Summary of Contents for montpellier MDI450-2
- Page 1 Dishwasher User’s Manual...
-
Page 2: Description Of The Appliance
Description of the Appliance 1. Upper basket with racks 2. Upper spray arm 3. Lower basket 4. Lower spray arm 5. Filters 6. Rating plate 7. Control Panel 8. Detergent and rinse-aid dispenser 9. Cutlery basket 10. Salt dispenser 11. Upper basket track latch Fixed Top Sprinkler: Provides better washing performance for utensils in the upper basket. -
Page 3: Safety Advice
Safety Advice This appliance is manufactured and intended for DOMESTIC use only. Any • guarantee offered with the appliance is not valid for any installation in a commercial environment. This appliance MUST BE EARTHED! • Never try and disconnect the power by pulling the supply cable – hold the plug •... -
Page 4: Operating The Appliance
Operating the Appliance Before Operating the Appliance Adding Salt • Remove the lower basket and then unscrew the salt container cap (1). • Add water and approximately 1kg of specialist dishwasher salt to the container until almost overflowing. N.B. It is normal for a small amount of water to come out of the container whilst filling it with salt. - Page 5 Remove the Rinse Aid Filler Cap (1). • Add Rinse Aid until the rinse aid level indicator becomes dark (2). • Replace the Filler Cap (3). • If the rinse aid level is sufficient the indicator light will be dark on the •...
- Page 6 Combined Detergent – Recommended Usage If you are using a combined detergent, add a rinse aid agent to your machine and switch the rinse agent setting to its lowest position (1) and activate the tablet detergent button in order to obtain better results. Depending on the water hardness you may need to fill the salt container with salt.
- Page 7 The Control Panel 1. Power On/Off Button 2. Programme Display – Indicates the selected programme number. 3. Programme Selection Button – Allows you to select a suitable programme. 4. ½ Load Button – By using this feature, you can reduce the duration of selected programs, and decrease the power and water consumption of your machine.
- Page 8 Loading the Baskets Upper Basket There are folding racks on the upper basket of your machine. You can use these racks in an open or closed position depending on whether you want to place cups, long glasses, or cutlery on them Ensure that items are not blocking the rotation of the top spray arm.
- Page 9 Alternate Basket Loads Lower Basket Upper Basket Incorrectly Distributed Loads...
- Page 10 Programme Selection Table...
- Page 11 Selecting a Programme Machine is started when the On/Off button is pressed, one dash appears in the programme display and the end of programme indicator turns on. When you select a programme with the programme selection button, the programme you select (1, 2, etc) appears on the programme display and the end of programme indicator turns off.
- Page 12 Chancelling a Programme Open the door of your machine. The last selected programme will appear on the screen. The discharge process will start after the door is closed. The machine discharges Keep the programme selection button pressed for 3 seconds. The End of Programme indicator will water for roughly 30 seconds.
- Page 13 Cleaning the Spray Arms Small particles of food will over time get into the spray arms and cause blockages. Periodically remove the spray arms (as shown below) and wash them in warm soapy water. Blocked spray arms are not covered under the Guarantee! To remove the lower spray arm pull it upwards, so that the upper...
- Page 14 Error Codes Error Code Error Description Control Make sure the water inlet tap is totally open and that there is Inadequate water supply no water leak Close the water inlet tap, remove the water inlet hose from the tap and clean the filter at the connection end of the hose Restart your machine, contact the Repairtech helpline if the error resumes Continuous water input...
- Page 15 Before Calling Service If you appear to have a problem with your dishwasher, please take a few minutes to check the following ‘trouble shooting’ guide. The problem may be easily solved without the need for a service call. Dishwasher Will Not Start Is the power on at the socket? •...
- Page 16 Knocking Noise From Inside the Cabinet The spray arm is catching against an item in the basket – reposition the • items Items of crockery are loose in the basket and water pressure is causing • them to move – reposition the items of crockery The Crockery is not Clean Ensure that you load items correctly –...
