FEATURES
Corner Master
By having adopted a brand new concept design that is appropriate for
walls, the Robot Cleaner's cleaning performance is incredibly efficient.
Learning Mode
The Robot Cleaner is capable of memorizing the cleaning environment
via its Smart Operation feature for smarter cleaning.
Turbo Mode
In the Turbo mode, the Robot Cleaner operates the suction motor and
the brushes at a greater speed giving cleaner results.
When selected, the "Turbo" mode is automatically activated on carpets,
which enables the Robot Cleaner to run more efficiently.
Drawer Mop Plate (Option)
The "Drawer mop plate" makes it much easier for users to fit and remove
the mop without having to turn over the device.
My Space Mode
By commanding it to clean a particular area, the Robot Cleaner quickly
cleans that desired area.
Repeat Cleaning
The Robot Cleaner will continuously clean until the battery runs out.
Zigzag
Location Search Function
If the Robot Cleaner is moved from a spot while operating, the device will
automatically search for the previous location and return to the spot from
where it was interrupted.
Advertisement
Table of Contents
Related Manuals for LG VR7621SPG
Summary of Contents for LG VR7621SPG
- Page 1 FEATURES Corner Master By having adopted a brand new concept design that is appropriate for walls, the Robot Cleaner's cleaning performance is incredibly efficient. Learning Mode The Robot Cleaner is capable of memorizing the cleaning environment via its Smart Operation feature for smarter cleaning. Turbo Mode In the Turbo mode, the Robot Cleaner operates the suction motor and the brushes at a greater speed giving cleaner results.
-
Page 2: Table Of Contents
CONTENTS BEFORE USING ADDITIONAL INFORMATION Safety precautions 50~52 Troubleshooting Included with product Before you call for service Parts description 10~11 Button functions Display status information REFERENCE Before you start Reference items Overview [IEC 62929 Standard] Setting for Cleaning Performance Test METHOD OF USE How to install the home station How to turn the Robot Cleaner power... -
Page 3: 2~6 Safety Precautions
3. If the supply cord is damaged, it must be replaced by LG Electronics Service Agent in order to avoid a hazard 4. This appliance can be used by children aged from 8 years and above and persons with reduced physical,... - Page 4 Failure to follow this warning can cause electric shock, fire or product failure. If the power cord is broken, do not plug it in. Take the product to an LG Electronics Authorised service repairer. Do not place the home station...
- Page 5 SAFETY PRECAUTIONS WARNING Do not spray or use Turn the power supply off inflammable materials, immediately if any abnormal sound, odor, or smoke is surfactants, or drinking water generated from the Robot in the vicinity of the Robot Cleaner by removing it from the Cleaner.
- Page 6 Doing so can cause product failure. Do not put any water failure. or detergent on the Robot Cleaner. If liquids get inside of the Robot Cleaner, turn off the power supply and contact an LG Electronics sales agent or customer care center.
- Page 7 SAFETY PRECAUTIONS CAUTION If the floor is wet or has wet When the robot cleaner is spots, wipe them up before operating, it may hit the chair leg, desk leg, table leg or other using the Robot Cleaner. Do narrow pieces of furniture. not use the Robot Cleaner on a wet surface.
-
Page 8: Included With Product
INCLUDED WITH PRODUCT Robot Cleaner Remote controller Home station s Figures can be different from actual objects. Cleaning Tool Dust bin filter (spare) DVD Manual (option) for cleaning sensors for cleaning the filter Cleaning brush Mop plate (option) Ultra microfiber mop (It’s on the dust bin cover) (2 pieces) (option) Batteries for remote controller... - Page 9 PARTS DESCRIPTION - ROBOT CLEANER Plan view Upper camera sensor Dust bin cover Display & Manipulation button Dust bin cover button Front view Ultrasonic sensors Obstacle detecting sensor window Detecting sensors of home station & Receiving sensors of remote controller Rear view Power switch Ventilation port...
- Page 10 PART DESCRIPTION – HOME STATION / DUST BIN Home station Remote controller holder Charging terminal Power cord fixing hook Dust bin Dust bin handle Cleaning brush Dust bin cover Suction port flap Sponge filter Dust bin lid opening button EPA filter Filter cover s Figures can be different from actual objects.
-
Page 11: Button Functions
BUTTON FUNCTIONS – ROBOT CLEANER • If the button is pressed, ‘Turbo Mode’ will be set with a voice confirmation. TURBO • If the button is pressed whilst in ‘Turbo Mode’ , it will be canceled. • Used to turn the power on from Standby, start or stop cleaning. •... - Page 12 BUTTON FUNCTIONS – REMOTE CONTROLLER Power Pressing this button will Home turn the power on from Used to recharge the Robot Standby or the power will Cleaner by making it return to the be returned to Standby Home Station. (p18) while the power is ON.
