- Page 1 Arc Welding Power Supply PA20P-x, PA40P-x, PA60P-x, PA100P-x, PA-200P-x Single & Multi-output DC TIG Welders OPERATION MANUAL 961-00035 rev11...
- Page 2 Conversion to new layout 2020-04 Detail Update Copyright 2020: Amada Weld Tech UK Ltd All rights reserved. The products named in this manual are only used for identification purposes and may be trademarks or registered trademarks of the respective companies. 961-00035 rev11...
-
Page 3: Table Of Contents
Operating Instructions PA-xxP Table of Contents Table of Contents General Information ......................5 Technical Description ......................6 Technical Specification .....................6 Introduction ........................7 Commissioning ........................8 Electrical Connections ......................8 Shield Gas Connections ....................9 Rear Panel Layout ......................10 Getting Started ........................ 12 3.4.1 Power on .......................... 12 3.4.2 The Default Menu Screen .................... - Page 4 Operating Instructions PA-xxP Table of Contents 10.1 RS232 Port (9way D Type) ....................34 10.2 MWSBus ........................... 34 10.3 USB Port .......................... 34 10.4 AVM Voltage Output Terminals ..................35 10.5 Single Output Digital I/O (37way D Type) ..............35 10.6 Multiple Output Digital I/O (37way D Type) ..............
-
Page 5: General Information
Restrictions on use environment conditions Use this equipment in an environment without conductive dust. If conductive dust enters into equipment, it may cause failure, electric shock or ignition. If using equipment in such environment, consult Amada Weld Tech. Warning 961-00035 rev11... -
Page 6: Technical Description
Operating Instructions PA-xxP Technical Description Technical Specification PA-20P-x PA-40P-x PA-60P-x PA-100P-x PA-200P-x Maximum Output 20Amps 40Amps 60Amps 100Amps 200Amps Current Output Voltage Main Supply Main Supply Main Supply Main Supply Main Supply 80V D.C. 70V D.C. 70V D.C. 45V D.C. 45V D.C. -
Page 7: Introduction
Operating Instructions PA-xxP Introduction Thank you for purchasing this MacGregor Arc welding power source. This manual is designed to help the new user to understand and operate the equipment quickly and safely. Please take a few moments to become familiar with the equipment and this manual before attempting to use the equipment. -
Page 8: Commissioning
Operating Instructions PA-xxP Commissioning Electrical Connections Use a properly rated Mains Service Supply An identification plate on the rear panel specifies the input mains voltage requirement. Provide Proper Ventilation Caution Use Lifting Gear to Move the Unit DO NOT Operate Machine Without Covers DO NOT Operate With Suspected Failures DO NOT... -
Page 9: Shield Gas Connections
Operating Instructions PA-xxP Shield Gas Connections The recommended shielding gas is Argon. This should be connected to the ‘GAS IN’ port on the rear of the welder. Please ensure the Argon gas is shut off at the bottle, and that the pressure is a maximum of 0.03MPa, before connecting to the welder. -
Page 10: Rear Panel Layout
Operating Instructions PA-xxP Rear Panel Layout PA-100P and PA-200P Positive Output Voltage monitor for AVM Isolated RS232 Port AUX drive fuse 2A (workpiece) Optional Gas inlet Negative Connections Cooling Fan Outlet and outlet To Welding Torches. External Input / Keep clear connections. - Page 11 Operating Instructions PA-xxP PA-20P, PA-40P and PA-60P Trigger/faults Isolated RS232 External Input / Port Program select Positive Output (workpiece) Port Optional Gas inlet and outlet connections. Negative Connections Voltage monitor for AVM To Welding Torches. Ensure any AUX drive fuse 2A (T) unused outputs have the supplied...
