- Page 1 Volt Sensor Pocket Tester Catalog # 61-063 Features Checks non-contact voltage from 40 - 600 VAC CAT III - 600V Audible and visual indication Tests for energized circuits Over-molded rubber cushion grip Compact rugged housing 1-year warranty...
- Page 2 6. Voltage detector will not read voltages through metal conduct or the like, and will not read through walls at a distance. 7. If the equipment is used in a manner not specified by IDEAL, the protection provided by the equipment may be impaired.
- Page 3 RATING & SPECIFICATIONS Model: 61-063 Working Voltage Range: 40-600 VAC max to ground Frequency: 50/60Hz Dielectric Strength: 2000V, 1 minute, 100uA or less during dielectric strength test Safety: IEC61010-1 Cat III - 600V Operating Environment: 32° to 104° F (0° to 40° C). 80% RH max.
