COMAC CAL FLOW 45 Installation And Technical Conditions page 23

Inter-flanged design
Diameter D
nominal Outside diameter
[mm] of sensor
15 51
20 61
25 71
32 82
40 92
50 107
65 127
80 142
100 168
125 194
150 224
200 284
The Table is for PN25.
Manual FLOW 45
L
Building length Building height
of sensor of sensor
90 110
90 120
90 130
90 140
110 150
110 165
130 185
130 200
200 226
200 253
200 283
200 340
Page 23 (total 28)
D1 Weight of
detached flow
sensor (kg)
2
2
3
3
4
4
5
6
7
9
11
14
D2 Compact
Building height flow meter
of comp. meter weight (kg)
195
205
215
226
236
251
271
286
312
338 10
368 12
427 15
COMAC CAL s.r.o.
3
3
4
4
5
5
6
7
8
