Danfoss MLM Series Application Manuallines page 10

Application Guidelines
60 Hz
Model HP
MLZ015
MLZ019 2.5
MLZ021
MLZ026 3.5
MLZ030
MLZ038
MLZ045
MLZ048
MLZ058 7.5
MLZ066
MLZ076
MLZ015
MLZ019 2.5
MLZ021
MLZ026 3.5
MLZ030
MLZ038
MLZ045
MLZ048
MLZ058 7.5
MLZ066
MLZ076
* at EN12900 conditions: To= -10°C, Tc= 45°C, RGT= 20°C, SC= 0K
** R507 performance data are nearly identical to R404A performance data
Motor voltage code 4: 400V/3~/50 Hz & 460V/3~/60 Hz
MLZ/MLM042: motor voltage code 1: 208-230V/1~/60 Hz
Only motor code4.code5 of MLZ are qualified with R407A/R407F
10
FRCC.PC.015.A8.02
Technical specifications
Nominal
cooling capacity *
W Btu/h
2 3800 12969
4900 16724
3 5300 18089
6400 21843
4 7900 26962
5 9200 31399
6 11200 38225
7 12200 41638
14300 48805
9 16700 56997
10 18100 61775
2 4100 13993
5300 18089
3 5700 19454
6900 23549
4 8500 29010
5 9800 33447
6 12000 40956
7 13100 44710
15300 52218
9 18000 61433
10 19400 66212
Efficiency *
Power
input *
COP EER
kW W/W Btu/h/W
1.85 2.04 6.96
2.40 2.06 7.03
2.63 2.01 6.86
3.10 2.07 7.06
3.52 2.25 7.68
4.10 2.24 7.65
5.37 2.09 7.13
6.01 2.03 6.93
6.68 2.14 7.30
7.89 2.12 7.24
8.64 2.09 7.13
1.98 2.05 7.00
2.57 2.06 7.03
2.81 2.01 6.86
3.32 2.08 7.10
3.77 2.26 7.71
4.38 2.24 7.65
5.75 2.09 7.13
6.44 2.04 6.96
7.15 2.14 7.30
8.45 2.13 7.27
9.25 2.09 7.13
Swept volume Displacement
cm3/rev m3/h
33.77 7.09
43.51 9.14
46.21 9.70
57.11 11.99
68.79 14.45
80.95 17.00
98.57 20.70
107.48 22.57
125.95 26.45
148.8 31.25
162.43 34.11
33.77 7.09
43.51 9.14
46.21 9.70
57.11 11.99
68.79 14.45
80.95 17.00
98.57 20.70
107.48 22.57
125.95 26.45
148.8 31.25
162.43 34.11
Net weight
Oil charge
(with oil)
Litres kg
1.06 30.84
1.06 30.84
1.06 30.84
1.06 30.84
1.57 37.2
1.57 37.2
1.57 37.2
1.57 37.2
2.66 44
2.66 45.18
2.66 45.18
1.06 30.84
1.06 30.84
1.06 30.84
1.06 30.84
1.57 37.2
1.57 37.2
1.57 37.2
1.57 37.2
2.66 44
2.66 45.18
2.66 45.18
