Remote Control
Reference Guide
The VR-5 supports remote control via MIDI. This document describes settings for remote control.
* If the system software version of your VR-5 is 1.0, it does not support remote control via V-LINK. The V-LINK
indicator does not light. Remote control via V-LINK will be supported in later versions.
Copyright © 2010 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written
permission of ROLAND CORPORATION.
1PS

Advertisement

loading
Need help?

Need help?

Do you have a question about the VR-5 and is the answer not in the manual?

Questions and answers

Related Manuals for Roland VR-5

Summary of Contents for Roland VR-5

  • Page 1 The VR-5 supports remote control via MIDI. This document describes settings for remote control. * If the system software version of your VR-5 is 1.0, it does not support remote control via V-LINK. The V-LINK indicator does not light. Remote control via V-LINK will be supported in later versions.
  • Page 2 STANDARD SETUP Rx CHANNEL VIDEO SEL TYPE If the system software version of your VR-5 is 1.0, it supports remote control of Standard Mode only. Other modes will be supported in later versions. COMMON SETUP You can set parameters common for all modes here.
  • Page 3 • Tx CHANNEL Select a MIDI transmit channel that matches the MIDI channel your external MIDI device expects. You can transmit MIDI messages corresponding to the following operations on VR-5. • Volume of MIC/LINE 1 and 2 • Volume of audio channels •...

  • Page 4: Midi Implementations

    40H-7FH (64 - 127) : On —————————————————————————————————————————— 1. MIDI messages received at MIDI IN If [Rx CHANNEL] in MIDI SETUP > STANDARD SETUP > is turned to [OFF], VR-5 does not receive the following MIDI messages. ■ Channel Voice Messages ● Note On...
  • Page 5 MIDI Implementations ❍Undefined (Controller No.14) Status 2nd Byte 3rd Byte * This controls the slider value of Audio 3. ❍Undefined (Controller No.15) Status 2nd Byte 3rd Byte * This controls the slider value of Player. ❍General Purpose Controllers 1 (Controller No.16) Status 2nd Byte 3rd Byte...
  • Page 6 MIDI Implementations ❍Hold 2 (Controller No.69) Status 2nd Byte 3rd Byte * This turn on/off the USER LOGO button. ● Program Change Status 2nd Byte pp=program number : 00H - 7FH (1 - 128) * With bank select or note on message, this switches the channel to the one corresponding to note number or selects/starts playback of a file. * Unavailable program change will be ignored.

  • Page 7: Midi Messages Transmitted From Midi Out

    If [MIDI OUT] in MIDI SETUP > COMMON SETUP is set to [THRU], VR-5 transmits only received messages. 2-2. Generating and Transmitting Messages If [MIDI OUT] in MIDI SETUP > COMMON SETUP is set to [OUT], VR-5 generates the following messages and transmits. ■ Channel Voice Messages ●...
  • Page 8 MIDI Implementations ❍Undefined (Controller No.15) Status 2nd Byte 3rd Byte * This transmits the value when Player slider is operated. ❍General Purpose Controllers 1 (Controller No.16) Status 2nd Byte 3rd Byte * This transmits the value when PC AUDIO LEVEL dial is operated. ❍General Purpose Controllers 2 (Controller No.17) Status 2nd Byte...
  • Page 9 MIDI Implementations ● Program Change Status 2nd Byte pp=Program Number : 00H - 7FH (1 - 128) * This is transmitted with bank select or note on when video channel is switched or file selection/playback occurs. * For the combination of bank select/program change or video channel/file number, refer to “MIDI Setup Menu” (p. 2) * For the combination of program change/note on or video channel/file number, refer to “MIDI Setup Menu”...
  • Page 10 MIDI Implementations Appendices Decimal and hexadecimal conversion table (The letter “H” follows numbers in hexadecimal notation.) MIDI uses hexadecimal notation in 7-bit units to indicate data values, addresses and sizes within an exclusive message. Hexadecimal and decimal numbers corresponds as follows. Deci Hexa Deci...

  • Page 11: Midi Implementation Chart
