Summary of Contents for BENETEAU OCEANIS 55

  • Page 1 OCEANIS 55 OWNER'S MANUAL 146876 Index F...
  • Page 3: Table Of Contents

    5 ....................... Introduction 9 ..................General specifications 13 ..............Design categories and displacement 17 ..................Stability and buoyancy 21 ....................Manoeuvrability 23 .................... Rigging and sails 41 ......................Safety 55 ........Information relating to fire risks and risks of explosion 61 .....................Electrical system 89 ..........Liquefied Petroleum Gas(LPG)system (LPG) CONTENTS 95 ..................Domestic appliances 11 11...
  • Page 5 A BENETEAU is made to last, in order to bring you all the pleasure you expect from a vessel over a period of many years. Each boat is subject to the utmost attention to detail from the design stage right through to launching.
  • Page 6 This manual has been produced to help you enjoy using your boat in all safety. It contains the details of the boat and of all the equipment provided and installed on your boat, as well as the instructions for their use. Read it carefully and really get to know your boat before using it. This owner's manual is not in any way a navigation or mariner's training manual.
  • Page 7 Notes on reading this manual The various symbols used throughout the manual for crucial safety information are as follows: DANGER Indicates the existence of a serious inherent danger with a high risk of death or serious injury if the appropriate precautions are not taken. WARNING Indicates the existence of a danger which could lead to injury or death if the appropriate precautions are not taken.
  • Page 9 TECHNICAL SPECIFICATIONS Construction ..................10 General dimensions ................. 10 Engine....................10 Electricity ..................10 Capacities..................11 Sails ....................11...
  • Page 10: General Specifications

    CONSTRUCTION Model..................................................OCEANIS 55 Architect / Interior design......................................Berret Raccoupeau / Nauta design Builder ..................................................SPBI S.A Principal means of propulsion ............................................... Sail Hull and deck construction material ............................Laminated sandwich glass / Polyester / Balsa wood Application..................................................infusion GENERAL DIMENSIONS L.O.A (L )* ..................................................
  • Page 11 CAPACITIES Total mass of the liquid content of fixed tanks when they are full ................................. 1 688 kg Fuel capacity: Tank 1 (*) ..............................................200 l Fuel capacity: Tank 2 (*) ..............................................200 l Fuel capacity: Extra tank ..............................................200 l Fresh water capacity: Tank 1 (*) ............................................
  • Page 13: Design Categories And Displacement

    DESIGN CATEGORIES AND DISPLACEMENT Boats n°1 to n°4 ................14 Boats from the hull N°5..............15 Design categories................16...
  • Page 14 - Some of the data is shown on the manufacturer's plate fixed to the boat. The explanation of the data is given in the appropriate chapters of this manual. - The recommended maximum load includes the weight of all the people onboard, of provisions, personal belongings, of all equipment not included in the weight of the boat in ballast, of the cargo (if relevant) and of all liquids contained in fixed tanks when full (fuel, water, grey water, black water).
  • Page 15 BOATS FROM THE HULL N°5 - Do not exceed the recommended maximum 2.2.1 Deep draught version (Deep draught keel) number of people onboard. However many people are onboard, the total, combined load of Design category people and any gear or equipment must never exceed the recommended maximum load.
  • Page 16 DESIGN CATEGORIES Category A: At high sea The boat is designed to sail in winds that may exceed Beaufort force 8 and in waves of a significant height of 4 metres and more. This craft is largely self-sufficient. Abnormal conditions such as hurricanes are excluded. Such conditions may be encountered on extended voyages, for example across oceans, or inshore when unsheltered from the wind and waves for several hundred nautical miles.
  • Page 17: Stability And Buoyancy

    STABILITY AND BUOYANCY Stability data ..................18 Access to the boat................19...
  • Page 18 STABILITY DATA - Fully laden displacement was used to evaluate the stability and buoyancy of the boat. The value of this displacement - Reduce speed in waves. can be found in paragraph "Technical specifications" at the beginning of this manual. - Always adjust the speed and heading of - Any changes in the distribution of loads onboard (for example by adding a raised structure for fishing, fitting a radar or your boat according to the sea conditions.
  • Page 19 ACCESS TO THE BOAT - It is imperative that both the cockpit and the Access to the cockpit engine compartment are kept closed when at sea. - When at sea close the guardrail side- opening or openings. - Slamming an access hatch may cause injury : always close the hatch gently and carefully.
  • Page 20 Access to the crew cabin Ladder Fitting / Holding Stability and buoyancy 146876 Index F...
  • Page 21 MANOEUVRABILITY ........22 Shallow draught version (Shallow draught keel) ..........22 Deep draught version (Deep draught keel) ......22 Very shallow draught keel version (Short draught keel)
  • Page 22 - This boat was tested using the stability rating STIX, which is a worldwide safety measurement of stability and which takes account of the length of the vessel, its displacement, hull dimensions, stability characteristics and flooding - If carrying too much sail, the boat could proofness.
  • Page 23: Rigging And Sails

    RIGGING AND SAILS Rigging diagram ................24 Standing rigging ................29 Running rigging................31 Sails ....................32 Setting the sails ................33 Deck fitting ..................37 Winches..................... 37 Genoa furler ..................39...
  • Page 24 RIGGING DIAGRAM 5.1.1 Classical mast Reference Designation Genoa furler Genoa sheet Mainsail sheet SHEET - Asymmetrical spinnaker / Code 0 Asymmetric spinnaker tack point / Code 0 Fore stay sail furler Self-tacking jib sheet Rigging and sails 146876 Index F...
  • Page 25 5.1.2 System - Mast step (Classical mast) Port side Reference Designation Genoa halyard Main halyard Boom topping lift Reef 1 Mainsail foot Mainsail sheet Starboard Reference Designation Kicking strap Reef 3 Reef 2 - 10 Spinnaker halyard - 11 - 12 Fore stay sail halyard Self-tacking jib sheet 146876...
  • Page 26 STEP Rigging and sails 146876 Index F...
  • Page 27 5.1.3 System - Mast step (Roller furling mast) Port side Reference Designation Genoa halyard Main halyard Boom topping lift Mainsail foot Mainsail sheet Starboard Reference Designation Kicking strap Main furling line Spinnaker halyard Fore stay sail halyard Self-tacking jib sheet 146876 Index F...
  • Page 28 STEP Rigging and sails 146876 Index F...
  • Page 29 STANDING RIGGING - To hoist a crew member up to the top of the mast, make a bowline with the halyard directly on the bosun's chair ring (never use the halyard snap shackle or shackle). - Never hoist a crew member when sailing in heavy weather.
  • Page 30 Reference Designation Quantity Forestay V2D3 Backstay Fixed bridle Adjustable bridle Lower - Forestay Hydraulic backstay Assembly: inside the cockpit Rigging and sails 146876 Index F...
  • Page 31 RUNNING RIGGING - Inspect the halyards for wear and condition. When not sailing, slacken the genoa halyard and keep it away from the forestay (risk of - Regularly check the condition of the jam cleat jaws. halyard becoming furled around the forestay, - Regularly clean the backstay blocks with fresh water.
  • Page 32 SAILS General points When the sailing season is over and, if possible, before winter, take the suit of sails to a - The working life of a sail mainly depends on its being regularly maintained. professional for an overhaul and effective - When sailing, trim the sails properly in accordance with the stresses in order to reduce the harmful strains on the fabric.
  • Page 33 SETTING THE SAILS 5.5.1 Mainsheet system Reference Designation Kicking strap Swivel single pulley Pulley Mainsail sheet Single frame pulley Reeving loop 146876 Index F...
  • Page 34 5.5.2 System - Genoa Reference Designation Genoa sheet Genoa furler line Single clutch Single block returns Swivel single pulley Rigging and sails 146876 Index F...
  • Page 35 5.5.3 System - Easy Sail Reference Designation Genoa sheet genoa car adjustment 5.5.4 System - Tacking jib Reference Designation Swivel single pulley Swivel single pulley SHEET - Staysail 146876 Index F...
  • Page 36 5.5.5 System - Code 0 / Asymmetrical spinnaker 5.5.6 System - Fore stay sail furler Reference Designation Reference Designation Swivel single pulley Fore stay sail furler Spinnaker sheet Swivel single pulley Spinnaker tack Furling line Rigging and sails 146876 Index F...
