Introduction And Highlights..............1 About This Guide..................1 The Microchip Internet Web Site............2 Customer Support.................2 Chapter 1. MCP1601 Evaluation Board ..........3 Introduction ................3 Detailed Description ..............4 Test Points ................6 Appendix A. Schematic and Board Layouts ......... 7 Introduction................7 Evaluation Board Schematic ...........
Page 4
MCP1601 Eval. Board User Guide NOTES: DS51315A-page iv 2002 Microchip Technology Inc.
This document describes how to use the MCP1601 Evaluation Board. The User’s Guide layout is as follows: • Chapter 1: MCP1601 Evaluation Board - For user’s evaluating the MCP1601 device, this section describes how to use the various features of the board.
MCP1601 Eval. Board User Guide THE MICROCHIP INTERNET WEB SITE Microchip provides easy access to our documentation and on-line support through our World Wide Web Site at www.microchip.com. You can download files from the web site or from our FTP site at ftp://ftp.microchip.com...
Chapter 1. MCP1601 Evaluation Board INTRODUCTION The MCP1601 Evaluation Board is designed to demonstrate the use of the MCP1601 Synchronous BUCK Regulator in a step down, inductor-based DC/DC converter application. It also describes the capability of the MCP1601 Evaluation Board and how to select the desired Synchronous Converter operating mode and program the output voltage.
, position 1 pushed to the right, the SHDN pin is pulled up and the output of the MCP1601 device is enabled. When switch U , position 1 is to the left, the MCP1601 device is in a low quiescent current SHDN mode and the output is disabled. DS51315A-page 4...
Page 9
Selecting the Operating Mode - Using Switch U3, Position 2 1.2.4 The multi-function SYNC/PWM pin on the MCP1601 is used to set the operating mode of the device. The three operating modes are: • Automatic switching from PFM Mode to PWM mode and back •...
1.3.1 The /SHDN or shutdown test point can be used to monitor the level of the shutdown pin or as an input to the shutdown pin of the MCP1601 device. With switch U , position 1 in the “off” position, a 1 MΩ resistor will pull the pin low.
Evaluation Board. A.1.1 Highlights The MCP1601 Evaluation Board is constructed using one (1) silk screen layer and two (2) 1 oz. metal wiring layers. The bottom metal wiring layer is a single ground plane which is routed to partition the P high current return pin from the small signal A return pin on the MCP1601 device.
MCP1601 Eval. Board User Guide Appendix B. Bill Of Materials (BOM) TABLE B-1: BILL OF MATERIALS (BOM) Reference Manufacturer Description Manufacturer Designator Part Number Ω 9C08052A1224FKHFT ® Resistor 1.24 M 1/8W 1% 0805 SMD Yageo Ω ® ERJ-6ENF6343V Resistor 634 k...
