Rear panel

XM jack
(U.S.A. and Canada
models only)
Connect the XM Mini-
Tuner Dock (sold
separately).
☞ P. 53
DOCK terminal
Connect a Yamaha iPod
universal dock
(sold separately).
☞ P. 23
L
GND
R
DOCK
XM
PHONO CD IN MD/
(PLAY) CD-R (REC)
DIGITAL OUTPUT
OPTICAL
DVD IN1
1
MD/CD-R
MD/CD-R
2
DTV
IN2
/CBL
3
DVD
DTV/CBL 4
FM
75 UNBAL.
OUT
OPTICAL
COAXIAL
CD
5
HDMI
DVD
6
DIGITAL INPUT
HDMI connectors
Connect the HDMI
components.
☞ P. 16
DIGITAL INPUT/
OUTPUT jacks
Connect the digital audio
cable plugs.
☞ P. 19-21

Connections

AUDIO jacks
Connect the analog audio
cable plugs.
☞ P. 18-21
MULTI CH INPUT jacks
Connect the input source
component equipped with the
multi-channel output jacks.
AUDIO
OUT DVD DTV/CBL IN DVR OUT IN VCR OUT
DVD DTV/CBL
A B
Y P P Y P P
B R B R
C
MONITOR OUT DVR
COMPONENT VIDEO
FRONT B/ZONE2/
PRESENCE
EXTRA SP L
R
ANTENNA TRIGGER
OUT
GND AM
+12V
15mA MAX.
REMOTE
IN OUT
TRIGGER OUT
Outputs the control signals to
external components.
REMOTE IN/OUT jacks
Connect the remote control
input and output jacks of
the Yamaha components.
☞ P. 23
ANTENNA terminals
Connect the FM and AM
antenna.
☞ P. 24
ZONE 2 OUT jacks
Connect the amplifier in Zone 2.
☞ P. 90
PRE OUT jacks
Connect external amplifiers
and an active subwoofer.
☞ P. 22
MULTI CH INPUT ZONE 2 PRE OUT
FRONT(6CH) CENTER OUT SINGLE
L
R
SB(8CH) SURROUND SUBWOOFER FRONT SURROUND SUR. BACK
MONITOR
DVD DTV/CBL DVR VCR
IN OUT IN OUT
OUT
VIDEO
SPEAKERS
FRONT A CENTER SURROUND
L L
R R
Video jacks
Connect the video cable plugs.
Speaker terminals
Connect the speakers.
☞ P. 13
CONNECTIONS
VOLTAGE SELECTOR
(Asia and General
models only)
☞ P. 4
☞ P. 22
CENTER
SUBWOOFER
VIDEO
S VIDEO
SURROUND BACK/
BI-AMP
L
R
SINGLE
AC OUTLETS
☞ P. 18-20
AC OUTLET(S)
☞ P. 24
11
En
