- Page 1 Model/modèle : 87795023 MPN2-12ERN1-BH9(H) PORTABLE AIR CONDITIONER Operator's manual Customer Service / Service à la clientèle: 1-866-206-0888 Our Customer service staff is available to help you. For any problem with your purchase, or to receive further information about this product, please call our toll-free number.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY PRECAUTIONS Safety rules ............................2 Operating condition ...........................2 Electrical information .........................3 IDENTIFICATION OF PARTS Accessories ............................3 Names of parts...........................4 AIR CONDITIONER FEATURES Electronic control operating instructions ...................5 OPERATING INSTRUCTIONS .....................6 INSTALLATION INSTRUCTIONS Location ............................8 Window kit installation ........................8 Exhaust hose installation ........................11 Water drainage ..........................12 CARE AND MAINTENANCE... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS Safety rules To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. Always do this Never do this Do not operate your air conditioner in a wet room Your air conditioner should be used in such a way such as a bathroom or laundry room. -
Page 4: Electrical Information
IDENTIFICATION OF PARTS For your safety Do not store or use gasoline or other flammable vapours and liquids in the vicinity of this or any other appliance. Avoid fire hazard or electric shock. Do not use an extension cord or an adaptor plug. Do not remove any prong from the power cord. -
Page 6: Air Conditioner Features
AIR CONDITIONER FEATURES ELECTRONIC CONTROL OPERATING INSTRUCTIONS Before you begin, thoroughly familiarize yourself with the control panel, remote controller and all functions, then follow the symbol for the functions you desire. The unit can be controlled by the unit control panel alone or with the remote controller. OPERATION PANEL OF THE AIR CONDITIONER AUTO MODE... -
Page 7: Operating Instructions
OPERATING INSTRUCTIONS DRY operation Error codes: E1- Room temperature sensor error- Press the "MODE" button until the Unplug the unit and plug it back in. "DRY" indicator light comes on. If error repeats, call for service. Under this mode, you cannot select a E2- Evaporator temperature sensor error- fan speed or adjust the temperature. - Page 8 OPERATING INSTRUCTIONS SLEEP operation Press this button, the set temperature will increase C/2 F in 30 (cooling) or decrease(heating) by 1 minutes.The set temperature will then increase C/2 F (cooling) or decrease (heating) by another 1 after an additional 30 minutes. This new temper- ature will be maintained for 7 hours before it returns to the originally selected temperature.
-
Page 9: Installation Instructions Location
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS Location The air conditioner should be placed on a firm foundation to minimize noise and vibration. For safe and secure positioning, place the unit on a smooth, level floor strong enough to support the unit. The unit has casters for easier transport, but it should only be rolled on smooth, flat surfaces. - Page 10 INSTALLATION INSTRUCTIONS Installation in a double-hung sash window Foam seal A (adhesive type) 1. Cut the foam seal (adhesive type) to the proper length and attach it to the window sill. Fig.10 2. Attach the window slider kit to the window sill. Adjust the Fig.10 length of the window slider kit according to the width of window, shorten the adjustable window kit if the width of...
- Page 11 INSTALLATION INSTRUCTIONS Installation in a sliding sash window Foam seal A 1. Cut the foam seal(adhesive type) to the proper length and (adhesive type) attach it to the window frame. See Fig.14. 2. Attach the window slider kit to the window stool. Adjust the length of the window slider kit according to the width of Fig.14 window, shorten the adjustable window kit if the width of...
