Summary of Contents for ZyXEL Communications VMG8924-B30A
Page 1
VMG8924-B30A Standard Version Firmware Release Note V1.00(AAPQ.14)C0 Date: December 15, 2017 Author: Ping Lin Reviewer: THIS DOCUMENT CONTAINS PROPRIETARY TECHNICAL INFORMATION THAT IS THE PROPERTY OF THE ZyXEL AND SHOULD NOT BE DISCLOSED TO OTHERS IN WHOLE OR IN PART, REPRODUCED, COPIED, OR USED AS BASIS FOR DESIGN, MANUFACTURING OR SALE OF APPARATUS WITHOUT WRITTEN PERMISSION OF ZyXEL.
Revision History Date Release Author Description 2013/11/07 Cj_Lai FW release for V1.00(AAPQ.0)b1 2013/11/26 Cj_Lai FW release for V1.00(AAPQ.0)b2 2014/02/18 Cj_Lai FW release for V1.00(AAPQ.0)b3 2014/04/10 Cj_Lai FW release for V1.00(AAPQ.0)b4 2014/04/21 Cj_Lai FW release for V1.00(AAPQ.0)b5 2014/04/23 Cj_Lai FW release for V1.00(AAPQ.0)C0 2014/07/21 Wood Huang FW release for V1.00(AAPQ.1)b1...
Page 5
2016/08/23 12.0 Albert Lu FW release for V1.00(AAPQ.10)C0 2016/10/28 12.1 Albert Lu FW release for V1.00(AAPQ.11)b1 2017/02/10 12.2 Albert Lu FW release for V1.00(AAPQ.11)b2 2017/02/21 13.0 Albert Lu FW release for V1.00(AAPQ.11)C0 2017/06/06 13.1 Ricky Fan FW release for V1.00(AAPQ.12)b1 2017/06/12 14.0 Ricky Fan...
QoS Monitor will show only if QoS software Queue is used. Qos software queue is created if rate limit or WFQ is configured. 802.11ac is supported with 4360 WLAN adaptor (VMG8924-B30A model). WPS lock down: 10 failures in 300 seconds.
Features list: Feature Additional Information VDSL G.993.1 VDSL Annex B G.993.2 VDSL2 Annex B, band plan 997, 998 Support VDSL profiles: 8a/b/c/d, 12a/b and 17a Maximum data rate (DS/US): 100Mbps/60Mbps G.994.1 (G.hs) Handshake Rate adaption ...
Page 9
Device) Interface Grouping Static/Policy Route Additional Subnet: IP Alias/Public LAN STB Vendor ID 5th Ethernet Port LAN VLAN Adjustable MTU size (max 1518 byte) MAC Encapsulation Routing / IPoE Qos classification route ...
Page 10
Firewall & Security 802.1x Authentication (EAP-TLS) PAP/CHAP MS-CHAP v1 and v2 Stateful Packet Inspection Parental control: Protocol Packet Filter/URL keyword blocking , Scheduled filtering policy based on time of day. ACL Rule support: (32 ACL rules) Selected Source/Destination Device Source/Destination IP Source/Destination Port (Any/Single/Range)
Page 11
Client connection : A minimum of 32 clients simultaneously connect to the AP Adjustable WLAN output power(via CLI , xml) Hidden SSID support Generate default unique ESSID by serial number (show on CPE back label) Generate default unique wireless KEY by MAC (show on CPE back label) ...
Page 12
Message Waiting Indicator (RFC 3842) T.38 Fax Relay Transparent Fax rely over G.711 Polarity Reverse Last Number Redial Flexible dial plan (RFC3525 section 7.1.14) Call return Immediate Dial SRTP Music On Hold ...
Page 13
Queue Management - Drop Tail - Rate Limit - Queueing and Scheduling · Strict Priority Queueing · Weighted Fair Queueing Counters and statistics for QoS and traffic Default L2/L3 tagging and queueing setting of each outgoing interface Management ...
Page 14
MultiBoot AT Command Diagnostic 802.1ag CFM Capabilities xDSL Statistics Ping/TraceRoute/NSlookup OAM Ping Remote packet trace function IGMP IGMP v1, v2, v3 IGMP Proxy IGMP Snooping Support fast leave Triple Play ...
[TE][Romfile] Let admin account can use phonetest command in TE Romfile (1). Bootup device with SMT rom file (2). use Admin to login console (3). ifconfig br0 to check IP is 192.192.192.4 (4). Command “phonetest dut 1234” to run Because we change TE Romfile, we need to rebuild file system. Therefore, the RootFS Checksum is different from AAPQ13b1.
6. [#34909] [eTIS #161100653][Vodafone] QoS Prio 0, Prio 5 and Prio 6 works not correct with Annex J VMG 1312-B30A 7. [#34911] [eTIS# 161200526]VMG8924-B30A; Unable to create ICMPv6 rule 8. [#34912] [eTIS #170100262]VMG8924-B-30A; Admin is able to save rom-d via zyshell 9.
