Roland Edirol R09 Brief Instructions

Edirol R09 brief instructions Edirol R09 brief instructions
Edirol R09 brief instructions Edirol R09 brief instructions
Front view
Power button
Input level controls
Battery and memory card
compartment
Recording Recording Recording Recording
Note - in the bag is a glossy booklet with useful tips on recording techniques for various situations.
1. Press and hold Power button until Recording screen ap-
pears.
2. Note battery indicator, bottom right. All white is good!
3. Press Rec button briefly- red surround flashes, and level
bars move in window.
4. Point mics towards sound source.
5. Use input level controls to set desired recording sensi-
tivity. Note - controls on rear for AGC and mic sensitiv-
ity.
6. When ready, press Rec button again to start recording.
Ensure red Peak light stays off.
7. When finished, press Stop button.
8. NB a foam pad or bean bag on a table make a good 'dead' support during recording
to avoid handling or other noises. The Low Cut filter reduces bumps and wind noise.
Replaying Replaying
Replaying Replaying
1. From the Recording screen, press the Finder button
briefly.
2. A list of recordings appears, latest at the bottom - scroll
up and down with the Play/pause and Stop buttons.
Page 1
aap/ CVTN Edirol R09 brief Instructions.pub / 06/05/2019
Edirol brief instructions
Mics
Headphone socket
Peak light
Output volume
Play/pause button
Record/Enter
Button
Stop button
