Rotronic HygroFlex HF8 User Manual

Humidity temperature transmitter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
E-M-HF8-V2_13
Document code
HygroFlex HF8 Humidity Temperature
Transmitter: User Guide
Document title
Humidity Temperature Transmitter
© 2012-2013; Rotronic AG
HygroFlex HF8
User Guide
Rotronic AG
Bassersdorf, Switzerland
Unit
Instruction Manual
1 of 37
Page
E-M-HF8-V2_20
Document Type

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HygroFlex HF8 and is the answer not in the manual?

Questions and answers

Related Manuals for Rotronic HygroFlex HF8

Summary of Contents for Rotronic HygroFlex HF8

  • Page 1 Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 1 of 37 Page Document title HygroFlex HF8 Humidity Temperature Transmitter User Guide © 2012-2013; Rotronic AG E-M-HF8-V2_20...

  • Page 2: Table Of Contents

    Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 2 of 37 Page Document title Table of contents Overview .............................. 3 Dimensional drawings ........................4 General description ..........................4 Power supply options ........................4 Probe inputs .............................

  • Page 3: Overview

    Document title Applicability: This manual applies to all instruments of the HygroFlex HF8 series with firmware version 2.x, where 2.x can be 2.0, 2.1, etc. Changes to the last digit of the version number reflect minor firmware changes that do not affect the manner in which the instrument should be operated.

  • Page 4: Dimensional Drawings

    Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 4 of 37 Page Document title Dimensional drawings Dimensions in mm General description Power supply options The HF8 can be ordered with different power supply options. Please verify the product identification label to determine which power supply option is installed on your transmitter.

  • Page 5: Probe Inputs

    The HF8 has two probe inputs. Probe input 1 is the input that is the closest to the front of the transmitter (see picture) Using the ROTRONIC HW4 software (Device Manager), each probe input can be configured to accept one of the following: HygroClip 2 humidity-temperature digital probe.

  • Page 6: Measured Parameters

    ROTRONIC HW4 software. Custom Calculations The ROTRONIC HW4 software version 3.2.0 or higher is required for setting up custom calculations and a service cable is required to connect the HF8 to a PC running the HW4 software.

  • Page 7: Real Time Clock

    All 4 analog outputs of the HF8 provide the same type of signal: 0…20 mA or 4…20 mA or 0…1V or 0…5V or 0…10V. The type of analog signal can be selected globally for all outputs after connecting the HF8 service connector to a PC running the ROTRONIC HW4 software. No adjustment is required after changing the type of output signal.

  • Page 8: Optional Display And Keypad

    The HF8 uses the RO-ASCII communications protocol. This protocol is not compatible with the protocol used by the previous generation of ROTRONIC instruments and by the HygroLog HL-NT data logger. Do not connect legacy products or the HL-NT data logger to the same RS-485 multi-drop network as the HF8 transmitter.

  • Page 9: Audible Alarm (Beeper)

    The service connector is a UART digital interface (Universal Asynchronous Receiver Transmitter) with a mini- USB type connector. This allows connecting the HF8 with a service cable to a PC running the ROTRONIC HW4 software. See “Maintenance” for the location of the service connector and for the type of service cable to be used.

  • Page 10: 3.13 Hw4 Software Compatibility

    Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 10 of 37 Page Document title 3.13 HW4 Software compatibility The HF8 is best used with HW4 version 3.2.0 or higher.

  • Page 11: Interaction Between The Hf8 And Hygroclip 2 Probe Functions

    Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 11 of 37 Page Document title MEASUREMENT LOOP VALIDATION Function Description ► Simulator mode Used to make the HF8 generate fixed values for the humidity, temperature and calculated parameter.

  • Page 12: Configuration Of The Analog Output Signal Type

    The HC2 probe settings have no effect on the HF8 Configuration of the analog output signal type The type of analog output signals generated by the HF8 can be configured with the ROTRONIC HW4 software after connecting the HF8 with a service cable to a PC running HW4.

  • Page 13: Hf8 Enclosure

    Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 13 of 37 Page Document title Immerse as much of the probe as possible in the environment to be measured. Prevent the accumulation of condensation water at the level of the sensor leads. Install the probe so that the probe tip is looking downward.

  • Page 14: Electrical Installation

    When planning an installation, the rules provided by EN 50170 should be followed under consideration of local circumstances to determine the position of machines and equipment. All ROTRONIC products are tested for Electromagnetic Compatibility according to EMC Directive 2004/106/EG and following European standards:...