-
Page 13: Display Status Information
DISPLAY STATUS INFORMATION Turbo Mode icon Operational Status icon Homing icon This indicates the This indicates the This indicates the settings for Turbo Mode. operational status of conditions of Homing Hombot. and Charging. Repeat Mode icon Remote connection Icon This indicates the Displayed when the settings for Repeat smartphone connect to... -
Page 14: Before You Start
BEFORE YOU START Check these items before cleaning • Do not use this device in a room where a child is left alone. The child could be injured. • Remove fragile or unnecessary objects from the room to be cleaned. Especially, remove expensive ceramics and valuables from the floor. -
Page 15: Overview
OVERVIEW Install the home station. (p15) Insert the power cord plug into an outlet and locate the station against a wall. If power is not supplied to the home station, the Robot Cleaner will not charge. Turn on the power supply of the Robot Cleaner. -
Page 16: How To Install The Home Station
Do not operate the Robot Cleaner if the Home Station has a damaged cord or plug, if it is not working properly, or if it has been damaged or dropped. To avoid electrical hazards, the cord must be replaced by LG Electronics, Inc. or a qualified service person. -
Page 17: How To Turn The Robot Cleaner Power Supply On & Off
HOW TO TURN THE ROBOT CLEANER POWER SUPPLY ON & OFF Turning on the main power supply Make sure the Power Switch is on at the rear-left of the Robot Cleaner. If the power is OFF, turn the switch ON. ※... -
Page 18: How To Start And Stop Cleaning
HOW TO START AND STOP CLEANING Using the buttons on the Robot Cleaner After the Robot Cleaner main power switch is turned on, press the START/STOP button to begin cleaning. A melody will sound and cleaning will begin. Press the START/STOP button during the cleaning cycle to stop cleaning. -
Page 19: How To Charge The Battery
HOW TO CHARGE THE BATTERY Automatic charging The Robot Cleaner returns to the home station at the end of a cleaning cycle or when its battery is running low. ※ If 10 minutes elapse without the Robot Cleaner moving or the battery is too low, the power will be automatically turned OFF. - Page 20 HOW TO CHARGE THE BATTERY Entering power saving mode Switching to power saving mode to reduce power consumption after full charge. • Will enter power saving mode if the following conditions are met - 10 minutes after full charge - When no connection or user input is made for 10 minutes - When there is no function (cleaning) reserved for the next 15 minutes •...
-
Page 21: Cleaning Modes
CLEANING MODES Zigzag Cleaning In ‘Zigzag’ mode, Robot Cleaner repeats a zigzag operation to clean each and every spot in the cleaning area. If you need to quickly clean an area choose ‘Zigzag’ mode. Press ‘Mode’ button on Remote Controller or main unit to select ‘Zigzag’... - Page 22 CLEANING MODES My Space Cleaning Pressing 'My Space' on the Remote Controller will set the My Space cleaning mode with a voice message. For cleaning of particular spaces, select this mode. The 1st stage: Use the Remote Controller to manually set the parameters of each cleaning block.
-
Page 23: Auxiliary Cleaning Modes
AUXILIARY CLEANING MODES Turbo Mode Pressing the 'Turbo' button on the Remote Controller or main unit will activate 'Turbo' mode, with a voice message. While in 'Turbo' mode, pressing the same button will cancel 'Turbo' mode, with a voice message. In 'Turbo' mode, Robot Cleaner runs more intensely for a powerful clean. -
Page 24: Mop Cleaning (Option)
MOP CLEANING (OPTION) By attaching the ultra microfiber mop, you can effectively use the Robot Cleaner to remove dust on hard floor surfaces. When the mop plate is attached, the Robot Cleaner will not climb on to carpets or over thresholds, in order to prevent transferring dirt Caution from the mop. -
Page 25: Location Search Function
LOCATION SEARCH FUNCTION The Robot Cleaner remembers its location while cleaning. If the user moves the Robot Cleaner while it is operating, it will search for the location it was moved from by using its navigational location search function before continuing to clean. -
Page 26: Smart Diagnosis
SMART DIAGNOSIS Robot Cleaner uses this Smart Diagnosis feature to run a self-diagnosis. If any irregularity is found from the diagnosis, please contact the local LG Electronics service center. ※ During Smart Diagnosis, the Robot Cleaner will move about within a 50 cm radius. So, make sure no objects are in the way within a 1 m radius around the Home Station, before starting Smart Diagnosis. - Page 27 Charging cannot be done due to a problem in infrared Run Smart Diagnosis again and, if the same message is sensor. announced, contact an LG Electronics service center. Charging cannot be done due to a problem in ultrasonic Run Smart Diagnosis again and, if the same message is sensor.
