Environmental Performance Specifications
Environmental Performance Specifications
The following table provides the environmental performance specifications of the Cisco NCS 2000 Series
passive optical modules.
Table 2: Environmental Performance Specifications
Environmental Condition
Continuous Operative
Temperature Range
(OTR)
Power Handling for the
Optical Port
Max USB current
consumption
Mechanical Specifications
The following table provides the mechanical dimensions of the passive optical modules, fiber shuffle, loopback
caps, and MPO fan-out unit.
Table 3: Mechanical Specifications
Optical unit
N C S 2 K - M F - 1 6 A D - C F S =
N C S 2 K - M F - 4 X 4 - C O F S =
N C S 2 K - M F - M P O - 8 L C =
NCS2K-MF-DEG-5=
NCS2K-MF-UPG-4=
N C S 2 K - M F - M P O - 1 6 L C =
Installing the Cisco NCS 2000 Series Passive Optical Modules
36
Min
-5
23
500
500
Description Physical Dimensions (mm)
Height
16-channel 35
colorless
omni-directional
add/drop
4-channel 17
colorless
omni-directional
add/drop
MPO to 8-LC 17
adapter
5-degree mesh 17
module
4-degree 17
upgrade module
MPO-16 to 35
16-LC fan-out
module
Installing the Cisco NCS 2000 Series Passive Optical Modules
Max Units
55 Celsius
131 Fahrenheit
mW
—
mA
Width Depth
179 164
179 164
179 164
179 160
179 160
179 146.5
Weight (kg)
0.8
0.58
0.58
0.58
0.58
0.689