  • Page 37 DECK FITTING General points - Inspect each piece of deck gear regularly (blocks, shackles, swivels, jam cleats, etc): Check that there are no cracks, corrosion or deformation. - When replacing a piece of deck gear, make sure that you use a type with the same strength specifications. - If careful, regular inspections are not carried out and damaged parts and/or worn ropes are not replaced, a block or tackle may suddenly break and cause an accident or serious injury and damage the boat.
  • Page 38 Rinse winches regularly with fresh water - Rinse winches regularly with fresh water. - Refer to the manufacturer's instructions for use and maintenance. - Dismantle, clean and lubricate each winch annually. Parts that have been damaged or worn may need replacing. - Avoid bulky clothing, long hair and jewellery Layout of components: that might become caught in the winch when it is...
  • Page 39 GENOA FURLER Refer to the manufacturer's instructions for 5.8.1 Manual genoa furler use and maintenance. Operation - Leave several turns of the furling line around the drum. - Furl/unfurl the genoa slowly so that the furling line is always under light tension thus avoiding any riding turns in the drum.
  • Page 40 5.8.2 Electric genoa furling system General points The electric genoa furler is supplied by direct current. A circuit-breaker protects the circuit. The control is located in the cockpit. It is comprised of the following elements: Relay box "Boxtron" Motor unit Location: Skipper's cabin Rigging and sails 146876...
  • Page 41 SAFETY Preventing man overboard situations and the means of getting someone back onboard ..............42 Storing the life-raft ................44 Securing moveable items ..............44 Deck Layout ..................45 Information about the risks of flooding and about the boat's stability 46 Emergency systems in case of steering gear failure....
  • Page 42 PREVENTING MAN OVERBOARD SITUATIONS AND THE MEANS OF GETTING SOMEONE BACK ONBOARD 6.1.1 Prevention of man overboard - The zones outside the working deck area are the hatched areas below - The "working deck" means those areas outside where people stand or walk during normal use of the boat. Ref 1: Fitting a means of climbing back onboard.
  • Page 43 6.1.2 Getting back onboard The means for getting back onboard must be able to be deployed by one person alone in the water, with no other help. - Some types of equipment for getting back onboard have a locking device when folded up: Installation of means to get back on board in the event of an accidental fall (Ref 1): It is important to keep the means for getting back onboard deployed and ready to use once the...
  • Page 44 STORING THE LIFE-RAFT Locker open Locker closed The life-raft(not supplied) must be stored in the space provided for it. A pictogram helps to locate it easily. Before putting to sea, carefully read the launching instructions shown on the liferaft. When at sea, never padlock or lock the stowage locker for the life-raft.
  • Page 45 DECK LAYOUT The maximum weight of the outboard engine on the pushpits must not exceed 20 kg. 1. Outboard engine (the outboard engine is not supplied). 2. Lifebuoy support bracket (the ring lifebuoy is not supplied). 146876 Index F...
  • Page 46 INFORMATION ABOUT THE RISKS OF FLOODING AND ABOUT THE BOAT'S STABILITY 6.5.1 Openings in hull Reference Designation Valve Vent hole - Fuel tank Black water tank Water tank vent Drainage - Deck hatch - Forward cabin Drainage - Deck hatch - Skipper's cabin Draining of manual bilge pump Electric bilge pump draining Washbasin draining - Head...
  • Page 47 OPTIONS Reference Designation Valve Black water tank (Version 3 cabins / 2 head compartments) Black water tank (Skipper's cabin) Drainage - Air conditioning - Condenser Drain - Water maker Black water tank (VacuFlush System) Vent hole - Auxiliary fuel tank / Extra water tank Drain scupper - Gangway Washing machine outlet...
  • Page 48 6.5.2 Drainage system General points - The inner moulding of the hull has channelling: the drainage channels. The drainage channels allow the water to drain down to the lowest point in the boat, where it can be discharged. So it is important to allow the water to flow freely down to this lowest point of the boat, which includes. - Regularly cleaning the lowest point of the boat and the drainage channels.
  • Page 49 Secondary drainage system Manual bilge pump Locker open Locker closed The manual bilge pump is in the cockpit (Ref 1). The bilge pump lever is located close to it (Ref 2). Operation: I- Put the lever on the manual bilge pump. II- Repeatedly work the lever up and down to its fullest extent.
  • Page 50 Main drainage system Electric bilge pumps - The bilge pumps are powered by DC. - Location of the electric bilge pumps: Ref 3. The switch for the electric bilge pump is located on the switch panel (Ref 4). Electric bilge pump Electric bilge pump (Sump) (Forward cabin)
  • Page 51 Bilge pump maintenance Please refer to the manufacturer's notes on the instructions for checking and maintaining the bilge pumps. - The drainage system is not designed to control water coming from breaches in the hull. - Keep the water level in the bilges to the minimum.
  • Page 52 DIAGRAM OF THE LAYOUT - DRYING OUT THE BILGE Pipe - Bilge pump system - Ø 20mm Pipe - Bilge pump system - Ø 25mm Reference Designation Intake strainer Electric bilge pump Manual bilge pump Non-return valve Bilge pump draining Safety 146876 Index F...
  • Page 53 EMERGENCY SYSTEMS IN CASE OF STEERING GEAR FAILURE Emergency tiller The emergency tiller is designed only to be able to continue underway at a reduced speed in case of steering gear failure. location of components Reference Designation Emergency tiller hole Emergency tiller Instructions in the event of steering gear failure I.
  • Page 55: Information Relating To Fire Risks And Risks Of Explosion

    INFORMATION RELATING TO FIRE RISKS AND RISKS OF EXPLOSION Propulsion engines and other fuel-burning equipment....56 Electrical system ................56 Gas system ..................56 Fire-prevention and fire-fighting equipment........56 Emergency exits in case of fire ............59 Extinguisher access hole ..............60...
  • Page 56: Electrical System

    7.1 PROPULSION ENGINES AND OTHER FUEL-BURNING EQUIPMENT The risks associated with motorisation are described in the MOTORISATION chapter. Note concerning the boat's tender: - If the tender is fitted with a more powerful outboard motor than 25 Kw, it must have on board a portable extinguisher with a rating equal to or greater than 8A / 68B. The risks associated with other fuel-burning equipment are described in the OTHER FUEL-BURNING EQUIPMENT chapter.
  • Page 57 Version 3 cabins / 2 Toilets Version 4 cabins / 2 Toilets Version 4 cabins / 4 Toilets Version 5 cabins / 3 Toilets Reference Minimum extinguishing capacity 5A / 34B 5A / 34B 5A / 34B 5A / 34B 5A / 34B 1 kg - When in use, this boat must be equipped wih a fire blanket to protect the cooking equipment and/or the galley, installed in the following place: near the cooking equipment.
  • Page 58 Maintenance of the fire-fighting equipment The owner/person operating the boat must: - Get the fire-fighting equipment checked at the frequency shown on the equipment; - Replace portable fire extinguishers, if outdated or discharged, by extinguishing apparatus of equal capacity; - Provide at least one fire bucket with a lanyard, in a readily accessible place, for protection on deck; - Get the fixed fire extinguishing systems filled or replaced if they are discharged or have expired.
  • Page 59 EMERGENCY EXITS IN CASE OF FIRE Think unlock the hatch (located in the front cabin) before using the boat. This should allow opening of the hatch by a person from the outside. NEVER: - Obstruct the passages leading to the emergency exits and the hatches;...
  • Page 60 EXTINGUISHER ACCESS HOLE The engine compartment has a port that makes it possible to inject the extinguishing product inside without opening the usual access hatches. In the event of the generator catching fire - Don't open it. - Please refer to the manufacturer's - Cut the supply (electrical and fuel) to the boat's engines, to the generator and to the ventilators.
  • Page 61 ELECTRICAL SYSTEM General information about the electrical system ......62 DC installation .................. 63 AC system ..................78...
  • Page 62 GENERAL INFORMATION ABOUT THE ELECTRICAL SYSTEM - The risks of fire or explosion may result from careless use of the DC and AC systems. - The risks of electrocution may result from careless use of the AC system. NEVER: - work on a live electrical system; - modify the elecrical system of the vessel or the relevant diagrams: It is important that the installation, maintenance and any modifications...
