Materials Included with the Elite Modem
The Elite modem contains standard RJ-11 telephone and jack interfaces to
connect the existing voice facility, and a 10Base-T Ethernet RJ-45 interface to
connect the Ethernet cable from the end-user PC.
The following table shows the components included in the Elite Modem
package. If you are missing any item, contact your product distributor for a
replacement.
Table 1-2List of Materials
Description
Elite Modem
Class 2, 5V, AC Power Supply
10Base-T Ethernet
Cable Assembly, RJ-45, 8 PIN 8
Conductor
Cable Assembly, RJ-11, 6 PIN, 6
Conductor
Revision 2.01
Item
Elite Modem Installation Guide
Installing the Elite Modem 1-3
08-01002-01
