LOW OHM TEST PROBE
LTP-2 
1.

GENERAL

MODEL LTP-2 Low Ohm Test Probe is an optional accessory device
for TOS6100 ( or Model 872) AC Low Ohm Tester. The probe has a
probe-side cable and a clip-side cable. To reduce the residual
resistance in measurement, voltage sampling is done at the root of the
test pin for the probe-side cable and at the root of the clip for the clip-
side cable.
On its main body the probe has START/STOP switches for remote
operation. The functions of the switches are identical with those of the
START/STOP switches of TOS6100 Tester ( or with those of the
TEST/RESET switches of Model 872 Tester).
2.

SPECIFICATIONS

Cable length:
Probe Dimensions:
Residual Resistance:
Remote Operation:
LTP-2
INSTRUCTION MANUAL
Approx. 2m
Dia. approx. 19mm,
Length approx. 150mm
< 10mΩ
START/STOP switches (TEST/RESET switches)
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LTP-2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Kikusui LTP-2

  • Page 1 LOW OHM TEST PROBE LTP-2  INSTRUCTION MANUAL   GENERAL MODEL LTP-2 Low Ohm Test Probe is an optional accessory device for TOS6100 ( or Model 872) AC Low Ohm Tester. The probe has a probe-side cable and a clip-side cable. To reduce the residual resistance in measurement, voltage sampling is done at the root of the test pin for the probe-side cable and at the root of the clip for the clip- side cable. On its main body the probe has START/STOP switches for remote operation. The functions of the switches are identical with those of the START/STOP switches of TOS6100 Tester ( or with those of the TEST/RESET switches of Model 872 Tester). SPECIFICATIONS Cable length: Approx. 2m Probe Dimensions: Dia. approx. 19mm, Length approx. 150mm Residual Resistance: < 10mΩ Remote Operation: START/STOP switches (TEST/RESET switches) LTP-2...
  • Page 2 Be sure to connect or disconnect the pin and clip only when the Tester is not delivering its test output (when the tester is in the READY (RESET) state). LTP-2...
  • Page 3 REMOTE OPERATION SWITCHES Namings of the operation switches differ between the TOS6100 Tester and Model 872 Tester as shown in the below table. The functions of the switches are virtually identical between the Testers. In this instruction manual, the switches of Model 872 Tester are indicated being enclosed in parentheses and the manual is applicable to both Testers. Tester Switch Naming TOS 6100 START STOP MODEL 872 TEST RESET LTP-2...
  • Page 4 The specifications of this product and the contents of this Manual are sub- ject to change without prior notice. © 2001 Kikusui Electronics Corporation Part No. Z1-960-602, IA001092 Printed in Japan KIKUSUI ELECTRONICS CORP.
