- Page 1 MAXPHOTONICS CO.,LTD MFP-20 Pulsed Fiber Laser User Manual WWW.MAXPHOTONICS.COM...
- Page 2 The MAXPHOTONICS Laser Model MFP-20 is a Class IV laser product. Before turn on the power of 220VAC please make sure that the interface is exact, otherwise, the laser model will be shattered.
- Page 3 MAXPHOTONICS CO.,LTD Safety Information Safety Conventions This symbol indicates laser radiation. We place this symbol on products which have a laser output. WWW.MAXPHOTONICS.COM...
-
Page 4: Table Of Contents
MAXPHOTONICS CO.,LTD Table of Contents Description 1.1 Products Description……………………………………………………….5 1.2 Accessories………………………………………………………………...6 1.3 Environment and Precautions…………………………………………..6 1.4 Specification……………………………………………………………..7 Installation 2.1 Installation Measurement Picture………………………………………...9 2.2 Installation Method ……………………………………………………….10 External Layout Interface Specification………………………………………………. .11 Operation 4.1 Preparation for Use……………………………………………………..15 4.2 Operation Steps……………………….………………………………..16 4.3 Warning…………………………………………………………………..17 Quality Assurance,Warranty and Return Process 5.1 General Warranty……………………………………………………... -
Page 5: Description
MAXPHOTONICS CO.,LTD Description 1.1 Description MFP-20 pulsed Ytterbium fiber laser is the one of most advanced products of MAXPHOTONICS. It is a revolutionary, new, high-performance OEM device which was developed for integration into high-speed, high resolution laser marking systems. The main advantage of the MFP-20 offers over ten times improvement in per-Watt... -
Page 6: Accessories
Any tampering with the product will void the warranty. WARNING: This device has output optical head connected to the MFP-20 by fiber cable. So please, be careful dealing with output head. Do not separate the fiber and the laser head. -
Page 7: Specification
MAXPHOTONICS CO.,LTD WARNING: MFP-20 Fiber Laser Module has three fans at the rear panel for active cooling. Make sure that there is sufficient airflow to cool the device. WARNING: NEVER look directly into output head and make sure that you wear appropriate laser safety glasses at all times while operating the product. - Page 8 MAXPHOTONICS CO.,LTD Pulse Repetition Rate, kHz 22—70 Nominal Peak Power (pulse energy/FWHM pulse > 5 duration), kW Peak Power Instability, % < 5 Residual Pump Power at the Output, dB <-60 OPTICAL OUTPUT Output Fiber, m 20 / 125 / 3000/7000 Output Fiber Length, m 1.9/2.5/3...
-
Page 9: Installation
MAXPHOTONICS CO.,LTD Humidity, % 10 to 95 Weight, kg 2.Installation 2.1 Installation Measurement Picture 2.1.1 WWW.MAXPHOTONICS.COM... -
Page 10: Installation Method
MAXPHOTONICS CO.,LTD 2.1.2 Isolator Measurement 2.2 Installation Method 1).Connected the electrical mold and optics mold That means connecting the cable and radio cable (If the single radio cable) to the two ends of the molds separately. 2).Check that the AC voltage selector (24) set to the correct voltage, then plug the remote control unit into the mains supply. -
Page 11: External Layout
MAXPHOTONICS CO.,LTD 3. External Layout 25 pin D-shape connector pin assignment WWW.MAXPHOTONICS.COM... - Page 12 MAXPHOTONICS CO.,LTD Control Interface Operation as followings 1.This laser is controlled by connecting through the DB25 interface, the detail information please view above sheet 2. Pin1~8 are the main line of setting the power of 8 bit,Pin1 is LSB，Pin8 is MSB。...
- Page 13 MAXPHOTONICS CO.,LTD H, the laser will be out after stated delay. When the level is L, the laser will be turned off after stated delay. Notes： a. MO should be turned on before 4ms of BS, if not, it will be no laser output.
- Page 14 MAXPHOTONICS CO.,LTD 8. Set up the Pin18 to and turning on MO. 9. Waiting about 4ms. 10. T hrough Pin19 to modulate the laser. Input H/L to control the laser’s switch. The up and down time have been limited（referring the specification）The modulate speed can not be faster than the total value of up and down’s time.
-
Page 15: Operation
4.3.1 The highest frequency should be70KHz 4.3.2 Please be careful when you adjust the rate of frequency when marking, or it will influence the marking results. 4.3.3 It’s workable for MAXPHOTONICS fiber laser to turn off the laser power directly WWW.MAXPHOTONICS.COM... -
Page 16: Quality Assurance,Warranty And Return Process
MAXPHOTONICS CO.,LTD 5. Quality Assurance, Warranty and Return Process 5.1 General Warranty The warranty of Maxphotonics fiber laser is 24 months upon the customer receive the fiber laser . All products are warranted by MAXPHOTONICS against defects in materials and workmanship for the period of time as set forth on the applicable purchase order or in the specifications starting with the date of shipment. -
Page 17: Service And Repairs
MAXPHOTONICS Fiber Laser or its representative in your area. Items authorized for return by us must be returned in a suitable container. -
Page 18: Rma Clearance Form
Mingschin Industrial Park,Nanhuan Road ,Shajing Town,Bao’an,Shenzhen,China Attention: Quality Manager This RMA file number will expire 31 days after the faxed date from MAXPHOTONICS FIBER LASER. Thereafter, units received in under the expired RMA number will result in a longer turn around time. - Page 19 7. Complete packing list with product model and serial number will insure prompt repair, if the other terms of this form are followed. 8. See the MAXPHOTONICS Terms and Conditions for the applicable warranty for the products before you request the return of the products.
