Cleaning the condenser unit

1.Clean the condenser when the
light condenser comes on.
The condenser is situated at the
lower part of the cabinet behind a
small door. To open the door, push
the catch as per picture.
During the drying cycle or at the end, it
is normal for water to be present on the
surface of the condenser insertion.
4. Clean the rubber seal round the
condenser cabinet and in the inner
part of the small door with a damp
cloth.

Emptying the water reservoir

Important:
Water extracted from the laundry condenses inside the machine and is collected in a reservoir.
The reservoir must be emptied after each drying cycle to ensure efficient operation when the machine is
next used. The pilot light
Proceed as follows:
14
10:33 Page 14
2. To pull out the condenser, first
turn the two red stops downwards.
Important:
Do not use pointed objects or
utensils to clean the spaces
between the plates, as this
could damage the condenser
and make it permeable.
Re-fit the condenser, turn the red
stops upwards and close the door.
Empty Tank
reminds you of this operation.
3. Then remove the condenser unit
holding it at the handle.
Important:
Do not use this appliance if the
condenser has not been fitted.