Page 20
6. [FR-013] Brand 2.0 7. [TE-002] CLI command list for MFG 8. [#160601009][VMG8324-B10A][SIP] Call Cancel does not work 9. [#160800212] VMG8924-B30A; UPnP port forwarding not displayed correct in TR069 10. [#160800507] VMG8924-B30A; TR069 doesn't follow the standard related to port-forwarding [Bug Fix] 1.
7. [ITS #151200136][CLI] Able to enable/disable WAN redirect via ssh 8. [ITS #151100825][PwrMang] Powered off LAN port still active 9. [ITS #160100124][DSL][VMG8924-B30A]Upgrade the DSL mode code to B2pv6F039s 10. [ITS #160300725][TR069] Show 802.11ac capabilities via TR069 11. [ITS #160101210][DSL][VMG8924-B10A]update DSL code to A2pv6F039q (update to A2pv6F039v) 12.
Page 23
14. [ITS #160300795][DSL][VMG1312-B10A][ADTRAN] New BRCM modem code 'A2pv6F039v' 15. [ITS #150800479][VPN] UDP VPN fail after reboot 16. [3G backup] upgrade 3G backup version to 1.16 17. [WWAN] TR069 support upgrade 3G WWNAN package 18. [VoIP] T.38 FAX Fallback and Can Accept Revert to Audio Request 19.
Page 24
31. [ITS #160201157][CLI][VMG8924-B10A] wlan get chquality only shows channel 1-6 32. [ITS #160201030 #160201039][CLI] command terminates telnet session 33. [ITS #160200269][SysLog][VMG8924-B30A] Management dies after 5 days 34. [ITS #160400200][GUI][VMG8924-B10A] Correct Turkey translation error. 35. [ITS #160400379][GUI][VMG1312-B10A] Grammar error when deleting an empty WDS entry 36.
44. [#FR-011][EoC] EOC registry, Follow EOC Registry Naming Rule v1.1 45. [PQA #208][GUI] SIP Service Provider cannot modify if Name contain special character. 46. [PQA #248][GUI]Virtual Device doesn't depend on real status. 47. [PQA #344][UPnP] By default settings (WAN: IPv6/IPv4 DualStack Mode), UPnP function is work, but after reboot CPE, the UPnP function will work failed.
Modifications in V1.00(AAPQ.9)b1 Based on 1.00(AAPQ.8)C0 to release V1.00(AAPQ.9)b1. [Configuration Modification] [Feature Enhancement] [Bug Fix] 1. [ITS #160300058] Wireless interface is missing in custom Interface Group 2. [ITS #160100334] Configuration backup and restore - wlan fails 3. [ITS# 150700048] TR069 SSL Fail Modifications in V1.00(AAPQ.8)C0 Based on 1.00(AAPQ.8)b2 to release V1.00(AAPQ.8)C0.
Modifications in V1.00(AAPQ.7)b1 Based on 1.00(AAKL.11)C0 to release V1.00(AAPQ.7)b1. [Configuration Modification] 1. Follow attach file “Default Setting List_for VMG8924-B30A generic.xlsx” to modify default setting for VMG8924-B30A generic firmware. [Bug Fix] 1. [SVD# 346][RMGMT] Enable FTP Trust domain on remote management will disable SNMP and ICMP wan function.
Modifications in V1.00(AAPQ.6)C0 Base on 1.00(AAPQ.6)b1 to release V1.00(AAPQ.6)C0. Modifications in V1.00(AAPQ.6)b1 Base on 1.00(AAPQ.5)C0 to release V1.00(AAPQ.6)b1. [Bug Fix] 2. [ITS# 150400843] After upgrade FW from old firmware. (ex: AAPQ3) The supervisor’s password & ACS password will become strange value. Modifications in V1.00(AAPQ.5)C0 Base on 1.00(AAPQ.5)b1 to release V1.00(AAPQ.5)C0.
Base on 1.00(AAKL.4)b3 to release V1.00(AAPQ.0)b4. Change modem code to ANNEX B Modifications in V1.00(AAPQ.0)b3 First release. Base on 1.00(AAKL.3)b3 to release V1.00(AAPQ.0)b3. Change modem code to ANNEX B Modifications in V1.00(AAPQ.0)b2 First release. Base on 1.00(AAKL.2)C0 to release V1.00(AAPQ.0)b2.
Public Domain Software Announcements The following public domain software are used in this firmware release: MIPS Linux kernel, version 2.6.30 http://www.linux-mips.org or http://kernel.org Bridge-Utils http://bridge.sourceforge.net BusyBox 1.0.0 toolset http://www.busybox.net/ Dproxy: dproxy-nexgen http://dproxy.sourceforge.net ebtables 2.0.6 http://ebtables.sourceforge.net bftpd 1.0.24 http://www.bftpd.org/ iproute2 iproute2-2.4.7-now-ss020116-try.tar.gz http://www.linuxgrill.com/anonymous/iproute2 iptables-1.3.8 http://www.netfilter.org...
