DCCconcepts Cobalt Alpha Series Manual page 4

Mains Power ON-OFF switch
Regulated DC 18v output
Cobalt
Power - Smooth well regulated power for perfect performance!
Its not commonly understood, but even those digital systems that show the use of AC power supplies in the manual actually
run on DC internally... and what you may also not know is that while AC power supplies may be lower cost, they also give
ZERO protection from inevitable voltage Surges and level changes, increasing the possibility of system damage!
So - using AC power makes little sense in reality - Especially as all involved in digital electronics agree that the quality of pow-
er supply that you choose will, more than any other factor, dictate the eventual performance of your model railway, because
best cause problems with communication and may, in the extreme, actually damage your precious decoders and other items.
It just makes good sense to use a top quality, properly regulated DC power supply.
Cobalt
18v at the input terminals of your DCC system, Cobalt
Using a different brand of control system or booster - it doesn''t matter! While we have "design matched" Cobalt
our Cobalt range, it has also been tested with all main DCC brands from "Starter sets" to full-feature 5amp systems, and
it consistently gives excellent results with all of those brands.
Cobalt Power - Pack contents:
• 1x Cobalt Power unit
• 1x Mains connection cord (Adapters for your country automatically supplied)
• 1x Power output connector with bare wire ends
• 1x Power output connector DC input plug for all Cobalt
• 1x Instruction Manual
Linking the Cobalt
Cobalt Central, Cobalt
to make it possible to link them together visually in-line and create a neat, tidy and professional look.
to make it easy to "tilt" the units to make a sloping front panel. All you need to do is cut a length of 1.1~1.2mm alloy or
plasticard to the width you want it to be and insert it into the groove to create the appearance you are looking for!
PLEASE NOTE: In some cases, the images used in this manual are of prototype or pre-production units and may vary slightly in appearance
from those actually on sale. However in all cases all of the connections and diagrams are identical and the information given is correct.
Central or similar digital device.
Range & creating a "Tilted Panel" look.
Box and Cobalt Power share a common case extrusion AND have recessed end plates
Overload reset Switch (hold for 3 seconds)
products.
page 5
Power-on LED
Power to
