There are port related LEDs on the Clearfog Pro Evaluation Board. These are indicating for example power on,
connection and port activity. For further details, please refer to our wiki.solid-run.com pages.
5.6 Clock options
For frequency configuration a dip switch is used. The default setting is the off-position for all 5 switches as in the
picture here:
Please refer to wiki.solid-run.com for various settings for different frequencies.
5.7 SIM card holder
It is possible to utilize a Cellular connection by inserting a SIM card into the SIM card holder. Please observe that a
GSM modem needs to be installed utilizing the mini PCIe connection.
5.8 Additional Components
The components listed here are also needed for starting to use the Evaluation Board:
SD card with installed OS (officially released distribution)
Suitable Power Adapter
SolidRun Ltd
U
M
SER S
ANUAL
www.solid-run.com
3 Dolev Street, 2495900 Migdal Tefen, Israel
JANUARY 2017
Page 8 of 13
