Stacking kit
A special stacking kit is available through your
dealer, to enable the mounting of the dyer on top
of a front loading washing machine with cover's
depth between 48 and 60 cm.
Read carefully the instructions supplied with the kit.
Door reversal
To make it easier to load or unload the laundry
the door can be reversed.
Reversing the door is not possible if installed
behind a door that opens in the opposite
direction.
Important:
This operation must be carried out by qualified
personnel.
Please contact the nearest Service Centre.

Electrical connection

Any electrical work required to install this
appliance should be carried out by a qualified
electrician or competent person.
WARNING:
THIS APPLIANCE MUST BE EARTHED.
The manufacturer declines any liability
should this safety measure not be observed.
20
10:33 Page 20
The manufacturer declines any responsibility
for damage or injury through failure to
comply with the above safety precaution.
Should the appliance power supply cable
need to be replaced, this must be carried out
by our Service Centre.
Should the appliance power supply cable
need to be replaced, this must be .carried out
by our Service Center.
Before switching on, make sure the electricity
supply voltage is the same as that indicated on
the appliance's rating plate.
The appliance is supplied with a 13amp plug
fitted.
In the event of having to change the fuse in the
plug supplied, a 13amp ASTA approved (BS1362)
fuse must be used.
Should the plug need to be replaced for any
reason, proceed as described below.
The wires in the mains lead are coloured in
accordance with the following code:
Green and Yellow
Blue
Brown
The plug must be accessible after the
appliance has been installed.
Important:
Important:
- Earth
- Neutral
- Live