-
Page 12: Getting Started
Operating Instructions PA-xxP Getting Started 3.4.1 Power on Ensure the unit is connected to a suitable mains lead and all the cables are properly connected to the welding torch. Switch on. The Indicator LED below the left corner of the screen will illuminate red, then flash orange (while system booting up), then go steady green. -
Page 13: Information Colour Coding Key
Operating Instructions PA-xxP 3.4.3 Information Colour Coding Key All of the menus on the welder use the following colour code. Additionally the background colour of the screen changes to indicate whether the welder is either in SETUP (MAN MODE) black background or RUN (AUTO MODE) blue background. Pressing this key returns or exits the current screen. -
Page 14: Memory Organisation
Operating Instructions PA-xxP 3.4.4 Memory Organisation 3.4.4.1 Memory Locations (Profiles) The PAxxP has 99 memory locations each of which is able to store the complete details of either a single or double pulse weld profile. In order to identify the memories, each location is given a number between 1 and 99. -
Page 15: Limit Functions
Operating Instructions PA-xxP Limit Functions 3.5.1 Monitored Limit Parameters The PAxxP controls the weld current output. Since V=IxR (Ohms Law), as the arc resistance changes, the voltage will reflect this change. Hence the PAxxP measures this voltage parameter in real time as the weld occurs, thereby allowing the machine to react to unexpected weld conditions. -
Page 16: Password Entry Screen (Log In/Out)
There are three 4 digit passwords on the system. USER. The factory default for this is 0000. BACKUP. Maintained by Amada Weld Tech UK Ltd for each machine. Can be supplied to customer if user password changed and then lost/forgotten. -
Page 17: Setup (Man Mode)
Operating Instructions PA-xxP Setup (Man mode) Setup screen Enable/Disable Voltage limits Pulse 1. Enable/Disable Energy limits Pulse 1. Turns Turns GREEN to indicate limits enabled/on. GREEN to indicate limits enabled/on. Turns RED on a fault, press for information. Displays Current Profile number And name. - Page 18 Operating Instructions PA-xxP Enable/Disable Voltage limits Pulse 2. Turns Enable/Disable Energy limits Pulse 2. Turns GREEN to indicate limits enabled/on. GREEN to indicate limits enabled/on. Displays Current Profile number and name. Minimum and Maximum voltage measured during peak period. Delay time Returns to the between pulse 1 pulse 1 screen.
-
Page 19: Setup (Man Mode) Graph Screen
Operating Instructions PA-xxP Setup (Man mode) Graph Screen Yellow lines indicates peak period during which the min and max readings are taken. Minimum and maximum voltage measured during the peak period i.e. between the High Voltage Limit yellow lines. Low Voltage Limit. Energy measured in the weld. -
Page 20: Setup (Man Mode) Load Screen
Operating Instructions PA-xxP Setup (Man mode) Load Screen Enables profile to Moves in increments of be viewed before it 5 profiles. is loaded. Moves in increments of 10 profiles. Profile list. Shows 5 profiles. Press one to view data in VIEW PROFILE window. -
Page 21: Setup (Man Mode) Save Screen
Operating Instructions PA-xxP Setup (Man mode) Save Screen Text label, touch to change. Maximum characters 8. Enter Profile number. Return to edit screen, no save. Returns to previous screen. Saves profile in specified location. This screen enables a profile to be saved. To select the location or change the name, touch the appropriate box. -
Page 22: Profile Editor
Operating Instructions PA-xxP Profile Editor Profile Editor screen Enable/Disable Voltage limits Pulse 1. Enable/Disable Energy limits Pulse 1. Turns Turns GREEN to indicate limits enabled/on. GREEN to indicate limits enabled/on. Displays Current Profile number And name. Measured energy of Minimum and weld pulse. - Page 23 Operating Instructions PA-xxP Enable/Disable Energy limits Pulse 2. Turns Enable/Disable Voltage limits Pulse 2. GREEN to indicate limits enabled/on. Turns GREEN to indicate limits enabled/on. Displays Current Profile number and name. Minimum and Minimum and maximum Maximum voltage energy limits. limits.
-
Page 24: Profile Editor Load Screen
Operating Instructions PA-xxP Profile Editor Load Screen Enables profile to Moves in increments of be viewed before it 5 profiles. is loaded. Moves in increments of 10 profiles. Profile list. Shows 5 profiles. Press one to view data in VIEW PROFILE window. -
Page 25: Profile Editor Save Screen
Operating Instructions PA-xxP Profile Editor Save Screen Text label, touch to change. Maximum characters 8. Enter Profile number. Return to edit screen, no save. Returns to previous screen. Saves profile in specified location. This screen enables a profile to be saved. To select the location or change the name, touch the appropriate box. -
Page 26: Run (Auto Mode)
Operating Instructions PA-xxP Run (Auto Mode) Run (Auto Mode) Main Monitor Screen Turns RED to indicate last weld caused a fault, Press for more information. Number of weld attempts Number of arc fails/faults Last weld energy in Joules Weld profile number currently being used. -
Page 27: Run (Auto Mode) Monitor Screen
Operating Instructions PA-xxP Run (Auto mode) Monitor Screen Enable/Disable Voltage limits. Turns Enable/Disable Energy limits. Turns GREEN GREEN to indicate limits enabled/on. to indicate limits enabled/on. Turns RED on a fault, press for information. Displays Current Profile number And name. Measured energy of Minimum and... - Page 28 Operating Instructions PA-xxP Displays Displays output/arc energy trend voltage trace for graph. last weld triggered. Displays detailed Exit returns fault information. to profile monitor. Yellow lines indicates the peak weld period during which the minimum and maximum voltage readings are taken. Time is scaled Indicates when to the overall weld pulse period.
