Three examples of remote alarm triggered from a dry contact in your BVS product
(Similar outputs are provided in all wall-mounted BVS products)
Vcc1
SSR
Alarm
Condition
Registered in
SentryHound-Pro
SSR - Solid State Relay
Remote Power
Light bulb as a
Warning/Alarm
Remote Ground
Remote Power
Siren as a
warning/alarm
Remote Ground
Vcc2
Visual and/or
audio alarm
in one BVS
wall-mounted
products:
WallHound
WallHound-Pro
WatchHound-Pro
