- Page 1 DT-TABLES ASSEMBLY INSTRUCTIONS *Model views may not represent exact model purchased...
- Page 2 TABLE OF CONTENTS ASSEMBLY COMPONENTS_______________________________________3 APRON TO LEG ATTACHMENT___________________________________4 LEG ASSEMBLY_________________________________________________5 LEG BRACES, STRETCHERS, AND LEG LEVELER___________________6...
-
Page 3: Assembly Components
ASSEMBLY COMPONENTS ITEMS INCLUDED PART # PART# 1-LEG KIT,TABLE 1-APRON ASSY,TABLE 1-TOP,TABLE BOX,TABLES 4-SCREW,7MMX50MM, 228564 8-SCREW,7MMX90MM 227578 OPTION FOR STRETCHERS OPTION FOR LEG BRACES 236263 3- SCREW,#6X3/4 TRUSS HEAD,QUAD,BLACK DESCRIPTION DATE Original Created 6-12-09 Deleted leg boot, added pencil strip, & chamfer leg 1/21/10... - Page 4 Assembly Instructions for Tables Items not included but needed for assembly: 1. ½” wrench Instructions: 1. Lay the table on the floor with the apron side up. (Be sure to lay the table on a clean surface so you don’t damage the tabletop.) 2.
- Page 5 3. Please note: There may be either 1 or two legs with a chamfer (45) on it. The legs with the chamfer go alongside the adjustable top as pictured below. 4. Apply a lock washer and a 5/16” nut onto each stud bolt. Tighten each nut using a minimum of 12 foot-pounds but not exceeding 17 foot-pounds of torque.
- Page 6 5. Screw leg levelers into t-nut in the bottom of the leg. 6. Turn the table over so the top is up. Set your table in place and adjust the leg levelers to level the table. 7. Add the pencil strip to the adjustable top using the (3) #6 x ¾ truss head, black screws provided.
