Figure 23 Virtual Keyboard

(5) Enter the password for the Wi-Fi network using the Left/Right arrow keys to
select characters followed by the OK key to add the character to the
password. When finished use the Left arrow key to select the ACCEPT
button and press the OK key to confirm the password.
Note: Press up arrow key changes to uppercase letters. Press down arrow key to
revert to lower case.
(6) Press the down arrow key and select the Connect button. Then press the OK
key. The SBB shall attempt to connect to the Wi-Fi network and if successful
"Connected" shall be displayed at the top of screen. If unsuccessful,
Disconnected shall be displayed.
Note: If the SBB does not connect, please repeat the above steps and confirm
the information entered is correct.
(7) Press the EXIT key twice to exit the hidden setup screens. The SBB will then
proceed to boot as described in section 7.1.
Hidden Network
(1) Confirm what SSID (network name) and password is to be used by Foxtel at the
property, plus the security used (None, WEP, WPA2-PSK, WPA-PSK).
(2) Set Configuration to Manual in Wi-Fi setup screen (if it is not already) by pressing
OK on Configuration, using the right-arrow key to select Manually and then
pressing OK to confirm the selection.
(3) Navigate down to Security and press OK. Use the right/left arrow key to select
the desired Wi‐Fi security option (None, WEP, WPA2‐PSK, WPA‐PSK) and press
the OK key to confirm.
(4) Navigate down to Manual (SSID) and press OK to display the virtual keyboard in
Figure 23.
(5) Enter the network name (SSID) for the Wi-Fi network using the Left/Right arrow
keys to select characters followed by the OK key to add the character to the
SSID. When finished use the Left arrow key to select the ACCEPT
button and press the OK key to confirm the password.
Note: Press up arrow key changes to uppercase letters. Press down arrow key to
revert to lower case.
(6) Navigate down to Password and press OK, which shall again display the virtual
keyboard in Figure 23 again.
(7) Enter the password for the Wi-Fi network using the Left/Right arrow keys to
select characters followed by the OK key to add the character to the
password. When finished use the Left arrow key to select the ACCEPT
button and press the OK key to confirm the password.
Note: Press up arrow key changes to uppercase letters. Press down arrow key to
revert to lower case.
(8) Press the down arrow key and select the Connect button. Then press the OK
key. The SBB shall attempt to connect to the Wi-Fi network and if successful
"Connected" shall be displayed at the top of screen. If unsuccessful,
Disconnected shall be displayed.
