Danfoss MLM Series Application Manuallines page 8

Application Guidelines
50 Hz
Model HP
MLZ015 2
MLZ019 2.5
MLZ021 3
MLZ026 3.5
MLZ030 4
MLZ038 5
MLZ042 5.5
MLZ045 6
MLZ048 7
MLZ058 7.5
MLZ066 9
MLZ076 10
MLZ015 2
MLZ019 2.5
MLZ021 3
MLZ026 3.5
MLZ030 4
MLZ038 5
MLZ042 5.5
MLZ045 6
MLZ048 7
MLZ058 7.5
MLZ066 9
MLZ076 10
* at EN12900 conditions: To= -10°C, Tc= 45°C, RGT= 20°C, SC= 0K
** R507 performance data are nearly identical to R404A performance data
Motor voltage code 4: 400V/3~/50 Hz & 460V/3~/60 Hz
MLZ/MLM042: motor voltage code 5: 220-240V/1~/50 Hz
Only motor code4.code5 of MLZ are qualified with R407A/R407F
8
FRCC.PC.015.A8.02
Technical specifications
Nominal Power
cooling capacity * input *
W Btu/h kW
3100 10580 1.55
4000 13652 2.04
4200 14334 2.21
5300 18089 2.71
6500 22184 2.99
7500 25597 3.47
8600 29352 4.53
9100 31058 4.55
10000 34130 5.01
11500 39249 5.69
13400 45734 6.78
14700 50171 7.51
3300 11263 1.66
4300 14676 2.19
4500 15358 2.37
5700 19454 2.90
6900 23549 3.20
8000 27304 3.72
9200 31399 4.85
9800 33447 4.87
10800 36860 5.37
12300 41980 6.09
14400 49147 7.26
15800 53925 8.04
Efficiency *
Swept volume
COP EER
W/W Btu/h/W cm3/rev
2 6.83 33.77
1.96 6.69 43.51
1.91 6.52 46.21
1.96 6.69 57.11
2.17 7.41 68.79
2.16 7.37 80.95
1.9 6.48 93.09
2.01 6.86 98.57
2 6.83 107.48
2.02 6.89 125.95
1.98 6.76 148.8
1.96 6.69 162.43
2 6.83 33.77
1.96 6.69 43.51
1.91 6.52 46.21
1.96 6.69 57.11
2.17 7.41 68.79
2.16 7.37 80.95
1.9 6.48 93.09
2.01 6.86 98.57
2.01 6.86 107.48
2.02 6.89 125.95
1.99 6.79 148.8
1.96 6.69 162.43
Net weight
Displacement Oil charge
(with oil)
m3/h Litres
5.88 1.06 30.84
7.57 1.06 30.84
8.04 1.06 30.84
9.94 1.06 30.84
11.97 1.57
14.09 1.57
16.20 1.57
17.15 1.57
18.70 1.57
21.92 2.66
25.89 2.66 45.18
28.26 2.66 45.18
5.88 1.06 30.84
7.57 1.06 30.84
8.04 1.06 30.84
9.94 1.06 30.84
11.97 1.57
14.09 1.57
16.20 1.57
17.15 1.57
18.70 1.57
21.92 2.66
25.89 2.66 45.18
28.26 2.66 45.18
kg
37.2
37.2
37.2
37.2
37.2
44
37.2
37.2
37.2
37.2
37.2
44