  • Page 63 DC INSTALLATION (12 V OR 24 V) 8.2.1 Battery use and distribution General points The boat is equipped with a direct current electrical system. The boat's electrical system comprises service batteries and the engine battery or batteries. The service batteries serve as the power supply for all the boat's electrical components.
  • Page 64 Maintenance - Avoid charging batteries to a voltage greater than 14,6 V. - All work carried out on a battery must only be carried out by someone qualified to do so. - Keep the batteries clean and dry. Whenever working on a battery, wear safety - Regularly check that the terminals and connection cables are clean.
  • Page 65 Maintenance of watertight batteries - This type of battery needs no maintenance and does not produce any gas during normal use. No ventilation is needed. - The optimum temperature for use is between 10 degree C and 30 degrees C. Lower temperatures will reduce the available capacity. Higher temperatures will increase the batteries' self-discharge rate.
  • Page 66 - Electrically controlled battery breakers: press the switches on the breaker control panel. In the event of electrical failure, it is possible to press down the button on top of the battery breaker manually to activate it. - Turn off all battery breakers before leaving The electrically-controlled battery breakers use very little electricity when they are on: It is imperative to turn off all the the vessel: risk of complete discharging of battery breakers during lengthy absences, to prevent the batteries from slowly and irreversibly discharging.
  • Page 67 8.2.3 Power distributor - The electronic charge dividers isolate the battery banks from each other and allow the charge to be directed automatically to the battery with the lowest charge. They give the advantage of preventing a drop in voltage. - The charge divider is electronic.
  • Page 68 8.2.4 Battery charger General points IT IS IMPERATIVE TO DISCONNECT THE BATTERY CHARGER BEFORE - The battery charger runs on AC power. DISCONNECTING THE BATTERY - A breaker protects the electrical circuit. TERMINALS FOR MAINTENANCE. - The battery charger charges all of the batteries onboard, while keeping the service battery bank isolated from the engine's battery bank.
  • Page 69 LAYOUT DIAGRAM - BATTERY CABLES 25mm² 70mm² 70mm² 25mm² 70mm² 125A 50mm² 35mm² 50mm² 25mm² 100 A 25mm² 70mm² 95mm² 95mm² 70mm² N D 1 2 N D 1 2 25mm² 35mm² 70mm² 35mm² 25mm² 95mm² 95mm² 35mm² 450A 95mm² 50mm²...
  • Page 70 8.2.5 Layout of the wiring looms in the hull - DC circuit Connexion Module Carré Cuisine BD AA6 AA7 AA11 AA12 Connexion Module batterie Connexion Module SDB AV BD Connexion Tâble Cokpit AA13 Connexion AA15 SDB AR TD AA14 AA16 Connexion Cabine AV PROP Connexion...
  • Page 71 8.2.6 Layout of the deck wiring looms - DC circuit L2C7 STE10 STE11 L5K10 L4K10 AN10 L6K10 L4H10 L2A10 L1A10 L1H10 L1C70 L1C7 L2K10 L3K10 L3W20 L1K10 L1C10 L3H10 L2H10 L1H10 L1K10 LE10 L2W20 L1C7 L2C10 L3C10 L4C10 L2C7 L1C9 L2C20 L3C20 L4C20 L2C9...
  • Page 72 8.2.7 Electrical panel Location: Saloon SAILING ENGINE FEUX DE NAVIGATION FEU DE PONT NAVIGATION LIGHTS DECK LIGHT CHARGEUR BATTERIES BATTERIES AND LEVELS BATTERY CHARGER MONITORING 12.6 FEU DE MOUILLAGE NAVIGATION MOORING LIGHT MAIN CHAUFFE EAU AC VOLTS POWER WATER HEATER ECL.TABLEAU GROUPE FROID PANEL LIGHT...
  • Page 73 References on Functions diagrams Multi-function display Push button - Volts Push button - Water Push button - Fuel Breaker "Deck light" Breaker "Navigation electronics" General circuit breaker "Interior lighting" Switch "Navigation lights" Switch "Mooring light" Switch "Auxiliary" Switch "Bilge pump" Switch "Water unit"...
  • Page 74 8.2.8 Circuit breakers A circuit-breaker can be re-set (manually press the black button to restart it). Reference Designation Location: Back of electrical panel Lighting Lighting Lighting Lighting 12 V socket Electric bilge pump Shower pump Shower pump Shower pump Hifi Gas solenoid (Version: US) Electric blind TV Antenna...
  • Page 75 8.2.9 Fuses - A fuse protects an electrical circuit from a power surge. If it blows, you must replace it with another fuse of the same When replacing fuses/circuit-breakers, always rating. ensure replacements are of the right capacity (see the colour-codes) Location: Back of electrical panel.
  • Page 76 8.2.10 Relay board Location: Port aft cabin Reference Designation Engine compartment ventilator Windlass Bow thruster Fridge 2 Fridge 3 DC installation 146876 Index F...
  • Page 77 8.2.11 Layout diagram - DC circuit 220 Volts / 50Hz +BPE21 +BPE22 +BPE21 -PE1 +PE1 +BPE2 -BPE22 +PE2 -BPE2 +PE21 146876 Index F...
  • Page 78 AC SYSTEM (110 V OR 220 V) - Never let the end of the boat/shore supply cable hang in the water: The result may be an electric field 8.3.1 General points liable to hurt or kill the swimmers nearby. - The boat is equipped with an alternating current electrical system. - There may be danger of electrocution if alternating current systems are incorrectly used.
  • Page 79 8.3.2 AC shore socket location of components 3. Generator 4. DC/AC converter 5. AC breakers AC shore socket Bipolar circuit breaker Differential circuit breaker Ref 1 Ref 2 Ref 2 1. Shore 2. Generator 3. Air conditioning 146876 Index F...
  • Page 80 8.3.3 Layout diagram AC ELECTRICAL SYSTEM SHORE / QUAI 1000W GENERATOR 078378 220 Volts / 50Hz PO WE R 065902 PQCL1 REVE RSE PO LA RI TY 6mm² 077555 3X2.5² 066176 220 Volts / 50Hz PQCL3 220 Volts / 50Hz 3X2.5²...
  • Page 81 8.3.4 Transformer - 220V / 115V (US version) The transformer allows the current to be transformed from 220V to 115V to supply the sockets for the electrical domestic Refer to the manufacturer's instructions for equipment. use and maintenance. The other on-board AC equipment operates on 220V (Air conditioning, Battery chargers, Water heater). The transformer operates completely automatically.
  • Page 82 AC breakers Location: Back of electrical panel AC ELEMENTS Reference Designation DC/AC converter 230AC 12DC Water maker Ice maker Dishwasher C 16 C 16 C 16 C 16 C 25 C 10 Washer Dryer AC system 146876 Index F...
  • Page 83 8.3.5 DC/AC converter Description - The inverter converts the DC voltage of the service battery bank to AC voltage. The circuit between the inverter and the batteries is protected by a fuse or a circuit-breaker. - The inverter is earthed by an earthing plate located under the hull (see earthing plate chapter). Operation Power supply for the AC electric sockets 220 V in the cabins: Once there is sufficient nominal voltage coming from the AC switch panel, AC power is supplied by the socket onshore or by the generator.
  • Page 84 Maintenance - Check at least once a year that the inverter cables and connections are properly bundled. The power to the inverter must only be supplied by lead batteries. - Clean the inverter by removing any accumulated dust to ensure good ventilation. Refer to the manufacturer's instructions for The control located on the equipment Remote control (Chart table)
  • Page 85 Layout diagram - DC/AC converter 10.4V 12.5 BORD ECLAIRAGE INT. GRO UPE FROID ELECT. NAVIG ATION CABIN LIGHTS FRIDG E UNIT NAV. INSTRUMENTS AUXILIAIRE ECLAIRAG E PONT AUXILARY DECK FLO ODLIGHT CHAUFFE-EAU CHARG EUR BATTERIE GRO UPE D'EAU FEU DE MOUILLAGE WATER HEATER BATTERY CHARG ER W ATER...
  • Page 86 8.3.6 Installation of hull AC wiring loom PAC50 PAC30 PTV2 CH1 CH2 PAC10 PAC20 PAC40 PQ11 PQ10 PAC60 PQ12 PQ11 PQ10 PQ12 AC system 146876 Index F...