-
Page 13: Water Drainage
INSTALLATION INSTRUCTIONS Water drainage: During dehumidifying modes, remove the drain Remove the plug from the back of the unit, install the drain drain plug connector (5/8" universal female mender) with 3/4" hose (locally purchased). For the models without drain connector, just attach the drain hose to the hole. -
Page 14: Care And Maintenance
CARE AND MAINTENANCE CARE AND MAINTENANCE IMPORTANT: 1) Be sure to unplug the unit before cleaning or servicing. 2) Do not use gasoline, thinner or other chemicals to clean Air filter the unit. (take out) 3) Do not wash the unit directly under a tap or using a hose. It may cause electrical danger. -
Page 15: Troubleshooting Tips
TROUBLESHOOTING TIPS TROUBLESHOOTING TROUBLES POSSIBLE CAUSES SUGGEST REMEDIES 1. Unit does not - P1 appears in the display window Drain the water in the bottom tray. start when pressing on/off - Room temperature is lower than Reset the temperature. button the set temperature.(Cooling mode) - The windows or doors in the room Make sure all the windows and... -
Page 16: Remote Controller
Specifications Model RG09K/BG (C)EF, RG09K/BG (C)EFU, Rated Voltage 3.0V (Dry batteries AAAX2) Lowest Voltage of 2.0V CPU Emitting Signal Transmission Distance 26 ft / 8 m (36 ft / 11 m range with 3.0 V) Environment -5 C 60 C (-41 F~140 NOTE: Temperature setting display: Celsius scale ( C): RG09K/BG (C) EF. - Page 17 Re pla c ing ba t t e rie s The remote controller uses two A A batteries (R03/LR03X2) (1) Slide the cover of the battery compartment off according to the arrow direction, then replace the old batteries with new ones. (2) Insert the new batteries making sure that the(+) and (-) of battery are installed correctly.
- Page 18 R emote C ontroller Features ON/OFF Button : Push this button to start operation, push the button again to stop operation. MODE Select Button: Each time you push the button, a mode is selected in a sequence that goes from AUTO COOL , FAN and HEAT...
- Page 19 Remote Controller Features NOTE: Press and hold buttons together for 3 seconds will alternate the temperature display between the C & F scale. SLEEP Button :In SLEEP mode, the set temperature will increase (cooling) or decrease (heating) by 1 C (2 F) over the next 30 minutes and by another 1 C (2 F) after an additional 30 minutes.
- Page 20 Indicators on remote controller Tra nsm ission I ndic at or This transmission indicator lights when remote controller transmits signals to the indoor unit. M ode displa y Displays the current operation mode. Including AUTO( ), COOL( ), DRY( ), HEAT( AUTO (Not applicable to cooling only models), FAN ONLY (...
- Page 21 Setting the clock Before you start operating the air conditioner, set the clock of the remote controller using the procedures given in this section. The clock panel on the remote controller will display the time regardless of whether the air conditioner is in use or not. I nit ia l Se t t ing or t he Cloc k After batteries are inserted in the remote controller, the clock panel will display "12:00".
- Page 22 Automatic operation When you set the air conditioner in AUTO mode, it will automatically select cooling, heating (on certain models), or fan only operation depending on what temperature you have selected and the room temperature. Once you select the operating mode, the operating conditions are saved in the unit's microcomputer memory.
- Page 23 Cooling/Heating/Fan only operation St a r t Ensure unit is plugged and power is available. The OPERATION lamp on the display panel of the unit starts flashing. 1.Mode select button (MODE) Press to select COOL, HEAT (on some models only), or FAN ONLY 2.TEMP/TIME button Set the desired temperature, the most comfortable temperature is between 21ºC - 28ºC (70ºF - 83ºF).
- Page 24 Timer operation 1. TIMER button Press the TIMER button, the remote displays 0.0 alongside either the TIMER ON or TIMER OFF indicator, and will flash. 2. TEMP/TIME button Press to set the desired time. Forward Backward Press or hold the forward or backward button to change the Auto time by 0.5 hour increments, up to 10 hours, then at 1 hour increments up to 24 hours.
- Page 25 Example of timer setting TIMER ON (Timer Start Operation) The TIMER ON feature is useful when you want the unit to turn on automatically before you return home. The air conditioner will automatically start operating at the set time. IMPORTANT:The time will be registered within a 3 second period (after pressing the TEMP/TIME button), so you should continue pressing the button until the...
- Page 26 COMBINED TIMER (Setting both ON and OFF timers simultaneously) TIMER OFF TIMER ON Stop Start operation) This feature is useful when you want to stop the air conditioner after you go to bed, and start it again in the morning when you wake up or when you return home.
- Page 27 WARRANTY Thank you for purchasing this UBERHAUS product. These products have been made to demanding high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 36 months from the date of purchase. This warranty does not affect your statutory rights.
