TESCOM™ 44-6800 E Series
Electrically Heated Vaporizing Regulator
Installation, Operations and Maintenance Manual
Installation, Operations and Maintenance Manual
Do not attempt to select, install,
use or maintain this product until
you have read and fully understood
this manual.
TR000058ENUS-02_10-20
October 2020
Advertisement
Table of Contents
Related Manuals for Emerson TESCOM 44-6800 E Series
Summary of Contents for Emerson TESCOM 44-6800 E Series
- Page 1 Installation, Operations and Maintenance Manual TR000058ENUS-02_10-20 October 2020 TESCOM™ 44-6800 E Series Electrically Heated Vaporizing Regulator Installation, Operations and Maintenance Manual Do not attempt to select, install, use or maintain this product until you have read and fully understood this manual.
- Page 2 Installation, Operations and Maintenance Manual TR000058ENUS-02_10-20 October 2020 TESCOM™ 44-6800 E Series...
- Page 3 Installation, Operations and Maintenance Manual Content TR000058ENUS-02_10-20 October 2020 Contents Chapter 1 Symbols.........................4 Chapter 2 Safety Precautions and Repair..................4 2.1 44-6800E Series Regulator Safety..................4 Chapter 3 3. Installation, Operations and Maintenance..............7 3.1 General Information......................7 3.1.1. Operating Parameters/Special Conditions For Safe Use..........8 3.2.
- Page 4 Content Installation, Operations and Maintenance Manual October 2020 TR000058ENUS-02_10-20 Symbols WARNING Paragraphs highlighted by the WARNING icon contain information about practices or circumstances that can lead to personal injury or death, property damage or economic loss. CAUTION Paragraphs highlighted by the CAUTION icon contain information that must be followed to maintain a safe and successful operating environment.
- Page 5 Installation, Operations and Maintenance Manual Content TR000058ENUS-02_10-20 October 2020 CAUTION Safety Precautions • Inspect the regulator before each use. • Never connect regulators to a supply source having a pressure greater than the maximum rated pressure of the regulator, valve or accessory. •...
- Page 6 Content Installation, Operations and Maintenance Manual October 2020 TR000058ENUS-02_10-20 • Do not interconnect vent lines; use separate lines if more than one vent is needed. Do not locate regulators, valves or accessories controlling flammable fluids near open flames or any other source of ignition. •...
-
Page 7: General Information
Assembly & installation drawings, Bill of Materials, and parts lists for your product may be obtained by contacting Emerson. Emerson will provide these by email, fax or mail. Your local TESCOM™ sales representative can provide additional assistance. Be sure to have your complete model number ready. - Page 8 Content Installation, Operations and Maintenance Manual October 2020 TR000058ENUS-02_10-20 Operating Parameters/Special Conditions For Safe Use 3.1.1 Maximum Inlet Pressure: 3,500 psig / 241 bar / 24,132 kPa Standard 6,000 psig / 414 bar / 41368 kPa Optional Maximum Outlet Pressure: 500 psig / 34 5 bar / 3,448 kPa Outlet Pressure Ranges: 0-25, 0-50, 0-100, 0-250, 0-500 psig...
-
Page 9: Installation
Installation, Operations and Maintenance Manual Content TR000058ENUS-02_10-20 October 2020 Installation 3.2.1 Installation Precautions WARNING Make sure that the components and materials used in the fluid handling system are compatible with the fluid and have the proper pressure rating. Failure to do so can result in death, serious injury and/or property damage. - Page 10 Content Installation, Operations and Maintenance Manual October 2020 TR000058ENUS-02_10-20 Adjust the temperature with the TRIM1 potentiometer. TRIM1 potentiometer, located on the electrical board, provides a 270° of adjustment. The temperature set point range is from 50 °C /122 °F (fully counter clockwise position) to 400 °C /752 °F (fully clockwise position).
- Page 11 Installation, Operations and Maintenance Manual Content TR000058ENUS-02_10-20 October 2020 Figure 3: Figure 4: Installation, Operations and Maintenance Manual...
-
Page 12: Operation
Content Installation, Operations and Maintenance Manual October 2020 TR000058ENUS-02_10-20 Operation 3.3.1 Regulator Adjustment Controlled outlet pressure settings are obtained using TESCOM™ pressure reducing regulators by adjusting the screw. Rotating the adjustment screw clockwise raises the outlet pressure while a counterclockwise rotation coupled with venting of the downstream side of the regulator plumbing lowers the outlet pressure. - Page 13 The user is responsible for assuring all safety and warning requirements of the application are met through his/her own analysis and testing. c. Emerson may suggest material for use with specific media upon request. Suggestions are based on technical compatibility resources through associations and manufacturers.
- Page 14 Content Installation, Operations and Maintenance Manual October 2020 TR000058ENUS-02_10-20 Mechanical Disassembly Bold letters within the steps indicate component location in Figure 6. The following steps outline the disassembly of pressure reducing regulators for maintenance and repair: a. Clamp the regulator in a vise by the side of the regulator body K. b.
- Page 15 An Assembly Drawing and Bill of Materials for the regulator and heater will be needed to complete maintenance procedures. The assembly drawing and bill of materials are separate from this manual and available by contacting Emerson (see last page for contact information). WARNING...
-
Page 16: Certifications And Warranty
Content Installation, Operations and Maintenance Manual October 2020 TR000058ENUS-02_10-20 Certifications and Warranty Hazardous Location Ratings WARNING-DO NOT OPEN WHEN ENERGIZED OPEN CIRCUIT BEF ORE REMOVING COVER OUVRIR LE CIRCUIT AVANT D'ENLEVER LE COUVERCLE SEE INSTALLATION DOCUMENT 100-240 VAC 400 WATT 50/60 Hz °... -
Page 17: Declaration Of Conformity
Installation, Operations and Maintenance Manual Content TR000058ENUS-02_10-20 October 2020 Declaration of Conformity EU DECLARATION OF CONFORMITY ATEX Directive 2014/34/EU Model Number: 44-6800 Product Name: Vaporizing Regulator Manufacturer’s Name: Tescom Corporation Manufacturer’s Address: 12616 Industrial Boulevard Elk River, Minnesota 55330-2491 United States of America European Contact: TESCOM EUROPE GMBH &... -
Page 18: Limited Warranty
Content Installation, Operations and Maintenance Manual October 2020 TR000058ENUS-02_10-20 Limited Warranty TESCOM™ Corporation (“Seller”) warrants that the licensed firmware embodied in the goods will execute the programming instructions provided by Seller, and that the goods manufactured or services provided by Seller will be free from defects in materials or workmanship under normal use and care until the expiration of the applicable warranty period. - Page 19 Installation, Operations and Maintenance Manual Content TR000058ENUS-02_10-20 October 2020 Installation, Operations and Maintenance Manual...
- Page 20 LinkedIn.com/company/Emerson-Automation-Solutions Twitter.com/EMR_Automation The Emerson logo is a trademark and service mark of Emerson Electric Co. Brand logotype are registered trademarks of one of the Emerson family of companies. All other marks are the property of their respective owners. © 2020 Emerson Electric Co. All rights reserved.