  • Page 87 8.3.7 Anodes General points - Never cover the anodes in antifoul. - The sacrificial anodes protect the boat's metal components from electrolysis. - During the first few weeks that the boat is in the water, check the anodes and if necessary - A sacrificial anode is a consumable part that protects submerged metal parts by its dissolution (oxidation).
  • Page 88 8.3.8 Earthing plates - An earthing plate is a shot-peened plate mounted on the hull to recreate an earth neutral point on the electrical circuit - Never antifoul over the earthing plates. of the equipment supplying AC power (generator and DC/AC converter). The earthing plate earths this equipment. The earthing plate is not an anode: it must not be allowed to deteriorate.
  • Page 89: Liquefied Petroleum Gas(Lpg)System (Lpg)

    LIQUEFIED PETROLEUM GAS(LPG)SYSTEM (LPG) The onboard gas system ..............90 Layout diagram................. 93...
  • Page 90 THE ONBOARD GAS SYSTEM location of components Reference Designation Gas cylinder locker Kitchen sink evacuation through-hull Gas locker drain Gas system Supply valve - Gas Gas cylinder locker Cooker Supply valve - Gas Locker closed / Locker open - Systematically store the gas bottles only in the lockers or storage places provided for these. - It is recommended that you ensure good ventilation when using gas powered equipment, to prevent asphyxiation.
  • Page 91 Use and maintenance of the installation - Please refer to the manufacturer's notes for the use and maintenance of the LPG cooker. - When the equipment is not in use close the taps on the LPG hose and on the gas bottles. Close the taps before changing the bottles and immediately in an emergency. - Make sure that the taps on the equipment are closed before opening the one on the bottle.
  • Page 92 To change an LPG bottle 1. Close the tap on the LPG bottle When the cooker is on, ventilate well to prevent any risk of asphyxiation. 2. Detach the LPG bottle Do not use the cooker as a means of heating. 3.
  • Page 93 LAYOUT DIAGRAM Version: Europe Reference Designation Regulator valve Gas cylinder Drain Connection kit - gas bottle Rubber washers Pictogram Connection kit - gas copper PVC girdled sleeve Gas appliance connection kit Version: US Reference Designation Regulator valve 12 V Gas cylinder Drain Stuffing box PVC girdled sleeve...
  • Page 95 DOMESTIC APPLIANCES Fridge....................96 Water-cooled refrigeration unit ............98 Microwave ..................100 Extractor hood ................101 Washer..................... 102 Dishwasher ..................103...
  • Page 96 10.1 FRIDGE General points - Refer to the manufacturer's instructions for use and maintenance. - The fridge is composed of 3 components: the compressor, the evaporator and the condenser. These components are connected by a closed circuit refrigerant gas circuit. The fridge is air-cooled. - Never heat or use tools to defrost the inside of the fridge more quickly (risk of damaging the - The fridge is DC powered.
  • Page 97 Fridge / Control Capacity: 130 litre Cooler / Thermostat Refrigeration unit for icebox Capacity: 100 litre Location: Galley 146876 Index F...
  • Page 98 10.2 WATER-COOLED REFRIGERATION UNIT General points - Refer to the manufacturer's instructions for use and maintenance. The fridge is composed of 3 components: the compressor, the evaporator and the condenser. These components are connected by a closed circuit refrigerant gas circuit. The refrigerator is water-cooled. - Never cover the condenser with antifouling paint.
  • Page 99 Maintenance Clean the refrigeration unit annually using a vacuum cleaner or a dry brush. 1. Condenser (submerged) 2. Evaporator 3. Compressor 4. Battery Condenser (Microbead plate) Refrigeration unit 146876 Index F...
  • Page 100 10.3 MICROWAVE General points - The microwave is AC powered. - A breaker protects the electrical circuit. - The microwave is designed to reheat food and drink or to cook food. Any other use is dangerous and forbidden. - The microwave must never be started when empty. - Remove all foil or metallic elements of the packaging before putting food in the microwave.
  • Page 101 10.4 EXTRACTOR HOOD General points Never allow children to use the domestic electrical equipment unsupervised. - The cooker hood runs on an AC power supply. - A breaker protects the electrical circuit. Refer to the manufacturer's instructions for Starting up use and maintenance.
  • Page 102 10.5 WASHER General points Refer to the manufacturer's instructions for use and maintenance. - The washing machine runs on an AC power supply. - A breaker protects the electrical circuit. - The washing machine is supplied with water from the onboard tanks via a supply valve. - Washing machine outlet: Thru-hull fitting.
  • Page 103 10.6 DISHWASHER General points - Refer to the manufacturer's instructions for use and maintenance. - The dishwasher is AC powered. - Do not use the dishwasher when underway. - A breaker protects the electrical circuit. - The dishwasher takes the water from the tanks onboard via a water feed valve. - Dishwasher drainage: located under the sink.
  • Page 105 11 11 AUDIO-VISUAL EQUIPMENT Television ..................106 Hifi....................107 Layout diagram................108...
  • Page 106 11.1 TELEVISION General points - The television is powered by AC provided by the DC/AC invertor which is powered by the service batteries. The inverter has an ON / OFF button. - A circuit-breaker protects the circuit. - Pre-cabling for the aerial is already installed on the boat. Starting up - First turn on the circuit breaker, then switch on the TV.
  • Page 107 11.2 HIFI - The sound system is DC powered. Refer to the manufacturer's instructions for use and maintenance. - The sound from the TV or from the DVD player is amplified by the boom box and the speakers. - The sound from the TV comes out of the integral speakers. - The sound from the TV can come from the speakers if AUX is selected on the DVD player.
  • Page 108 11.3 LAYOUT DIAGRAM Reference Designation Loudspeaker Base box (Bass speaker) Television Scart plug Audio/video cable Player DVD DVD remote control Audio cable Electronic radio aerial Up/down switch TV mechanism Waterproof remote control Waterproof loudspeaker Saloon Exterior Audio-visual equipment 146876 Index F...
  • Page 109 ONBOARD COMFORT Chilled water air conditioning ............110 Electronic equipment ..............120 Equipment other than for propulsion, which burns fuel ......123...
  • Page 110 11.4 CHILLED WATER AIR CONDITIONING General points - The air-conditioning is powered by alternating current. - The air-conditioning cools the air temperature inside the boat (only when the boat is floating in water). - The cooling circuit consists of one or more compressors that operate independently. A compressor is called "reversible" because it can heat the boat if the sea water temperature exceeds 10°C.
  • Page 111 Winter Storage: - Protection of sea water system: drain the whole sea water system. - Refer to the manufacturer's instructions for use and maintenance. - Protection of the chilled water system: The chilled water in the air conditioning piping is made up of a mixture of water and glycol at a level of 15%.
  • Page 112 Manual control of the air-conditioning NOTES 1. Data display - When the system is programmed in Screen which displays the desired temperature, the programmed values and the error messages. dehumidifying mode, the system's safety 2. MODE devices remain active: if there is an interruption Enables you to navigate between the different operating modes.
  • Page 113 OCKING METHOD - It is possible to lock the control buttons to avoid any accidental handling: Press the three buttons at once: MODE, UP (arrow pointing up), FAN. LC appears on the screen, which signifies "LOCK". - To unlock and resume use of the buttons, press the three buttons at the same time: MODE, UP (arrow pointing up), FAN. UL appears on the screen, which signifies "UNLOCK".
  • Page 114 Circuit breakers - Air conditioning Location: Chart table Reference Designation General Pump sea water Compressor C 20 C 6 C 6 C 6 C 6 Compressor Compressor Compressor Compressor Onboard comfort 146876 Index F...
  • Page 115 Draining the chilled water system - The first time you switch on the air-condtioning: Run the air-conditioning in full operating mode for about ten hours then - Refer to the manufacturer's instructions for drain the chilled water system (please consult your dealer). use and maintenance.
  • Page 116 LAYOUT - CHILLED WATER AIR CONDITIONING Reference Designation Fan-convector Cooling unit Seawater discharge Pump sea water Filter Seawater supply valve Thru-hull fitting Insulated pipes Chilled water pump System cut-off valve Onboard comfort 146876 Index F...
  • Page 117 DIAGRAM OF THE LAYOUT - AIR CONDITIONING Version 3 cabins / 2 head compartments Reference Designation Fan-convector Grid Cooling unit Chilled water pump Sea water intake Pump sea water Condensation drain 146876 Index F...
