YarwaY SERiES 400 intEgRAl StRAinERimpulSE
InstructIon, operatIon and maIntenance manual
Before installation these instructions must be fully read and understood
ratINgs
Operating pressure ranges
SERiES 460
SERiES 461
SERiES 441
BaCk prEssurE lIMIts
piston valve traps rated to 400 psig (28 bar)
(incl.) are factory set to operate from 20
psig (1.4 bar) to maximum rated pressure.
maximum allowable back pressure at trap
outlet equals 40% of pressure at trap inlet.
(Based on absolute pressure.)
piston Valve traps rated to 600 psig (42 bar)
(incl.) are factory set to operate from 40
psig (2.8 bar) to 600 psig (42 bar). maximum
allowable back pressure at trap outlet equals
25% of pressure at trap inlet. (Based on
absolute pressure.)
Note: the traps operate over the specified
ranges without adjustment.
piston Valve traps may be adjusted to operate
between 10 psig (.7 bar) and the minimums
stated above by removing the split washer (see
disassembly section.) Back pressures higher
than the percentages stated above will cause
the traps to blow open. Where normal system
back pressures are high, removal of the split
washer will also permit operation against back
pressures up to 55% of pressure at trap inlet.
(Based on absolute pressure.)
Emerson.com/FinalControl
mAX. tEmpERAtuRE (C)
SAtuRAtiOn
CuRVE
All
liQuiD
pHASE
All
SupERHEAt
SERiES 440
mAX. tEmpERAtuRE (F)
Disc valve traps rated to 600 psig (42 bar) (incl.)
operate from 4 psig (.28 bar) to maximum rated
pressure. maximum allowable back pressure
at trap outlet is 60% of pressure at trap inlet.
(Based on absolute pressure.)
sErIEs NuMBErs
to determine the size, series number, and
pressure temperature rating refer to the
nameplate on the trap body.
© 2018 Emerson. All Rights Reserved.
®
VCIOM-09534-EN 18/09

Advertisement

loading
Need help?

Need help?

Do you have a question about the Yarway Integral Strainerimpulse 400 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Emerson Yarway Integral Strainerimpulse 400 Series

  • Page 1 Where normal system back pressures are high, removal of the split washer will also permit operation against back pressures up to 55% of pressure at trap inlet. (Based on absolute pressure.) Emerson.com/FinalControl VCIOM-09534-EN 18/09 © 2018 Emerson. All Rights Reserved.
  • Page 2 YarwaY SERiES 400 intEgRAl StRAinERimpulSE ® InstructIon, operatIon and maIntenance manual suFFIx lEttEr IdENtIFICatION Internal parts rating size end Figure available end psig, °F) connections number piston disc connections (bar, °C) ½" SW, Fl 400-975 (28-524) 400-775 (28-413) SW, Fl 600-975 (42-524) 600-775 (42-413) ¾"...
  • Page 3: Installation

    YarwaY SERiES 400 intEgRAl StRAinERimpulSE ® InstructIon, operatIon and maIntenance manual INstallatION welding - socket welding or seal welding of this trap body to the piping should be piping to and from the trap should be equal to completed according to applicable Codes, trap size or one size larger.
  • Page 4: Maintenance

    YarwaY SERiES 400 intEgRAl StRAinERimpulSE ® InstructIon, operatIon and maIntenance manual MaINtENaNCE dIsassEMBlY FiguRE 2 piston valve type piston valve type Check bonnet nut torque after 48 hours of operation. 1. Remove bonnet and unscrew seat. 1. For best trap operation and maximum 2.
  • Page 5 YarwaY SERiES 400 intEgRAl StRAinERimpulSE ® InstructIon, operatIon and maIntenance manual disc valve type Do not reuse any of the old parts when FiguRE 3 1. Remove bonnet and unscrew seat. installing a new renewal kit. Always use new Disc valve type 2.
  • Page 6 YarwaY SERiES 400 intEgRAl StRAinERimpulSE ® InstructIon, operatIon and maIntenance manual rENEwal kIt - pIstON ValVE tYpE rENEwal kIt - dIsC ValVE tYpE Installing renewal kit - reassembly Installing renewal kit-reassembly 1. Clean sealing surfaces and all internal 1. Clean sealing surfaces and all internal parts.
  • Page 7 Responsibility for proper selection, use, and maintenance of any product remains solely with the purchaser and end user. Yarway is a mark owned by one of the companies in the Emerson Automation Solutions business unit of Emerson Electric Co. Emerson Automation Solutions, Emerson and the Emerson logo are trademarks and service marks of Emerson Electric Co.
