Summary of Contents for Rotronic HygroFlex TF5
- Page 1 Rotronic AG E-M-TF5-V1_21 Bassersdorf, Switzerland Document code Unit HygroFlex TF5 Temperature Transmitter: Instruction Manual User Guide Document Type 1 of 23 Page Document title HygroFlex TF5 Temperature Transmitter User Guide © 2015; Rotronic AG E-M-TF5-V1_21...
-
Page 2: Table Of Contents
Rotronic AG E-M-TF5-V1_21 Bassersdorf, Switzerland Document code Unit HygroFlex TF5 Temperature Transmitter: Instruction Manual User Guide Document Type 2 of 23 Page Document title Table of contents Overview .............................. 3 Dimensional drawings ........................4 Display and keypad option ....................... 4 General description .......................... -
Page 3: Overview
The TF5 features a robust housing. Digital signal processing ensures consistent product performance and also facilitates the task of field maintenance with features such as potentiometer free – digital calibration. Based on the ROTRONIC AirChip 3000 digital technology the TF5 series offers the following functions: •... -
Page 4: Dimensional Drawings
Rotronic AG E-M-TF5-V1_21 Bassersdorf, Switzerland Document code Unit HygroFlex TF5 Temperature Transmitter: Instruction Manual User Guide Document Type 4 of 23 Page Document title Dimensional drawings Models with USB or Ethernet interface Dimensions in mm Display and keypad option The LC display option for the TF53 has a backlight. -
Page 5: General Description
External Pt100 RTD probe and probe connector The TF5 is equipped with a 4-pin Binder connector series 712 and is compatible with any of the ROTRONIC Pt100 RTD probes (see separate manual E-M-Pt100-Probes). In principle, the TF5 can be used with any third... -
Page 6: Analog Output Signal (Tf52 And Tf53)
The analog signal is always 4…20 mA, TF53 The ROTRONIC HW4 software allows changing the type of output signal to one of the following: 0…20 mA, 4…20 mA, 0…1V, 0…5V or 0…10V. No calibration or adjustment is required after changing the type of output signal. -
Page 7: Service Connector
The service connector is a UART digital interface (Universal Asynchronous Receiver Transmitter) with a mini- USB type connector. This allows connecting the TF5 either to a PC running the ROTRONIC HW4 software or to a probe input of another instrument that is compatible with the HygroClip 2 (HC2) probes. In both cases a service cable is required. -
Page 8: Function Overview
Rotronic AG E-M-TF5-V1_21 Bassersdorf, Switzerland Document code Unit HygroFlex TF5 Temperature Transmitter: Instruction Manual User Guide Document Type 8 of 23 Page Document title Function overview MEASUREMENT ACCURACY AND RELIABILITY AirChip 3000 Functions Description ► Temperature adjustment o 1-point or 2-point temperature calibration or adjustment... -
Page 9: Factory Default Settings
Factory default settings Notes: o Configuration of the TF5 by the user and access to its functions requires a PC with the ROTRONIC HW4 software (version 2.1.1 or higher) installed. Service cable AC3006 or AC3009 is used to connect the TF5 service connector to a USB port of the PC. - Page 10 Rotronic AG E-M-TF5-V1_21 Bassersdorf, Switzerland Document code Unit HygroFlex TF5 Temperature Transmitter: Instruction Manual User Guide Document Type 10 of 23 Page Document title Functions Applicability Factory default Temperature adjustment TF52, TF53 Device write protection TF52, TF53 Disabled Menu access from keypad...