  • Page 118 Version 4 cabins / 4 head compartments Reference Designation Fan-convector Grid Cooling unit Chilled water pump Sea water intake Pump sea water Condensation drain Onboard comfort 146876 Index F...
  • Page 119 Version 4 cabins / 2 head compartments Reference Designation Fan-convector Grid Cooling unit Chilled water pump Sea water intake Pump sea water Condensation drain 146876 Index F...
  • Page 120 11.5 ELECTRONIC EQUIPMENT The onboard electronics are powered by direct current. LEAD LINES Transducer location - Do not store material on top of the sensors. - Do not cover the sensors in antifoul when antifouling the hull. - Regularly clean the sensors. Auto pilot - To ensure optimum perfomance, keep all metallic objects away from the gyrocompass.
  • Page 121 - Place the protective covers on the repeaters Location of the aerial: Starboard cockpit when unused for long periods. - When sailing store the protective covers inside the boat to avoid losing them. - The various repeater displays are back-lit. - Regularly clean the fascias of the repeaters with fresh water.
  • Page 122 LAYOUT DIAGRAM - ELECTRONIC PARTS NSS8 NSS8 NSS8 NSS8 12/24V 12/24V 12/24V 12/24V 139820 128311-4m 4,50m 128311-4m 139820 Photo4 4,50m 128311-4m 128312-5m 128311 139820-4,50m 139820-4,50m 139820-4,50m 136849-2m 136850-15m NEP2 WiFi Module Sonic Hub 136849 136849 NAIS&SPLITTER VHF Broadband Radar 12/24V 12/24V RS12 136849...
  • Page 123 11.6 EQUIPMENT OTHER THAN FOR PROPULSION, WHICH BURNS FUEL (GENERATOR, HEATING) 11.6.1 General points - Make sure that the ventilation openings in the engine (and generator, if installed) compartment are well cleared. - Stop the engine and refrain from smoking during fuel tank filling. - Get your fuel circuit checked regularly by a professional engineer.
  • Page 124 11.6.2 Generator LAYOUT DIAGRAM Onboard comfort 146876 Index F...
  • Page 125 General points - The generator is a machine which can produce AC electrical power using mechanical power (fuel). The generator will fed the onboard equipment operating at 220V or 110V, moored or sailing. - The generator starts with its own battery (12 V circuit). - Make sure that there is enough fuel in the fuel tank before using the generator.
  • Page 126 In the event of the generator catching fire - Don't open it. - Please refer to the manufacturer's instructions for using the generator. - Cut the supply (electrical and fuel) to the boat's engines, to the generator and to the ventilators. - Never start the generator when the climate - Use the extinguisher access port on the generator to discharge the contents of the portable extinguisher.
  • Page 127 LAYOUT OF COMPONENTS Battery charger - 25A Battery switch Remote control Anti-siphon valve Location: Port aft cabin Location: Port aft cabin Location: Chart table Location: Port aft cabin (see the chapter on Electricity: Battery (see the chapter on Electricity: Battery charger) switch) Access: Port aft locker...
  • Page 128 11.6.3 Water heating The water pump and the diesel pump are built into the heater. The cabins and saloon are fitted with heating units to which - Please refer to the manufacturer's the water piping is connected. instructions for the use and maintenance of the heating system.
  • Page 129 Control Easystart - The water heating operates on direct current. - Please refer to the manufacturer's instructions for the use and maintenance of the - The Easystart timer serves to turn the heater on and off, as well as to choose its operating time, the length of time and heating system.
  • Page 130: Onboard Comfort 12

    Control Heating unit & Thermostat 1. Heating unit 2. Supply valve - hot water (This valve allows you to isolate a faulty circuit) Fuses Heater Fuel spur: Access: Chart table - Heating unit x5 Access: Starboard cockpit locker Starboard tank Heater Onboard comfort 146876...
  • Page 131 WATER SYSTEMS General points ................132 Using a valve................... 133 Fresh water filling system ............. 134 Fresh water distribution system ........... 136 Main plumbing equipment ............. 139 Black water system (WC)............... 148 Waste water system ............... 161...
  • Page 132 13.1 GENERAL POINTS - It is essential to rinse the entire on-board water system the first time the boat is used (The water system is protected in - Regularly check water-tightness of joints in the factory by a dietary anti-freeze). the water system installations.
  • Page 133 13.2 USING A VALVE The valve is shut when the valve handle is at right angles to the pipe, the valve is open when the valve handle is in line - Valves have a lifespan of approximately 5 with the pipe. years.
  • Page 134 13.3 FRESH WATER FILLING SYSTEM All versions Supply pipe - Ø 19mm Pipe - Vent hole - Ø 16mm Pipe filling - Ø 38mm Reference Designation Deck filler Fresh water tank - 325 litre Fresh water tank - 330 litre Tank vent Water unit Water systems...
  • Page 135 Relationship between the tank number, its position and the gauge (on the Water tank electrical panel) Tank no.1: Forward tank Forward tank: Tank - Saloon (Starboard): Tank no.2: Tank - Saloon (Starboard) 330 litre 324 litre Tank no.3: Extra tank (Port side) Water tank direction valves Location: Starboard saloon 1.
  • Page 136 13.4 FRESH WATER DISTRIBUTION SYSTEM Version 3 cabins / 2 head compartments Pipe - cold water - Ø 19mm Pipe - hot water - Ø 19mm Pipe - cold water - Ø 12mm Pipe - hot water - Ø 12mm Reference Designation Water unit...
  • Page 137 Fresh water distribution system (Options) Pipe - Fresh water - Ø 19mm Pipe - Fresh water - Ø 12mm Pipe - hot water - Ø 12mm Pipe - Sea water - Ø 16mm Pipe filling - Ø 38mm Pipe - Vent hole - Ø 16mm 146876 Index F...
  • Page 138 Reference Designation Thru-hull fitting - Intake - with valve Carbon filter Sink mixer tap Valve - Spout Selection valve - 3 way Foot pump Water unit Fresh water tank - 325 litre Tank vent Deck filler Electric pump Connector - deck washer Fresh water shore supply Sea water filter Motor unit - Water maker...
  • Page 139 13.5 MAIN PLUMBING EQUIPMENT 13.5.1 Water unit - The water unit is supplied by direct current. - It serves to feed all the boat's plumbing equipment with fresh water. It is fitted with a pressure switch that activates the flow when the pressure in the water system falls. - The water unit must only be used with the fresh water supply.
  • Page 140 13.5.2 Cockpit shower - The cockpit shower allows the use of fresh water for rinsing off. - The shower is fitted with a mixer tap. - The tap has a dual function: - It allows the water to be turned on/off, - It allows a choice of water temperature (hot water / Cold water).
  • Page 141 13.5.3 Deck wash pump (Sea water) - The deck wash pump is supplied by direct current. - The deck wash pump allows the deck or the boat's tender to be washed. - The deck wash pump is switched on at the electric panel. Operation - Open the sea water intake valve.
  • Page 142 13.5.5 Sea water/fresh water foot pump - The foot pump allows the use of sea water/fresh water without needing electricity. - Siting of the sea water/fresh water selector valve: Under the sink. - Water from the foot pump comes out at the spout located at the sink. Spout Control - Foot pump Sea water intake / Access...
  • Page 143 13.5.6 Water heater - The water heater allows the use of hot water on board the boat. - The water heater operates by heat recovery from the engine cooling circuit or the on board AC electrical supply. - The water heater thermostat regulates the water temperature only when it is operating with electrical resistance. The thermostat is pre-set in the factory. - The mixer tap allows the temperature leaving the water heater to be adjusted.
  • Page 144 13.5.7 Ice maker (Ice maker) General points - Refer to the manufacturer's instructions for use and maintenance. - The ice maker provides a supply of ice from the onboard water system. - The ice maker runs on the AC power supply. - Never heat or use tools to defrost the inside of the fridge more quickly.
  • Page 145 13.5.8 Water maker General points - The watermaker allows fresh water to be produced from the sea water. - The watermaker can be supplied either: - by DC direct current, - by AC alternating current. - A circuit-breaker protects the circuit. - Several elements make up the watermaker circuit: - sea water intake, - sea water filter(s),...
  • Page 146 Operation - Before starting the watermaker circuit, check that the supply and discharge valves are open. - Using the watermaker with DC supply needs a lot from the battery bank: make sure to recharge them regularly by running the boat's engine. - The different quality and salinity of the sea water used affect the production of fresh water;...
