedures other than those specified herein may result in
hazardous radiation exposure.
• LASER LIGHT - DO NOT STARE INTO BEAM.
• CLASS 2 LASER PRODUCT
• This Laser Product is designated as Class 2 during all proce-
dures of operation.
• Do not point the laser or allow the laser to be directed or
reflected toward people or animals.
___________________________________________________
Instruction Sheet
0 1 2 - 1 5 5 9 0 B
Horizontal adjustment
screw
Power switch
Power input jack
Vertical adjustment
screw
www.pasco.com
