Assembly Instructions
PLEASE NOTE THAT THIS IS NOT THE OWNER'S MANUAL BUT THE
ASSEMBLY INSTRUCTIONS ONLY.
BEFORE OPERATING THIS GO-KART, MAKE SURE THE OPERATOR READS
AND UNDERSTANDS THE OWNER'S MANUAL, WARNING LABELS AND IS
FAMILIAR WITH ALL GO-KART CONTROLS.
FOR QUESTIONS REGARDING ASSEMBLY OF THIS GO-KART, PLEASE CALL
COLEMAN POWERSPORTS, TOLL FREE 888-405-8725
colemanpowered.com
REV 60619

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SK100 and is the answer not in the manual?

Questions and answers

Related Manuals for Coleman Powersports SK100

Summary of Contents for Coleman Powersports SK100

  • Page 1 BEFORE OPERATING THIS GO-KART, MAKE SURE THE OPERATOR READS AND UNDERSTANDS THE OWNER’S MANUAL, WARNING LABELS AND IS FAMILIAR WITH ALL GO-KART CONTROLS. FOR QUESTIONS REGARDING ASSEMBLY OF THIS GO-KART, PLEASE CALL COLEMAN POWERSPORTS, TOLL FREE 888-405-8725 colemanpowered.com REV 60619...
  • Page 2 PARTS Owner’s Manual Hardware Rear Wheels Front Wheels Safety Net Nose Piece FRONT BUMPER Side pads Net Supports Tool Kit...

  • Page 3: Front Wheel Assembly

    FRONT WHEEL ASSEMBLY Hardware: M14 Washer 2ea. (A) M14 Castle Nut 2ea. (B) Cotter Pins 2ea. (C) 1. Locate front wheels. Front Wheel Note: Front wheels have bearings on both sides of hubs Bearing 2. Install front tires on axles making sure air stem on rim faces out.

  • Page 4: Rear Wheel Assembly

    REAR WHEEL ASSEMBLY Hardware: Wheel Spacers 2ea. (A) 2ea. (B) M14Washer 2ea. (C) M14 Castle nuts 2ea. (D) Cotter pins 2ea. (E) Rear wheel Keyway 1. Slide wheel spacer (A) over Grove axle 2. Insert Key (B) into Keyway grove on axle. 3.
  • Page 5 BUMPER ASSSEMBLY Hardware: M8 x 35 bolts 2ea. (A) M8 Lock Nuts 2ea. (B) Bumper 1ea. (C) 1. Install front bumper (C) and attach to Frame using bolts (A) and Lock Nuts (B). Tighten bolts.

  • Page 6: Nose Assembly

    NOSE ASSEMBLY M6 X 16 Screws 4 ea. (A) M6 Plastic Flat Washers 4 ea. (B) Plastic Nose piece 1ea. (C) 1. Attach front nose piece (C) to frame with Screws (A) and plastic washers (B). Bottom view 2. Attach wires (D) to ON/OFF switch (E).
  • Page 7 STEERING COLUMN AND SIDE PADS INSTALL M8 X 55 bolt 1 ea. (A) M8 Lock Nut 1 ea. (B) Frame Pads 2ea. (E) 1. Lift steering column (C) up to steering bracket 2. Attach bracket with Bolt (A) and Lock nut (B) 3.
  • Page 8 NET SUPPORT ASSEMBLY M8 X 30 Allen Head bolts 4 ea. (A) M8 Lock Nuts 4 ea. (B) M8 X 45 Phillips Screw 1ea. (C) M8 X 55 Phillips Screw 1ea. (D) Loop support 1ea. (E) Back support 1ea. (F) 1ea (G) 1.

  • Page 9: Pre-Ride Inspection

    PRE-RIDE INSPECTION WHAT TO CHECK FOR Inspecting and checking the CHECK condition of the Go Kart Steering • Smoothness before each ride is important. • No restriction of Following the pre-ride check movement list will help insure the you do Brakes •...
  • Page 10 WARNING Never Attempt to start this Go-Kart without reading and understanding the Owner’s/Operator’s manual. The Owner’s/Operator’s manual provides information on safety, parts, functions, pre-ride inspection, starting and maintenance. Powersports Phone: 888-405-8725 Colemanpowered.com...
