Description of the appliance

1 Control panel
2 Fluff filters
3 Rating Plate
4 Consenser Unit
5 Water reservoir
6 Adjustable feet

Controls panel and their functions

PROGRAMME TIME
SELECTOR DIAL
10:32 Page 5
Allows you to select electronically controlled or time controlled
drying.
Turn the dial to the required programme or time.
3
5
6
1
2
4
5