- Page 29 Operating Instructions PA-xxP Scale for upper Y axis. 0 to 999.9 Joules. The welder records energy readings for the Last Energy readout last 1000 welds, then rolls round. for pulse 1. The graph/window will show the last 100 welds. Exit returns to Scale for lower Y monitor menu.
-
Page 30: Run (Auto Mode) Load Screen
Operating Instructions PA-xxP Run (Auto mode) Load Screen Enables profile to Moves in increments of be viewed before it 5 profiles. is loaded. Moves in increments of 10 profiles. Profile list. Shows 5 profiles. Press one to view data in VIEW PROFILE window. -
Page 31: Configuration Screen
I/O ouput. This is the logic of the digital outputs either normal, or inverted. Language. Changes the current default language for the display. Calibration. This screen is password protected, and requires the Amada Weld Tech engineer password to be entered. -
Page 32: Gas Control Screen
Operating Instructions PA-xxP Gas Control Screen Units fitted with gas control provide the ability to set pre and purge gas valve actuations. In addition, the gas valve maybe turned on and off either via the keypad or from an external input 961-00035 rev11 32/42... -
Page 33: Io Monitor Screen
Operating Instructions PA-xxP IO Monitor Screen Show the status of the inputs on the 37 Shows the status of the program select way IO connector. bits, on the 15 way connector. Touch to force the outputs on to test the wiring and setup the PLC inputs. -
Page 34: Control Connections
Operating Instructions PA-xxP Control Connections Amada Weld Tech recommend the use of screened cables for all connections. 10.1 RS232 Port (9way D Type) The 9 Way D type connector provides an optically isolated RS232 communications port. Connections are as follows;... -
Page 35: Avm Voltage Output Terminals
Operating Instructions PA-xxP 10.4 AVM Voltage Output Terminals These terminals are designed for connection to a MacGregor AVM (Arc Voltage Monitor). They are not isolated from the welding circuit, and should NOT be used for any other purpose. Take care when making these connections to match polarity, RED is positive, BLACK is negative. Take care that these wires are not short circuited or crossed. -
Page 36: Multiple Output Digital I/O (37Way D Type)
The Sequence Start input fires outputs 1 to 4, with a delay of 100ms between welds. The Pedal input is only active when the machine is in setup (man mode). Amada Weld Tech recommend the use of screened cables for all connections. 961-00035 rev11... -
Page 37: Remote Profile Select (15Way D Type)
If no profile is selected, the welder welds with the profile number displayed on the front panel screen. Profile numbers that can be selected are 1 to 63. All other numbers are invalid. Amada Weld Tech recommend the use of screened cables for all connections. 961-00035 rev11... -
Page 38: Process Faults And Warnings
Operating Instructions PA-xxP Process Faults and Warnings Please refer to the ‘Trouble Shooting Guide’ if the arc is failing to ignite. The unit will display context based warning screens, reporting where appropriate the fault detail. 11.1 High Voltage Limit Fault Violation of a high voltage limit can indicate an increase in the arc gap or a loose connection in the torch or work piece. - Page 39 Operating Instructions PA-xxP Overheat condition warning General warning screen format Double pulse warning at power up 961-00035 rev11 39/42...
-
Page 40: Basic Trouble Shooting Guide
9. If the problem is still present after performing all of the tests above, it could be that the internal fuse has blown. If it is suspected that this is the fault with the unit, please contact Amada Weld Tech for assistance, as it may be necessary to return the unit for repair. 961-00035 rev11... - Page 41 Operating Instructions PA-xxP If the timing of the external signals (weld trigger inputs) is too fast, then the welder will stop operating. All of the external fault signals are energised, and no inputs are recognised. The welder will start sounding its beeper on and off. To recover, power cycle the unit, and check the timing of the external PLC signals.
-
Page 42: Index
Operating Instructions PA-xxP Index 13.1 Headword Index Additional Warnings ............... 38 Memory Locations (Profiles) ............14 AVM Voltage Output Terminals ............. 35 Memory Organisation ..............14 Monitored Limit Parameters ............15 Multiple Output Digital I/O (37way D Type) ........36 MWSBus ..................
