Application Guidelines

MLZ/MLM015-019-021-026

Brazed
129
111
34°
Ø163.5 - 165.5
Discharge
port1/2"
ODF
72.1-75.1
360
195
11
All dimensions in mm
16
FRCC.PC.015.A8.02

Dimensions

239
190
4 x Ø 19
110
190
31°
73°
45°
Suction port 3/4" ODF
Oil sight glass
393
Schrader valve
and cap
231
79
55
19
Terminal box P & T (spade terminals)
P & T terminal box type
Refer to section "Ordering information and packaging" for overview of shipped mounting accessories
129
239
110
Discharge line
Ø1.00"-14UN(2A)
72.1-75.1
360
195
All dimensions in mm
Rotolock
239
190
suction line
31°
34°
73°
45°±2°
Ø163.5-165.5
Oil sight glass
Schrader valve
and cap
11
Mounting grommet
1.7
29.5
41
Ø11
Ø 41
Recommended torque for mounting bolts:
11 Nm (±1 Nm)
4x Ø19.0
111.5
190
239
Suction line
Ø1"1/4-12UN(2A)
393
231
79
55
19
not supply with
the grommet
5/16" - 18 UNC
self tapping