  • Page 147 Layout of components: Starboard saloon Control panel Membrane unit Motor unit (Ref 3) (Ref 5) (Ref 6) Sea water intake (Ref 8) 1. Seawater supply valve 2. Sea water filter (Ref 10) 146876 Index F...
  • Page 148 13.6 BLACK WATER SYSTEM (WC) General points - Black water is human waste including the flushing water from the toilets. - Close the valves after each use and above all when the boat is unattended. - Regularly check the valves and thru-hull seacocks for proper operation and watertightness. - Regularly check the tightness of the flexible pipe clamps and connections.
  • Page 149 13.6.1 Location diagram of black water system Version 3 cabins / 2 head compartments Pipe - Waste water - Ø 20mm Pipe - Sea water - Ø 16mm Pipe - Sewage - Ø 38mm Pipe - Sewage - Ø 50mm Reference Designation WC evacuation - Deck...
  • Page 150 Location diagram of black water system (Skipper's cabin) Pipe - Waste water - Ø 20mm Pipe - Sea water - Ø 16mm Pipe - Sewage - Ø 38mm Pipe - Sewage - Ø 50mm Reference Designation WC evacuation - Deck Tank vent WC evacuation to sea Sewage tank - 50 litre...
  • Page 151 YOUR BOAT IS FITTED WITH A BLACK WATER TANK To minimise the smells coming from this tank, we advise the following use and maintenance: Holding tank - A black water tank is used solely for the temporary collection of water coming from the toilets. - The tank can be emptied in 2 ways: - By connection to a pumping system that empties the tank by suction.
  • Page 152 Maintenance of black water tank - The risk of unpleasant odours forming increases when the waste water remains in the tank for a long time. - Never use automobile anti-freeze in the black water system: risk of poisoning. - Whenever possible empty the tank regularly even before it is full. - Every time the tank is emptied put in about 5 litres of fresh water and add an appropriate detergent additive (available from chandleries).
  • Page 153 Layout diagram of black water system Emptying by gravity (Skipper's cabin) Reference Designation Seawater intake valve Thru-hull seacock Black water tank Vent hole "WASTE" deck connection 146876 Index F...
  • Page 154 Using a marine toilet fitted with a tank emptied by gravity I. Open the sea water intake valve (Ref 2). Refer to the manufacturer's instructions for use and maintenance. II. Fill the bowl by using the manual toilet pump. III. Using the toilet (Ref 1). IV.a.
  • Page 155 VacuFlush System (pressurised black water system) - Refer to the manufacturer's instructions for use and maintenance. - Check that the seat of each toilet is properly closed to allow the pressurised black water system to operate. - Use rapidly dissolving toilet paper. (To determine the dissolving capacity of a toilet paper, immerse a square of the paper in a container and shake between 5 and 10 times.
  • Page 156 Reference Designation Inlet pipe for faecal matter Tank drainage hose Drainage system isolation valve (shown here in the 'open' position) Tank vent hole Vacuum pump Drainage pump electrical circuit Black water tank Gauge transmitter Safety relay (allows the electrical supply to be cut off when the tank is full) G H I Water systems...
  • Page 157 LAYOUT OF COMPONENTS WC evacuation to sea Valve in closed position: The Boat's fresh water supply tap drainage pump can operate. The (located behind the pedal) WCs are operational. 146876 Index F...
  • Page 158 General points - The electric toilets work off the house water system. - The WCs are supplied by direct current. - The valve located on top of the tank (the drainage system isolation valve) must be closed to enable the WCs to be operated. When the valve is in the open position, it allows the black water tank to be emptied, either through the deck fitting, or through the drainage pump (WC evacuation to sea).
  • Page 159 Gauge - When the tank is full (red indicator lamp lit on the gauge indicator), a relay located near the tank cuts off the electrical supply to the system. That prevents the use of the toilets. The tank must be emptied so that the WCs may be operated again. Black water tank gauge &...
  • Page 160 Diagram of the layout - VacuFlush System Version 3 cabins / 2 head compartments Pipe - Waste water - Ø 20mm Pipe - Sea water - Ø 16mm Pipe - Sewage - Ø 38mm Pipe - Sewage - Ø 50mm Reference Designation WC evacuation - Deck...
  • Page 161 13.7 WASTE WATER SYSTEM General points - Observe local regulations regarding the emptying of grey water tanks. - The waste water system is the water coming from the sink, showers, air conditioning drains and washbasins. All this water is collected in the grey water tank, drained via a discharge pump controlled by a float switch. - Close the valves after each use and above all when the boat is unattended.
  • Page 162 Layout diagram waste water Pipe - Waste water - Ø 20mm Pipe - Waste water - Ø 25mm Pipe - Waste water - Ø 40mm Reference Designation Sink plug hole Pump discharge - Cooler Drain plug - Cooler Icebox drainage Washbasin drain plug Shower plug hole Water systems...
  • Page 163 Layout of components: HOWER Draining pump for shower + Shower plug hole The shower pump control Delay relay OOLER Control - Icebox drainage 146876 Index F...
  • Page 165 ENGINE Information about the risks of fire and of explosion of engines... 166 Danger from moving mechanical parts ........... 167 General points..................167 Starting the engine................169 Engine water intake valve ..............170 Anti-siphon valve ................. 175 Fuel filter ....................176 Engine installation ................
  • Page 166 14.1 INFORMATION ABOUT THE RISKS OF FIRE AND OF EXPLOSION OF ENGINES - Make sure that the coolant is circulating properly. - Ensure that the engine compartment ventilation air inlets are kept clear. - Stop the engine and refrain from smoking during fuel tank filling. - Get your fuel circuit checked regularly by a professional engineer.
  • Page 167 14.2 DANGER FROM MOVING MECHANICAL PARTS - Keep away from the moving parts of the engine (belts and moving parts or hot components) and the drive shafts etc.. - Regularly check that the O ring on the filler cap is in good condition, to prevent any water - Be careful if you have long hair, bulky clothing, rings etc (at risk of being caught).
  • Page 168 Gauge - The fuel level is transmitted from the dipstick to the indicator located on the electrical panel. - Some of the gauges must be calibrated when you first fill the tanks: please consult your dealer. Deck filler Gauge Tank no.1: Port tank Electrical panel (Refer to the instructions for use) Tank no.2: Starboard tank...
  • Page 169 14.4 STARTING THE ENGINE Before starting the engine, it is imperative: - Before using the engine, make sure you carefully read the handbook provided by the - to open the fuel supply valve; engine manufacturer. - to open the sea water intake valve of the engine; - to switch on the battery supply by using the battery isolator switches;...
  • Page 170 14.5 ENGINE WATER INTAKE VALVE The sea water intake valve plays a crucial role in ensuring that the engine runs well. - Keep the strainer under the hull as clean as possible; - Brush the strainer whenever the boat is lifted out; - Don't cover the strainer in antifoul.
  • Page 171 DIAGRAM OF THE LAYOUT 146876 Index F...
  • Page 172 Engine 146876 Index F...
  • Page 173 Detail B 146876 Index F...
  • Page 174 Reference Designation Anti-siphon valve Sea water filter Expansion tank Fuel filter Engine battery Battery switch Water trap Outlet Engine control lever Ventilator Fuel tank Fuel tank Engine instrument panel Motor Sail Drive Fuel filler Vent hole - Fuel tank Fresh air inlet Extinguisher access hole Fresh air inlet Hot air outlet...
  • Page 175 14.6 ANTI-SIPHON VALVE - The function of the anti-siphon valve is to inhibit the siphoning action when the engine stops thus preventing a return of water. - It is possible that on starting the engine or at certain engine speeds some drops of water may be seen escaping from the anti-siphon valve. If so you need to clean the anti-siphon valve: dismantle the water collector at the top of the anti-siphon valve, then clean the valve with fresh water to remove any impurities.
  • Page 176 14.7 FUEL FILTER Engine running problems may have different origins, including dirty fuel. The injection pump may wear out if there is water in the system. The water results either from the condensation resulting from an insufficiently filled tank, or from a filler cap either not closed properly or with a damaged seal. In order to prevent any water infiltration, the fuel runs through two filters: - One filter is an integral part of the engine, its role is to filter fuel very finely.