-
Page 28: Smart Application Function
SMART APPLICATION FUNCTION You can control the Robot Cleaner from your smartphone. The "LG Roboking" application provides the following functions: • Simple Control, Cleaning Diary, Schedule Cleaning, Smart Diagnosis AP with Internet access Smartphone (Android or iOS) Robot Cleaner with network access... - Page 29 SMART APPLICATION FUNCTION Signing up for membership You need to subscribe your personal login ID on the server to control the Robot Cleaner from your smartphone. 1. The [Startup Screen] opens when you run the "Smart ThinQ" application. Select “nation / Language”...
- Page 30 SMART APPLICATION FUNCTION How to register the product You will need to register the product on the application to control the Robot Cleaner from your smartphone. Add your Robot Cleaner to the app with the Wi-Fi feature to use the Smart function. 1.
- Page 31 SMART APPLICATION FUNCTION Wi-Fi / Register product (Android) Product registration can be done using the "Wi-Fi" function for Robot cleaner. 1. Check whether the "Smart ThinQ" mark is printed or not. If there is a “Smart ThinQ” mark on the product, press the "Yes" button. [Product category] •...
- Page 32 SMART APPLICATION FUNCTION Product network / Register product (Android) 1. Long-press the "TURBO(Register/3sec)" button on Roboking for 3 seconds. 2. By selecting your AP on the "Wi-Fi network" list, you will automatically be directed to the product registration mode. 3. After registration is complete, the [Dashboard] screen will open. 4.
- Page 33 SMART APPLICATION FUNCTION How to register the product (iOS) You will need to register the product on the application to control the Robot Cleaner from your smartphone. Add your Robot Cleaner to the app with the Wi-Fi feature to use the Smart function. 1.
- Page 34 SMART APPLICATION FUNCTION Product network / Register product (iOS) 1. Please long-press the “Turbo” button for 3 seconds while the Robot cleaner is turned on. 2. Please turn on the “Wi-Fi connection” function in iPhone “Settings.” 3. Please press the “Check connection” button on the App screen after connecting to “LG_HOMBOT_ REG”...
- Page 35 SMART APPLICATION FUNCTION Startup screen of application The following screen will open when you connect to the Robot Cleaner for the first time from the "Smart ThinQ" application: Displays the product's You can check for any nickname. alert history. Menu The home icon selects Schedule Cleaning, the product list page.
- Page 36 SMART APPLICATION FUNCTION Startup screen of application Menu Schedule Cleaning, Cleaning Diary, Smart Diagnosis, Setting. Simple Control You can operate the Robot cleaner manually on the Simple control screen. In addition, you can start cleaning or self navigate it back to the docking station by pressing the "Start Cleaning"...
- Page 37 SMART APPLICATION FUNCTION Simple Control You can operate the Roboking manually on the Simple control screen. In addition, you can start cleaning or self navigate it back to the docking station by pressing the "Start Cleaning" or "Start Charging" button. The "Start Cleaning"...
- Page 38 SMART APPLICATION FUNCTION Menu – Schedule Cleaning You can schedule the time you want the Robot Cleaner to start cleaning. To set up Schedule cleaning, toggle across the Schedule cleaning key to turn it on or off in the Schedule cleaning menu. After enabling Schedule cleaning, set up the time and repetition, and then click "Save"...
- Page 39 SMART APPLICATION FUNCTION Menu – Cleaning Diary You can view the diary to find out when the Robot Cleaner did the cleaning. Cleaning Diary records information such as date, mode, and the start and completion times of each cleaning. Click Play button on the right of the completed cleaning list; an active cleaning map of that particular cleaning event will appear.
- Page 40 Be sure to resolve any issue identified in the diagnosis by taking a corresponding measure. If the symptom persists, contact the customer service center of LG Electronics. • Smart Diagnosis on the application provides the same function as that of the remote control.
- Page 41 SMART APPLICATION FUNCTION Menu – Setting You can check or change the current information set up on Robot Cleaner. Click Voice gender to change the voice of the Robot Cleaner to male or female. Click Product nickname to change the current nickname of the Robot Cleaner; a pop-up where you can enter a new nickname opens (up to 10 characters allowed including English, Korean and numeric).
