- Page 1 RF-7220-07-1 Wireless Outdoor Siren Installation Sheet © 2017 UTC Fire & Security Americas Corporation, Inc. 1 / 3 P/N 466-2912 • REV A • ISS 05JAN17...
- Page 2 EN: Installation Sheet Wiring diagram Figure 2 legend (1) Siren PCB (7) Tamper (2) Speaker (8) Beacon + (red) (3) Beacon (9) Beacon- (black) (4) 4X lithium battery pack (not included) (10) Siren driver + (red) (5) IO module power cable (black) (11) Siren driver −...
- Page 3 Note: The lithium battery pack BS7201-N is not included with the siren, and must be purchased separately. Contact information Specifications www.utcfireandsecurity.com or www.interlogix.com Power supply specifications Number and type of BS7201-N, 4-cell custom battery pack, Customer support batteries lithium (purchased separately) For customer support, see www.utcfssecurityproducts.eu...