  • Page 15: Guidelines For Rs-485 Wiring

    Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 15 of 37 Page Document title • Bus signals such as RS485 • Data signals for PCs, printers etc. • shielded analog inputs •...
  • Page 16 This resistance should not exceed 500 ohms. Operation of the HF8 does not require all current loops to be closed. Using the ROTRONIC HW4 software, any unused output of the HF8 can be disabled.
  • Page 17 Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 17 of 37 Page Document title HF8 relay contacts © 2012-2013; Rotronic AG E-M-HF8-V2_20...
  • Page 18 Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 18 of 37 Page Document title 6.4.2 Terminal block diagram (all models) Terminal Blocks K1 and K2 (analog outputs) Description K1-1: GND Output signal 1 (-) see also 6.4.3...
  • Page 19 Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 19 of 37 Page Document title Terminal Block K3 (RS-485) Description K3-1: V+ VDC (+), when HF8 is powered from RS-485 data cable...
  • Page 20 Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 20 of 37 Page Document title Terminal Block K8 (Relay 2) Description K8-1: NC Normally closed (relay not energized) K8-2: COM...

  • Page 21: Operation

    Operation Analog outputs Use the ROTRONIC HW4 software to configure the HF8 as desired, complete the mechanical and electrical installation, connect the probe and simply power up the HF8. Digital interface The HF8 uses the RO-ASCII communications protocol and does not offer any other option.
  • Page 22 RS-485 Compatibility: The HF8 uses the RO-ASCII communications protocol. This protocol is not compatible with the protocol used by both the previous generation of ROTRONIC products and by the HygroLog HL-NT data logger. Do not connect legacy products or the HL-NT data logger to the same RS- 485 network as HF8.

  • Page 23: Optional Display And Keypad

    Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 23 of 37 Page Document title Optional display and keypad 7.3.1 Display modes The LC display has a backlight which can be set to be on all the time or whenever a key is pressed. The backlight can also be disabled.
  • Page 24 Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 24 of 37 Page Document title 7.3.2 Keypad MENU Activates the internal menu. Press this ENTER key again to go back to the previous sub-...
  • Page 25 Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 25 of 37 Page Document title Submenu Selections or Main Menu Menu Items Notes Items Information Device Settings Display Trend ON / OFF...
  • Page 26 Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 26 of 37 Page Document title Submenu Selections or Main Menu Menu Items Notes Items Information Probe 1 Info Serial Nbr...

  • Page 27: Frequently Used Settings

    Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 27 of 37 Page Document title Submenu Selections or Main Menu Menu Items Notes Items Information Data Logging Recording (ON /...

  • Page 28: Data Logging Function

    Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 28 of 37 Page Document title menu, use the [+] or [-] key to select the calculated parameter. Press ENTER to confirm and press MENU to exit.

  • Page 29: Relay Contacts

    Service cable Cable AC3006 is used to connect the HF8 to a USB port of a PC running the ROTRONIC HW4 software. Prior to connecting the HF5 to a USB port you must install the ROTRONIC USB driver on the PC (available from the HW4 CD or from www.rotronic-humidity.com).

  • Page 30: Periodic Calibration Check Of The Hygroclip 2 Probe

    Long term stability of the ROTRONIC Hygromer humidity sensor is typically better than 1 %RH per year. For maximum accuracy, calibration of the probe should be verified every 6 to 12 months. Applications where the probe is exposed to significant pollution may require more frequent verifications.
  • Page 31 Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 31 of 37 Page Document title 8.4.2 Calibration against a reference environment The HF8 can be used to do a 1-point or multi-point calibration of up to two probes against a known reference environment.

  • Page 32: Cleaning Or Replacing The Probe Dust Filter

    HEX. Procedure for updating the firmware: • Use cable AC3006 to connect the service port of the HF8 to a USB port of a PC with the ROTRONIC HW4 software installed. Note that the ROTRONIC USB driver must be installed on the PC as explained in the HW4 manual E-M-HW4v3-Main.

  • Page 33: Technical Data

    Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 33 of 37 Page Document title Technical data 10.1 Specifications General Humidity temperature transmitter with analog output signals Device type Optional relay outputs...
  • Page 34 Document title Output 1 Can be made to correspond to any parameter and probe Parameter User configurable with the ROTRONIC HW4 software Scale User configurable with the ROTRONIC HW4 software Output 2 Can be made to correspond to any parameter and probe...

  • Page 35: 10.2 Dew Point Accuracy

    Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 35 of 37 Page Document title Digital interface options Interface options RS-485 USB and RS-485 Ethernet (wired) and RS-485 Ethernet with PoE...

  • Page 36: Supporting Documents

    E-M-TCPIP-Conf with Ethernet (TCP/IP) interface Temperature and humidity calibration basics E-M-CalBasics Instructions for using the ROTRONIC humidity standards E-T-HumiDefs Humidity Definitions Note: All document file names have an extension corresponding to the document release number. This extension is not shown in the above table.

  • Page 37: Document Releases

    Rotronic AG E-M-HF8-V2_13 Bassersdorf, Switzerland Document code Unit HygroFlex HF8 Humidity Temperature Instruction Manual Transmitter: User Guide Document Type 37 of 37 Page Document title Document releases Doc. Release Date Notes Nov. 14, 2012 Original release Page 19: the HF8 is now being shipped with the protective...