- Page 42 SMART APPLICATION FUNCTION Misc. 1 - Software update The network-enabled model of the Robot Cleaner can update the software automatically via the application. 1. Make sure that the "Smart ThinQ" application is up to date on the Play Store.(Unless you update the app to the latest version, software update will not be available.) 2.
- Page 43 SMART APPLICATION FUNCTION Misc. 2 - Mode You can order to robot cleaner simply without connection with robot cleaner through Mode function. Mode function has total 4 functions. If you push ‘ A pplied’ button, Robot cleaner will act according to Mode like below.
-
Page 44: Product Info Initialization
3. Pressing "Start/Stop" again will turn Robot Cleaner on with a melody. ※ Any dispute between seller and buyer is an issue between the two parties. LG Electronics provides a product initialization function for smooth transaction. • Initialization returns the following information as factory default setting. -
Page 45: Cleaning The Dust Bin
CLEANING THE DUST BIN If the dust bin is full, suction power can be reduced. Clean the dust bin before or after each cleaning session. Clean the dust bin using the following sequence: 1. Open the dust bin compartment cover by pressing the PUSH button on the Robot Cleaner. -
Page 46: Cleaning The Dust Bin Filter
CLEANING THE DUST BIN FILTER The Dust Bin Filter consists of a EPA Filter and Sponge Filter. Clean both the EPA and Sponge filters as per the following sequence. 1. Pull the hook on the left of the EPA Filter module on the rear side of Dust Bin to separate the EPA Filter and the sponge. -
Page 47: Cleaning The Brush
CLEANING THE BRUSH The rotating Brush, located on the bottom of Robot Cleaner, helps collect the dust. Clean the Brush as per the following sequence. ※ Before turning over the main unit, lay a soft cloth on the floor and remove the Dust Bin. Otherwise, the main unit can get scratched and dust will fall from the Dust Bin. -
Page 48: Cleaning The Sensor/Charging Terminal
CLEANING THE SENSORS/CHARGING TERMINALS There are sensors on the Robot Cleaner that detect obstacles, stairways and the home station for charging the battery. In order to maintain the performance of the Robot Cleaner, regularly clean the sensors and charging terminals as follows: 1. -
Page 49: Cleaning The Side Brush
CLEANING THE SIDE BRUSH Foreign objects/materials such as hair can easily adhere to the side brush. Remove such materials at least once a week. If excessive amounts of foreign materials are stuck to the brush, there is the risk of damage to the brushes. If the floor is rough or frequently cleaned, the side brushes may bend or become deformed. -
Page 50: Cleaning The Ultra Microfiber Mop (Option)
※ If the Mop is used in a damp or wet state, it will cause the Robot Cleaner to malfunction. • To avoid product malfunction, only use the ultra microfiber mop provided with the Robot Cleaner. • Additional microfiber mops can be purchased by visiting a nearby LG Electronics service center. -
Page 51: Troubleshooting
TROUBLESHOOTING Upon a voice message, "The wheels are not touching the floor. Please move Roboking onto flat floor." A warning message will be given if a wheel does not contact the floor surface for any reason. • Is a wheel trapped in the front door, balcony, stairway, etc? s Move the Robot Cleaner on to the flat floor. - Page 52 TROUBLESHOOTING Upon a voice message, "Please check if the dust bin is installed with the filter." A warning message will be given if there is no Dust Bin or Filter housing fitted. • Is the Dust Bin fitted to the Robot Cleaner? s Open the Dust Bin compartment cover and check to ensure the Dust Bin is in place.
- Page 53 TROUBLESHOOTING Upon a voice message, "Please remove foreign material from the brushes on the bottom." A warning message will be given if foreign materials restrict the Brush's rotation. Turn off the main power switch on the rear of the Robot Cleaner. Lay a soft cloth on the floor and put the Robot Cleaner upside down on it.
-
Page 54: Before You Call For Service
BEFORE YOU CALL FOR SERVICE Confirm before reporting the failure of Robot Cleaner. Problem Solutions (Reference page) The power supply cannot be Check that the power switch is turned on. (Page 16) turned on. The power supply This is not a failure. Robot Cleaner has its own power saving automatically turns off. -
Page 55: Reference Items
REFERENCE ITEMS Open source software notice To obtain the source code under GPL, LGPL, MPL and other open source licenses, that is contained in this product, please visit http://opensource.lge.com. In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. - Page 56 [IEC 62929 Standard] Setting for Cleaning Performance Test Dust Removal Test - Box(Hard Floor & Carpet) 1. Put fully charged Robot Cleaner down on start point and turn on. 2. Push ‘TURBO’ button on the Robot Cleaner or ‘Turbo’ button on the Remote Controller and Robot Cleaner will be set Turbo Mode.
