< Important>
When 3.5 type device is implemented into the central slot, remove the device cover
from the dust-proof bezel then install the dust-proof front bezel.
When 3.5 type device is implemented
into this position, remove the device
Device cover
cover.
(1) Push the hook of the bezel cover, then remove the bezel cover.
③
②
①
(2) Open the key, then remove the HDD cover.
HDD Cover
②
①
③
28
