- Page 1 4741K MICRO-MOBILE CABINET ASSEMBLY INSTRUCTIONS...
- Page 2 TABLE OF CONTENTS PAGE REVISIONS TABLE …………………………………………………………………………………………………………………….…………………..……….…………..……….…………………………………………..…………………………… ASSEMBLY COMPONENTS …………………………………………………………………………………………………………………….…………………..……….……….…………….………………………………………… CASTER ASSEMBLY …………………………………………………………………………………….…………………..……….……………………………..……….…………………………………..…………………………………………… DIVIDER ASSEMBLY …………………………………………………………………………………………………………………….…………………..……….…..……….…………….………………………..………………………………… TROUBLE SHOOTING_________________________________________________________6 - 2 -...
- Page 3 ASSEMBLY COMPONENTS ITEMS INCLUDED PART # PART # ASSEMBLY INSTRUCTIONS 1-HARDWARE BOX 4-CASTER,4" SWIVEL TOP PLATE 100081 1 - ELECTRICAL EXTENSION CORD 100036 1 - CASTER HARDWARE BAG 206509 12-MICROSCOPE DIVIDERS 100995 ***Please Refer to Ken-A-Vision’s #SCGNO9 Manual for operating instructions*** DESCRIPTION DATE INITIAL...
- Page 4 Assembly Instructions for 4741K MICRO-MOBILE CABINET Items not included but needed for assembly: 1. ½”Wrench 2. Adjustable pliers Instructions: 1. Attach the (4) Casters into place using the (16) 100488 100081 4” SWIVEL TOP PLATE, W/BRAKE SCREW, ¼” - 20X1 ¼” SLOTTED FLAT, & the (16) 100483 NUT, ¼” - 20 HEX ZINC into the bottom of the base as shown.
- Page 5 Insert microscope dividers (100995) into pre-drilled holes as shown. NOTE: Doors removed to show details. Figure 2 3. Clean top with water only. - 5 -...
- Page 6 Trouble Shooting Tip: If the lights on the power distribution panel do not come on and run in sequence, t is possible the power supply has become disconnected inside the unit. This can be checked by removing one of the wood panels the power distribution panel is mounted on.
