Electro-Harmonix nano SMALL STONE Manual page 2

- POWER -
Power from the internal 9-volt battery is activated by plugging into the
INPUT jack. The input cable should be removed when the unit is not in use
to avoid running down the battery. If a battery eliminator is used, the Nano
Stone will be powered up as long as a wall-wart is plugged into the wall.
The barrel connector on the front of the Nano Stone is for a 9-volt battery
eliminator capable of delivering 100 mA of current. The inner ring of the 9-
volt battery eliminator must be negative, the outer ring positive. The unit's
battery may be left in or taken out when the eliminator is in use.
To change the 9-volt battery, you must remove the 4 screws on the bottom
of the Nano Stone. Once the screws are removed, you can take off the
bottom plate and change the battery. Please do not touch the circuit board
while the bottom plate is off or you risk damaging a component.
The input impedance presented at the Input Jack is 100 k-ohms. The output
impedance at the Output Jack is 15 k-ohms.
- WARRANTY INFORMATION -
Please register online at http://www.ehx.com/product-registration or complete and
return the enclosed warranty card within 10 days of purchase. Electro-Harmonix will
repair or replace, at its discretion, a product that fails to operate due to defects in
materials or workmanship for a period of one year from date of purchase. This
applies only to original purchasers who have bought their product from an authorized
Electro-Harmonix retailer. Repaired or replaced units will then be warranted for the
unexpired portion of the original warranty term.
If you should need to return your unit for service within the warranty period, please
contact the appropriate office listed below. Customers outside the regions listed
below, please contact EHX Customer Service for information on warranty repairs at
info@ehx.com or +1-718-937-8300. USA and Canadian customers: please obtain a
Return Authorization Number (RA#) from EHX Customer Service before returning
your product. Include with your returned unit: a written description of the problem
as well as your name, address, telephone number, e-mail address, and RA#; and a
copy of your receipt clearly showing the purchase date.
United States & Canada
EHX CUSTOMER SERVICE
ELECTRO-HARMONIX
c/o NEW SENSOR CORP.
55-01 2ND STREET
LONG ISLAND CITY, NY 11101
Tel: 718-937-8300
Email: info@ehx.com
Europe
JOHN WILLIAMS
ELECTRO-HARMONIX UK
13 CWMDONKIN TERRACE
SWANSEA SA2 0RQ
UNITED KINGDOM
Tel: +44 179 247 3258
Email: electroharmonixuk@virginmedia.com
This warranty gives a purchaser specific legal rights. A purchaser may have even
greater rights depending upon the laws of the jurisdiction within which the product
was purchased.
To hear demos on all EHX pedals visit us on the web at www.ehx.com
Email us at info@ehx.com