  • Page 177 14.8 ENGINE INSTALLATION Sail Drive engine installation 14.9 ENGINE CONTROL - The engine manufacturer's notes provide detailed explanations on how to operate the engine and keep it running well. - Read the manufacturer's notes on use and maintenance of the engine. Location: Starboard cockpit.
  • Page 178 14.10 ACCESS TO THE ENGINE The access to the engine is via: - Side hatches, - the companionway. All access hatches to the engine absolutely must be kept shut when at sea. Engine 146876 Index F...
  • Page 179 14.11 DIESEL TRANSFER PUMP - The transfer pump allows fuel to pass from one tank to the other. - The boat's engine is supplied by the aft tank. When it is empty, a pump allows the transfer of fuel from the forward tank to the aft tank. The switch located on the pump must be permanently in the ON position: the pump control is located separately.
  • Page 180 14.12 PROPELLER - The propeller delivered with the boat represents the end result of trials carried out in collaboration with the engine - Respect speed limits. manufacturer. Never change the propeller without first consulting a professional engineer. - If this boat is equipped with a fixed blade - Propeller efficiency will drop if the propeller blades are damaged in any way or dirty: regularly clean the blades carefully.
  • Page 181 14.13 DOCK & GO VERSION General points It is imperative to change the transmission oil after the 250 first hours of use (please - The Dock & Go transmission is an electronically controlled mechanical transmission. consult your dealer). - This type of transmission operates without a reverse gear, reversing is achieved by rotating the POD 180 degrees. - The Dock and Go system is powered by the service batteries circuit onboard: the battery bank must be sufficiently charged to enable the system to run well.
  • Page 182 14.13.1 Start Quick Guide Start the engine using the control lever Start the engine, using the joystick to move sideways (Dock & Go) (forward and reverse) Turn on all battery switches. Turn on all battery switches. Turn on power to the navigation electronics at the electrical Start the engine.
  • Page 183 14.13.2 Diagrammatic view Reference Designation Heat engine POD rotary motor: Make the POD under the waterline turn 270 to starboard Clutch actuator: enables gear engagement and disengagement Clutch: Mechanical linkage between the engine and the propeller shaft TCU: (Transmission and Clutch Management) interface between the clutch activator and the VMU VMU (Vessel Management Unit): the brains of the system, it gathers all the info from the system(joystick, control lever, TCU,...
  • Page 184 LAYOUT OF COMPONENTS Rotating motor Clutch actuator (Ref 2) (Ref 3) TCU housing (Transmission and Clutch Management) VMU housing (Vessel Management Unit) Throttle actuator (Ref 5) (Ref 6) (Ref 7) Engine 146876 Index F...
  • Page 185 LAYOUT Bow Thruster (no ZF) RPM sensor Autopilot (no ZF) Power RPM sensor adapter Angular steering sensor Throttle acuator Main Harness VMU Throttle cable X10 (only ZF) Joystick X6 - CAN In Harness V.M.U. Termination resistor Side Mounting Control head harness Control head Steering electrical safety connector...
  • Page 186 14.18.2 Operation 1. General points - The Dock and Go system is a manoeuvring aid to facilitate coming alongside and leaving the dock. This system must not in any circumstances be used as a means of navigation, even during approach manoeuvres in port. - In some use modes of the system, especially sideways movement, the bow thruster has to work very hard.
  • Page 187 3. Operation - Turn on all battery switches. The bow thruster battery master switches will turn on automatically when the bow thruster control is picked up. - Open the fuel supply valve(s) from the fuel tank(s). - Open the engine water inlet valve. - Switch on the navigation electronics (Electrical panel).
  • Page 188 4. Joystick operation REMINDER: Before using the system, ensure that the bow thruster light is illuminated (see above) once the boat's engine If you activate the joystick while the rudder is startedCheck that the bow thruster indicator light is showing steady green when the joystick is in operation. blade is not in the same position as the boat's axis, it will automatically move itself to the correct position.
  • Page 189 USING THE JOYSTICK Push the joystick forwards: - The boat moves forwards. - The acceleration is proportional to the position of the joystick. Push the joystick back: - The boat moves backwards. - The acceleration is proportional to the position of the joystick. Push the joystick to port: - The boat moves to port.
  • Page 190 The effects of the Dock & Go system's rotation will be noticeable to a greater or lesser extent depending on the boat's way. Several movements can be combined Push the joystick to starboard + Turn the joystick clockwise: - The boat moves to starboard but the bow swings more quickly than the stern. Push the joystick to starboard + Turn the joystick anti-clockwise: - The boat moves to starboard but the stern swings more quickly than the bow.
  • Page 191 Turn the joystick anti-clockwise: - The boat turns to port (virtually pivoting around its keel). Forward or reverse acceleration is proportional to the position of the joystick. Turn the joystick clockwise: - The boat turns to starboard (virtually pivoting around its keel). Forward or reverse acceleration is proportional to the position of the joystick. Push the joystick forwards + turn clockwise: - The boat moves forward and turns to starboard.
  • Page 192 QUIT JOYSTICK MODE To retake control with the engine control lever, it is essential to disengage the joystick by pressing the button behind the joystick. Press the button for 1 second. - RAYMARINE version: The auto pilot comes out of "MOTORISED HELM" mode and goes into "STAND-BY"...
  • Page 193 5. MODE "WARM UP" (warming up the engine) - "WARM UP" mode is a mode in which the engine is disengaged and accelerated. - To engage the "WARM UP" position, press the button and keep it pressed whilst moving the throttle to the first forward notch, then release the button. "WARM UP" is only possible in forward gear.
  • Page 194 7. Maintenance Check engine oil level: - The level must be between the 2 marks on the gauge (see engine manual). Check POD base oil level: - The level must be taken by inserting the dipstick in the hole (without screwing it down). - The level must be between the 2 marks on the gauge (see ZF manual).
  • Page 195 8. Dock & Go circuit protection Lighted safety fuses Reference Designation Motor supply 40A Supply VHS 1 after engine contact Supply VHS 2 after engine contact VMU power supply VMU VMU power supply TCU 1 VMU power supply TCU 2 Supply VMU after engine contact Supply TCU after engine contact Supply pod after engine contact...
  • Page 197 STEERING SYSTEM General points ................198 Layout diagram................199 Bow thruster ................... 204...
  • Page 198 15.1 GENERAL POINTS - The steering operates by steering cables. - The steering system is an important safety feature. For this reason, the annual inspection of the whole system must be carried out by a professional engineer. - Regularly check the tension of the steering cables and the tightness of the steering components. If need be, adjust the tension of the steering cables. Don't tighten the steering cables excessively.
  • Page 199 15.2 LAYOUT DIAGRAM 146876 Index F...
  • Page 200 Steering system 146876 Index F...
  • Page 201 146876 Index F...
  • Page 202 Steering system 146876 Index F...
  • Page 203 Reference Designation Rudder Rudder stock Steering wheel Steering Gear + brake Steering Gear Chain Sheave Line Steering sector Set - Sector support Sector support Stock arm (Single) Sector axle Stock arm (double) Flanged bush Stock arm stop Stock arm - Port side Stock arm - Starboard Backing plate Connecting rod...
  • Page 204 15.3 BOW THRUSTER General points - The bow-thruster's motor is DC powered. - The bow-thruster assists with steering the boat when manoeuvering at low speed (picking up a mooring buoy or berthing on a pontoon for instance). - An operating relay is installed in the circuit. - A fuse protects the electrical circuit.
  • Page 205 During lift-out - Check that the propellers turn properly, with neither play nor stiffness. - Refer to the manufacturer's instructions for use and maintenance. - Clean the blades carefully. - Never run the motor when the propeller is - Remove the propeller, clean the shaft support, smear the shaft with silicone-based grease before refitting the propeller. out of the water.
  • Page 206 Layout diagram - Bow thruster PE4A - gr1 PE3 - n2.5² PE5 - mar2.5² PE2 - or2.5² PE5 - or2.5² PE1 - r35² SORTIE REPATITEUR DE CHARGE PE12 r 95² PE11 - r95² BPE11 - r95² BPE11 - n 95² iv 95²...
  • Page 207 DECK FITTINGS General points ................208 Equipment ..................211 Berthing, anchoring, towing............216 Main elements of the chain locker ..........218 Electric windlass ................219...