-
Page 11: Mechanical Installation
Rotronic AG E-M-TF5-V1_21 Bassersdorf, Switzerland Document code Unit HygroFlex TF5 Temperature Transmitter: Instruction Manual User Guide Document Type 11 of 23 Page Document title Mechanical installation General guidelines Relative humidity is extremely dependent on temperature. Proper measurement of relative humidity requires that the probe and its sensors be at exactly the temperature of the environment to be measured. -
Page 12: Electrical Installation
When planning an installation, the rules provided by EN 50170 should be followed under consideration of local circumstances to determine the position of machines and equipment. All ROTRONIC products are tested for Electromagnetic Compatibility according to EMC Directive 2004/106/EG and following European standards:... -
Page 13: Cable Grip And Cable Specifications
Rotronic AG E-M-TF5-V1_21 Bassersdorf, Switzerland Document code Unit HygroFlex TF5 Temperature Transmitter: Instruction Manual User Guide Document Type 13 of 23 Page Document title Lightning protection Cabling in areas with a risk of lightning requires a lightning protection. For cabling underground in between buildings, we recommend the use of special fiber optic cables. - Page 14 Rotronic AG E-M-TF5-V1_21 Bassersdorf, Switzerland Document code Unit HygroFlex TF5 Temperature Transmitter: Instruction Manual User Guide Document Type 14 of 23 Page Document title Note: connect the + of the power supply to only one of the V+ terminals. The two terminals marked V+ are internally connected.
- Page 15 Rotronic AG E-M-TF5-V1_21 Bassersdorf, Switzerland Document code Unit HygroFlex TF5 Temperature Transmitter: Instruction Manual User Guide Document Type 15 of 23 Page Document title Terminals Description Power supply (-) or neutral K1-1: GND (tied with other GND) Power supply: 15…40 VDC (+) K1-2: V+ or 12…28 VAC (Phase)
-
Page 16: Minimum Load Requirements For The Tf53 With Voltage Outputs
Rotronic AG E-M-TF5-V1_21 Bassersdorf, Switzerland Document code Unit HygroFlex TF5 Temperature Transmitter: Instruction Manual User Guide Document Type 16 of 23 Page Document title Operation Minimum load requirements for the TF53 with voltage outputs The following requirements apply to any external device or circuit connected to the TF53 transmitter with... -
Page 17: Tf52 And Tf53 Transmitters (Analog Outputs)
TF5. USB network connection Prior to connecting the TF55 to a USB port you must install the ROTRONIC USB driver on the HW4 PC. For instructions see the HW4 manual E-M-HW4v2-Main (§ 6.3) Internal menu (optional keypad and display) Note: Unauthorized access to the menu can be prevented by disabling the “display menu”... -
Page 18: Maintenance
Service cable • Cable AC3006 is used to connect the TF5 to a USB port of a PC running the ROTRONIC HW4 software. • As an alternative, cable AC2001 is used to connect the TF5 to a probe input of the HP23 hand-held calibrator. -
Page 19: Firmware Updates
Use cable AC3006 to connect the service connector of the TF5 to a USB port of a PC with the HW4 software installed. Note that the ROTRONIC USB driver must be installed on the PC as explained in the HW4 manual E-M-HW4v2-Main. -
Page 20: Technical Data
Rotronic AG E-M-TF5-V1_21 Bassersdorf, Switzerland Document code Unit HygroFlex TF5 Temperature Transmitter: Instruction Manual User Guide Document Type 20 of 23 Page Document title Technical data Specifications General TF52 TF53 Device type Humidity temperature transmitter with analog output signals Circuit type... - Page 21 Rotronic AG E-M-TF5-V1_21 Bassersdorf, Switzerland Document code Unit HygroFlex TF5 Temperature Transmitter: Instruction Manual User Guide Document Type 21 of 23 Page Document title Configurable analog outputs TF52 TF53 Output 1 Not used Output 2 Temperature Factory default scale As per ordering code 0…20 mA...
-
Page 22: Accessories
Rotronic AG E-M-TF5-V1_21 Bassersdorf, Switzerland Document code Unit HygroFlex TF5 Temperature Transmitter: Instruction Manual User Guide Document Type 22 of 23 Page Document title Conformity with standards TF52 TF53 EMC Directive 2004/108/EG: EN 61000-6-1: 2001, EN 61000-6-2: 2005 CE / EMC immunity... -
Page 23: Document Releases
Rotronic AG E-M-TF5-V1_21 Bassersdorf, Switzerland Document code Unit HygroFlex TF5 Temperature Transmitter: Instruction Manual User Guide Document Type 23 of 23 Page Document title Document File Name Contents E-M-CalBasics Temperature and humidity calibration basics Note: All document file names have an extension corresponding to the document release number (example of a first release: E-M-HW4v2-Main_10).
