5. Technical specifications

Function
Modes
Pump size
Input power
Max Amperage
Connection Size
Pressure Tank
Pump Start pressure
Pump stop
Maximum pressure
Max ambient air temp
Max water temp
Maximum flow
Cable to Pump
Power Cable
IP Rating
Accessories
(Sold Separately)
NXT PRO
On/Off + Configuration
Mode 1 Pressure Controller
Mode 2 Pressure Switch
Up to 2.2kW - 240V 1Ph
80 - 240V 1ph 50Hz
Generator compatible
16 amp
1" BSP Male
0.3l removable spring controlled diaphragm tank
Internal 1" BSPF thread to connect external pressure
vessel once OEM accumulator removed
Default 2.2 bar
User adjustable 0.5 - 6.0 bar
Flow less than 0.9 lpm in Mode 1
User adjustable 1.8 - 9.0 bar in Mode 2
Pressure differential range 0.3 – 8.5 bar
10 bar.
3 - 50°C
3 - 60°C
Tested to 150 lpm / 9m
Tested to 300 lpm / 18 m
'Plug and Play' IEC C13/C14 appliance connector.
Fly lead supplied when purchased as control only
10 amp
15 amp cables
1 ¼" union kit for flows up to 300 lpm
3
/hr - 1" outlet
/hr - 1 ¼" outlet
3
IP65
5