  • Page 208 16.1 GENERAL POINTS 16.1.1 Polyester - Regularly brush the deck using a gentle de-greasing agent then rinse the deck with fresh water. - Use as few cleaning agents as possible. - Don't use solvents or aggressive detergent agents. - Don't discharge cleaning agents into the water: Consult the harbourmaster's office to find out the conditions of water use and the maintenance area for cleaning your vessel.
  • Page 209 16.1.4 Solid wood on exterior wooden panelling - Wood exposed to harsh conditions, such as salty air and UV rays tends to become whiter and to lose its natural colour. Never use detergents, acetone or other harsh This phenomenon has no effect on the intrinsic qualities of the wood, but can spoil its aesthetic appeal. products on the wood.
  • Page 210 16.1.6 Synthetic wood composite decking (imitation teak) The product is UV resistant with no need for sanding or special cleaning products. Do not pour acetone on the decking. Normal cleaning: - Rinse in fresh water, using a sponge or a soft brush. - Clean with soap or a household product if necessary, then rinse in fresh water.
  • Page 211 16.2 EQUIPMENT - Do not use the gangway when at sea. 16.2.1 Gangway - Never manoeuvre the gangway with anyone Description on it, below it or within its arc of movement. - The gangway allows you to embark/disembark easily when the boat is moored stern on to the pontoon. - Do not use the gangway as a diving board.
  • Page 212: Deck Fittings 16

    Hydraulic unit Location: Port aft locker 1. Motor 2. Manual emergency lever 3. Oil filler cap Emergency procedure - A key allows the user to open the electronics box to put the emergency switch to ON. - Operate the manual lever to stow the gangway. - Put the switch back into its original position after the manoeuvre.
  • Page 213 16.2.2 Electric platform (Rear skirt) General points - Do not climb onto the platform while in motion. The platform runs on the DC power supply. A circuit-breaker protects the circuit. - Do not use the rear platform while sailing. Using the remote control: - Maximum platform load = 300 Kg.
  • Page 214 emergency procedure In case of electrical failure, you can close the platform manually by following the stages below: - Shut off the DC supply of the cylinder by the circuit breaker (Starboard aft cabin); - Remove the protection key from the cylinder body (Ref 1); - Insert an Allen key to be used as a crank handle.
  • Page 215 16.2.3 Davits - The davits enable the launch and retrieval of the tender from the transom. Any other use is dangerous and forbidden. No one is to be onboard the tender while launching or retrieving it. - The davits are equipped with a pulley block for manoeuvering the tender. This pulley block is manoeuvered by hand. - A breaker protects the electrical circuit.
  • Page 216 16.3 BERTHING, ANCHORING, TOWING 16.3.1 Anchor points Responsibility It is the responsibility of the owner/user of the boat to ensure that the berthing lines, towing cables, chains and mooring lines and the anchors are adequate for the intended use of the boat, i.e. that the lines or chains do not exceed 80 % of the breaking strength of the corresponding anchor point. MOORING LINES MOORING TOWING...
  • Page 217 16.3.2 Towing Responsibility: It is important that the owner thinks through the actions required when securing a towing cable onboard. - Generally the breaking strength of lines/chains must not exceed 80% of the breaking strength of the anchor points. Location of attachment points - Always tow or be towed at low speed.
  • Page 218 16.4 MAIN ELEMENTS OF THE CHAIN LOCKER Refer to the manufacturer's instructions for use and Access - Chain locker: maintenance. Clinch Skipper's cabin Windlass operations are dangerous: - Always keep the anchor chain or rode free and unfouled; - Carry out manoeuvres carefully and always wear shoes;...
  • Page 219 16.5 ELECTRIC WINDLASS General points - The windlass is DC powered. - The windlass is designed for anchoring purposes: Any other use is dangerous and forbidden. - An operation relay is fitted to the electrical circuit. - A circuit-breaker protects the power supply to the windlass. - The windlass operation is activated by an operational interlock relay which is powered by the engine's alternator: the windlass only works when the boat's engine is running.
  • Page 220 Maintenance - once a year, dismantle, carefully wash and grease all the moving parts of the windlass. The handle serves only to release the chain grab in order to lower the anchor manually - Regularly grease the supply terminals of the electric motor of the windlass and of the relay control box. should the electric windlass break down.
  • Page 221 LAYOUT DIAGRAM - CHAIN METER Reference Designation Location: Starboard cockpit Remote control for the windlass Service batteries Operation relay Windlass Breaker Chain meter 146876 Index F...
  • Page 223 HULL FITTINGS Upholstery..................224 Interior woodwork ................227 Interior maintenance ..............227 Safe ....................227...
  • Page 224 17.1 UPHOLSTERY - Test the product on a small hidden area of LEATHER the surface before cleaning. Maintenance - Avoid excessive moisture. Leather must be regularly cleaned and waxed. - Do not scrub on leather surfaces. To do so, clean the leather surface with a damp rag. This operation will remove dust. - If you notice leather colour on the rag, Every 6 months to a year depending on use, apply a leather shampoo on the leather then use a hydrating cream which immediately stop cleaning.
  • Page 225 ALCANTARA (microfibre) Stain removal The fabric must be free from dust before removing. To do so, use a vacuum cleaner to achieve optimal cleanness. Rub with a duster soaked in a solution containing ammonia diluted by 10%. Dilute to the strength appropriate for this fabric. Try it out first on a hidden corner, the hem for instance, if the appearance of the fabric changes, dilute accordingly.
  • Page 226 COATED FABRIC (PVC) Maintenance - The PVC must be regularly cleaned with soapy water to maintain its appearance and avoid accumulation of debris. Try to avoid using the following products: lacqeurs, aggressive cleaning products, detergents, xylene or acetone-based products which can cause permanent damage or make the fabric deteriorate. The use of such products is at the owner's risk.
  • Page 227 17.2 INTERIOR WOODWORK - Clean the interior varnish using a de-greasing shampoo on a damp cloth. If the stains persist or if in doubt, consult a cleaning specialist. - Polish the interior varnishing with a chamois leather. When winterising the boat, make sure the - If there are any stains or light scratches, it is possible to polish the varnish.
  • Page 229 HANDLING, TRANSPORT Lifting plan ..................230 Lifting....................231 Keel ....................232 Upper limit of antifoul ..............233 Launch/Lift out................233 Stepping/unstepping the mast ............233 Winter Storage ................234 Transport..................235...
  • Page 230 18.1 LIFTING PLAN Dock and Go version: it is imperative to engage forward gear for several seconds to position the engine base of the boat correctly under the crane before stopping the boat's engine. A. lifting slings B. Bers Note: Measurements are expressed in mm. The position of the lifting slings is shown in the pictogram below: Handling, transport 146876...
  • Page 231 18.2 LIFTING - Before applying the first coat of antifouling on the hull, you can key the hull using wet sandpaper of 400 grade or higher. - Follow the manufacturer's recommendations scrupulously when applying antifouling. - The lower hull of your boat should be covered with an anti-fouling paint which will prevent the adhesion of marine growth.
  • Page 232 18.3 KEEL General points The ballast is the appendix located under a sailing yacht. It is an essential component of stability, essential for the operation of the boat. The ballast is fixed to the bottom of the hull by bolts or pins and nuts with the corresponding tightening torque. Maintenance The ballast is a part of the hull under the waterline.
  • Page 233 18.4 UPPER LIMIT OF ANTIFOUL The boat's hull has a shallow indent moulded along its length: the upper marking corresponds to the upper limit of antifoul on the hull. 18.5 LAUNCH/LIFT OUT The initial commissioning of your boat will require a lot of skill and care. The proper working of all your boat's equipment Do not remain onboard or beneath the boat is the result of the quality of the commissioning operations.
  • Page 234 18.7 WINTER STORAGE - Take advantage of laying up the boat to carry out a full inventory of the equipment. - The winterisation of the engine requires the skills of a professional engineer: please consult - Check the expiry dates of the safety equipment. your dealer.
  • Page 235 18.8 TRANSPORT Packing plan Note: Measurements are expressed in mm. 146876 Index F...
  • Page 237 ENVIRONMENT Waste management................ 238...
  • Page 238 Waste management: - Throw all packaging in the recycling containers provided for this. - Make sure you know the local enviromental regulations and follow the codes of best - Once a piece of equipment has completely stopped working, find out about the relevant recycling regulations from your practice.

Table of Contents

Save PDF
