7
Optional | Female connector front and isometric view, notice the
white marker on top (highlighted in orange).
9
Female
Optional | Align the white marker of the Female and Male
connector.
11
Turn the power ON.
Male
8
Optional | Male connector front and isometric view, notice the
white marker on top (highlighted in orange).
10
Female
Optional | Snap the connector while keeping the white marker
aligned.
Male
Manual | liniLED® Diffuse
9
