Quick Start Guide
Hardware Connections
1
Connect gateway modem (1-a) using
an Ethernet cable.
OR
Connect a DSL splitter (1-b) using the
gray telephone cable.
2
Connect computer using the yellow
Ethernet cable.
3
Connect 3G dongle.
4
Connect phone.
5
Connect the power adapter.
6
Check LEDs.
Internet Setup
IP Address: 192.168.1.1
1/2
WiFi-N/AC VDSL2 4-port Bonding Combo
5
POWER
3
USB
1-a
WAN
ETHERNET
INTERNET
2
4
DSL
1-b
VMG9823-B10A
WAN VoIP IAD
6
VoIP
Username: admin
Password: 1234
Copyright © 2015 ZyXEL Communications Corp. All Rights Reserved
INTERNET
Internet is ready.
Go to Wireless Setup.
ON
INTERNET
Internet is not ready.
Go to Internet Setup.
OFF
VoIP 1/2
VoIP registration is
complete.
ON
VoIP 1/2
OFF
VoIP registration is not complete.
Go to the Web Configurator and
configure VoIP settings.
