1
......................................................
W
One PCI-P16C16 card
One companion PCI CD (V5.1 or later)
On
e Quick Start Guide(This document)
2
......................................................
Installing Windows Driver
Follow those steps:
I. Setup the Windows driver.
You can get the driver from:
CD:\NAPDOS\PCI\PCI-P16R16\DLL_OCX\
http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/pci-p16r16/dll_ocx/
hat's on your package?
Language
Version
Update
- 1 -
PCI-P16C16
English
V1.1.1
May 2011
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ICP DAS USA PCI-P16C16
Summary of Contents for ICP DAS USA PCI-P16C16
- Page 1 English Version V1.1.1 Update May 2011 ……………………………………………… hat’s on your package? One PCI-P16C16 card One companion PCI CD (V5.1 or later) e Quick Start Guide(This document) ……………………………………………… Installing Windows Driver Follow those steps: I. Setup the Windows driver. You can get the driver from: CD:\NAPDOS\PCI\PCI-P16R16\DLL_OCX\ http://ftp.icpdas.com/pub/cd/iocard/pci/napdos/pci/pci-p16r16/dll_ocx/...
- Page 2 Windows driver only support windows 98/NT/2000 and XP/2003/vista 32-bit versions. Click button to start installation. III. Click button to install driver into the default folder. IV. Click button to continue installation. Click button to reboot the PC. ……………………………………………… stalling Hardware on PC Follow those steps: Shut down your computer Remove all covers from the computer...
- Page 3 ……………………………………………… in Assignments - 3 -...
- Page 4 ……………………………………………… elf-Test I. Prepar e items. DN-37(Optional) External Power Device ex.DP-665(Optional) II. Use DN-37 to connect the CN1.OUT 0 with CN1.DIA_0. III. CN1.GND1, CN1.GND2 connects to Exterior GND(-). (pin1 connect to pin12; pin22,pin26 connect to GND(-)). IV. Use DP-665 +24 V connects to DN-37 CN1.Ext.Power1 and t DN-37 DIB_0.
- Page 5 V. Run the DIO sample program. Get the zipped file from: CD:\NAPDOS\PCI\PCI-P16R16\dll_ocx\Demo VI. Check number of the PCI-P16C16, and test DIO function. Please follow those steps: The one PCI- P16C16 had successfully installed to PC. Select the board number for the PCI- P16C16.It starts from 0.
- Page 6 ……………………………………………… dditional Information PCI- P16C16 Card Product page: http://www.icpdas.com/products/DAQ/pc_based/pci_p16c16.htm DN-37(Optional) page: http://www.icpdas.com/products/DAQ/screw_terminal/dn_37.htm DP-665(Optional) page: http://www.icpdas.com/products/Accessories/power_supply/dp-665.htm Documents: CD:\NAPDOS\PCI\PCI-P16R16\manual http://ftp.icpdas.com.tw/pub/cd/iocard/pci/napdos/pci/pci-p16r16/manual/ Software: CD:\NAPDOS\PCI\PCI-P16R16 http://www.icpdas.com/download/pci/p16r16/index.htm The ICP DAS Web Site http://www.icpdas.com Technical support Supplies and ordering information Ways to enhance your device Application story Contact Us Service@icpdas.com Copyright ©2008 by ICP DAS Co., Ltd.
