1. O
VERVIEW
1.1 General Information
The SolidRun Clearfog PRO is a high performance Evaluation Platform featuring
provides a base for building various applications and fits well with a wide range of various target markets requiring
high performance processing power, connectivity and storage interfaces. The SolidRun Clearfog PRO has compact
dimensions and a low power consumption, utilizing an ARM Cortex A9 Single/Dual CPU.
SolidRun Clearfog PRO Evaluation Board components are listed here:
SolidRun Clearfog PRO Carrier Board
A38x uSOM for the SolidRun Clearfog PRO
Power adapter
Heat sink
Enclosure (optional)
Micro SD card (optional)
Officially released distributions
Open WRT
o
Yocto
o
Please contact SolidRun support for further information:
1.2 Summary of Features
Listed here are the available features of the product:
1 GB DDR3 RAM
4 MB NOR Flash [storage memory / boot]
MicroSD based storage (Can be replaced with an on-board eMMC)
M.2 slot supporting 2242 SSD modules
Two slots supporting either Mini PCIe or mSATA SSD modules
One SIM Card holder for Mini PCIe cellular modem
10/100/1000 Mbps Ethernet WAN port
SFP frame
Six switched 10/100/1000 Mbps Ethernet LAN ports
One USB 3.0
Telephony/Audio header supporting PSTN and analog audio modules
MicroBus Header supporting serial interfaces such as SPI , UART, etc.
Serial communication over MicroUSB for development purposes
JTAG Interface for low level development and debug
Power over Ethernet (PoE) Header (optional module)
RTC Backup battery
9-32V power supply
Other elements on the board are:
Push button connected to a GPIO.
SolidRun Ltd
U M
SER S ANUAL
support@solid-run.com.
-A9 Core at 1.6 GHz
www.solid-run.com
3 Dolev Street, 2495900 Migdal Tefen, Israel
JANUARY 2017
38x-uSoM). It
