Leightronix UltraNEXUS HD Blade Product Quick Manual page 4

3
WinLGX Software Installation
WinLGX System Management Interface
This section provides instructions for installing the UltraNEXUS-HD Blade system management software, WinLGX
along with some basic configuration steps. For more detailed configuration information, refer to the full manual. WinLGX
configurations (particularly for switch type and size) must be completed before a schedule can be created.
1.
Visit www.leightronix.com/support.html and find
your UltraNEXUS-HD series product.
2.
Click the appropriate link for your product under
the Current Client Software Version column to
download the WinLGX installer.
3.
Navigate to where the WinLGX installer (WinLGX_
v7.0.x.x_Installer.exe) is saved on your
computer.
4.
Right click the WinLGX installer and choose the
run as administrator option to start the
installation. Follow the prompts to complete setup.
5.
As WinLGX installs, two additional windows will be
displayed. NOTE: Refer to Figure 6.a on the right
for a description of each window and installation
guidelines.
6.
Click Finish to close the WinLGX setup
wizard and return to Windows.
WinLGX Minimum
System Requirements
• Microsoft Windows 7 or newer
• 1.6 GHz or faster processor
• 2 GB of RAM
NOTE: The following steps were written
for Windows 7 and 8, and may vary for
later versions.
™ ,
Microsoft Visual C++ library window: This
window is used to install the Microsoft Visual C++
runtime components needed to run WinLGX on your
computer or network. Click Repair if you are using
WinLGX version 6 or older (i.e., WinLGX versions
6.0.1.48). If you are already running WinLGX 7 or
greater, click Cancel on the bottom of the popup
window.
NOTE: Choosing Cancel does not stop the WinLGX
installation process, which will continue as a
background operation.
VLC media player setup wizard: VLC media player
is necessary in order to use the WinLGX software
preview and confidence monitor features (for more
information on these features, refer to the full
manual). If you do not intend to use the WinLGX
software monitor features, you may opt out of the
VLC installation process by clicking Cancel. If you
choose to install VLC media player, but do not want the
player to be automatically chosen for media playback,
deselect Audio Files and Other under the File Type
Associations settings during installation.
Figure 6.a
WinLGX Site Manager
Use the WinLGX Controller Site Manager window to store your UltraNEXUS-HD Blade server's network IP
address information. WinLGX uses each server's IP address to locate the server and send/receive system
information. Manage the IP address listing of your UltraNEXUS-HD Blade as follows:
1.
Click Add on the Controller Site
Manager window to open the Add New
Controller window.
2.
Enter the IP address displayed on the
server's front panel. This address can be
viewed from the front panel display by
pressing the multidirectional switch up/
down until the IP address is shown.
3.
Enter username in the User field.
4.
Enter password in the Password field.
NOTE: The username and password are case-sensitive and may only contain letters and numbers.
FACTORY-DEFAULT USERNAME AND PASSWORD FOR THE ULTRANEXUS-HD BLADE
User field: admin
Password field: The last six digits of the UltraNEXUS-HD Blade server's serial number. NOTE: Enter any letters
in uppercase (example 102A2A).
How To Schedule Your
First Broadcast
Head to the Scheduling Events
section in the full manual to set up
your first broadcast!
Contact tech support
for additional assistance:
(800) 243-5589
support@leightronix.com
5.
Click Find. If the correct IP address has
been added, your server's site ID, location,
serial number, and time zone display in the
Add New window.
6.
Click OK to enter your UltraNEXUS-HD
Blade server in the site manager database.
7.
If applicable, repeat steps 1-6 for each
additional UltraNEXUS-HD series server in
your system, otherwise click Connect to log
in to the UltraNEXUS-HD Blade server.
