Product Overview
Instruction manual | Bedienungsanleitung | Notice d'emploi |
Istruzioni per l'uso | Instrucciones de manejo | Manual de
instruções | Gebruiksaanwijzing | Instrukcja obsługi |
Bruksanvisning | Betjeningsvejledning | Käyttöohje | Οδηγίε
λειτουργία | Kullanım kılavuzu |
使用说明书 | 使用說明書 | 取扱説明書 |사용 설명서 |
www.neumann.com | KH 120
Acoustics
-3 dB free field frequency response
Pass band free field frequency response
Self-generated noise (with input gain set to 100 dB for 0 dBu)
Total harmonic distortion < 0.5 % at 95 dB SPL at 1 m
Max. SPL in full space / calc. in half space at 3 % THD
at 1 m, averaged between 100 Hz and 6 kHz
Bass capability: Max. SPL in half space with 3 % THD at 1 m,
averaged between 50 Hz and 100 Hz
Max. short term SPL with IEC-weighted noise
(IEC 60268-5) at 1 m, in typical listening conditions
Max. short term SPL with music material at 2.3 m,
in typical listening conditions (pair)
Max. long term SPL with pink noise at 2.3 m,
in typical listening conditions (single/pair)
Electronics
Woofer amplifier, continuous (peak) output power
Tweeter amplifier, continuous (peak) output power
Controller design
Crossover frequency; crossover slope
Analog input
Input type
Input gain control (sensitivity)
Maximum input level
Product properties
Power consumption (idle)
Power consumption (full output AC)
Dimensions (H x W x D)
Weight
Drivers – woofer, tweeter
Threaded inserts for Neumann mounting hardware
Cabinet surface finish, Color
A complete list of specifications can be found on the product page at www.neumann.com.
|
52 Hz to 21 kHz, ±3 dB
54 Hz to 20 kHz, ±2 dB
<20 dB(A) at 10 cm
>100 Hz
105.1 dB SPL / 111.1 dB SPL
104.8 dB SPL
107 dB(C) SPL
97 dB(C) SPL (full range)
104 dB(C) SPL (with subwoofer)
88/93 dB(C) SPL (full range)
89/94 dB(C) SPL (with subwoofer)
50 W (80 W), THD and noise < 0.1 %
with deactivated limiter
50 W (80 W), THD and noise < 0.1 %
with deactivated limiter
analog, active
2.0 kHz; 24 dB/oct., 4th order
BASS: 0, -2.5, -5, -7.5 dB
LOW-MID: 0, -1.5, -3, -4.5 dB
TREBLE: +1, 0, -1, -2 dB
XLR, electronically balanced
0 dB to -15 dB
94, 100, 108, 114 dB SPL
24 dBu (ANALOG mode)
18 dBu (ANALOG DELAYED mode)
100 to 240 V~, 50/60 Hz
20 W
200 W
277 x 182 x 220 mm (107/8" x 71/8" x 85/8")
6.4 kg (14 lbs 2 oz)
magnetically shielded – 130 mm (5.25"), 25 mm (1")
2 x M8 on rear panel with depth 15 mm (5/8")
painted aluminium, Anthracite (RAL 7021)
or White (9016) or other RAL color
( )
/
Block diagram
XLR: Analog
GND Lift
Fine
Coarse
0
Gain
-2.5
-5.0
-7.5
Bass
Installation angles
3
3
0
0
°
°
6
6
0
0
°
°
9
9
0
0
°
°
1
1
2
2
0
0
°
°
1
1
5
5
0
0
°
°
A
N
-
L
Quick Guide
Kurzanleitung
Guide rapide
Guida rapida
Guía de inicio rápido
Guia rápido
Beknopte handleiding
Krótka instrukcja obsługi
Snabbguide
Kort vejledning
Pikaohje
Γρήγορος οδηγός
Kısa Kılavuz
Краткая инструкция
简要说明
快速使用指南
クイックガイド
요약 안내서
·
.
·
·
- ·
-
·
@
.
·
.
.
Power on
Display Dimmer On/O
and Bright/Dim
Cross-
Production
Over
Limiters
Trimmers
(24 dB/
oct)
0
+1
-1.5
0
-3.0
-1
-4.5
-2
Low Mid
Treble
0
0
°
°
3
3
0
0
°
°
1
1
8
8
0
0
°
°
1
1
5
5
0
0
°
°
Mute
Power
Amps
Treble
Bass
6
6
0
0
°
°
9
9
0
0
°
°
1
1
2
2
0
0
°
°
